Replace Relay Support Holder, Side Wall Rear Opel Corsa D

Fuse Box 2 illustrations ~102 words

Remove

  1. 1. Disconnect battery
  2. 2. Open service flap, left side
  1. 3. Remove relay support, side wall • Remove relay support cover (1) • Unscrew 2 nuts (2) and (3) • Take out relay support – Disconnect wiring harness (4) – Move and insert required pins

Note. Ensure correct pin assignment

  1. 4. Remove relay support holder • Unscrew 2 screws (1) and (2) • Remove bracket

Install

  1. 5. Install relay support holder • Insert bracket • Tighten 2x bolts
  2. 6. Install relay support, side wall
  3. 7. Close service flap
  4. 8. Connect battery
  5. 9. Program volatile memories
