Replacing Battery Tray Opel Corsa D

Remove

1. 1. Disconnect battery
2. 2. Loosen positive distribution • Open positive distribution • Disconnect positive terminal (1) • Unclip positive distribution and put aside – Undo 3x clip (2)

3. 3. Remove battery • Unscrew bolt (1) • Remove battery bracket • Remove battery

4. 4. Remove battery support. • Unscrew 3x bolts (1) • Unclip compact plug (2) • Unclip glow-plug indicator control unit (3) • Unclip 3 cable ties (4) • Unclip wiring harness

Note. Applies only to vehicles with diesel engine.

Install

5. 5. Install battery holder • Insert battery tray • Attach wiring harness • Clip in compact plug • Clip in 3 cable ties • Clip in glow-plug indicator control unit • Tighten 3x bolts
6. 6. Install battery • Insert battery • Insert battery bracket • Tighten bolt
7. 7. Fasten positive distribution • Clip in positive distribution – Clip in 3x clip • Tighten screw on positive terminal 5 Nm • Close positive distribution
8. 8. Connect battery
9. 9. Program volatile memories
