The Z 17 DTH engine is fitted with the Denso engine management system.
The engine management system must continually regulate the injection map, the number of injection processes and the amount of fuel injected, depending on temperature, load and engine speed.
Components of the Denso Engine Management System
| 1 | Engine control unit | 14 | Ignition "ON" (terminal 15) |
|---|---|---|---|
| 2 | Crankshaft sensor | 15 | Electric throttle valve |
| 3 | Camshaft sensor | 16 | EGR valve adjuster |
| 4 | Pressure accumulator sensor | 17 | Vacuum valve - turbocharger |
| 5 | Fuel temperature sensor | 18 | Metering unit |
| 6 | Charge pressure sensor | 19 | Injectors |
| 7 | Intake air temperature sensor | 20 | Pre-heating system control unit |
| 8 | Coolant temperature sensor | 21 | Shielded glow plugs |
| 9 | Oil quantity sensor | 22 | Fuel filter heater |
| 10 | Instrument cluster | 23 | Engine warning light |
| 11 | Air conditioning control unit | 24 | Vacuum valve - swirl flaps |
| 12 | Speed regulator | 25 | Fan relay |
| 13 | Accelerator pedal sensor |
