Body System — Heated Windows — wiring diagram (2008) Opel Combo C

Components on these wiring diagrams 25

Click a component to highlight it on every diagram it appears on.

• 5 — Body, Rear, Left
• A15 — Body Control Module
• Air — Conditioning
• Battery — Positive Voltage
• Body — Control Module
• Electronic — Climate Control
• Fuse — F14 7.5 Ampere Constant Voltage
• Fuse — F18 20 Ampere Constant Voltage
• Fuse — F3 7.5 Ampere Constant Voltage
• Ground
• Heated — Back Window
• Heating
• Ignition — Voltage
• K49 — Relay - Heated Back Window
• Mirror — Heating Element Control
• Not — Air Conditioning
• Not — Electronic Climate Control
• Outside — Mirror
• Previous
• R22 — Heated Back Window
• Rear — Defog Element Control
• Rear — Defog Relay Control
• X1 — Instrument Panel & Body Front
• X14 — Body Front & Body Rear, Left
• X59 — Body Rear, Left & Rear Window
