Field Remedy: 1958
| Subject: | Engine Z20LET/L/R - Improved cooling servicekit |
| Models: | Engines: | Option: |
|---|---|---|
| Astra-G 2001...2006,Zafira 2002...2006,Astra-H 2004...2006,Zafira-B 2005...2006 | Z20LET,Z20LET,Z20LEL| Z20LER,Z20LER |
| Complaint: | Loss of power, noise from turbocharger and/or oil leakage at turbocharger caused by damaged turboshaft bearings . |
|---|---|
| Cause: | Insufficient cooling of turbocharger. |
| Production: |
Remedy:
In case of customer complaint replace turbocharger and install cooling hose kit.
Working procedure:
1. Drain coolant (Picture I).
- open drain bolt (1) at radiator - collect coolant - close drain bolt
2. Replace all cooling lines and cooling hoses.
Note: For replacement of the cooling lines and cooling hoses the turbo- charger has to be removed.
Astra-G: - see working procedure "Exhaust Manifold with Turbocharger, Remove and Install (Z 20 LET)", group "J", Service Instruction Astra-G. (Document Number 00032432)
Astra-H Z20LEL and Z20LER: - see working procedure "Exhaust Manifold with Turbocharger, Remove and Install ", group "J", Service Instruction Astra-H. (Document Number 00501739)
Zafira-A: - see working procedure "Exhaust Manifold with Turbocharger, Remove and Install", group "J", Service Instruction Zafira-A. (Document Number 00101859)
Zafira-B: - see working procedure "Exhaust Manifold with Turbocharger, Remove and Install", group "J", Service Instruction Zafira-B. (Document Number 00501739)
Note: A: Front view of turbocharger after installing of repair kit turbo charger B: Back view of turbocharger after installing of repair kit turbo charger
3. Attach upper cooling hose to cooling line (Picture III).
- use 2x cable strap (arrows)
4. Refill coolant
- see working procedure "Coolant System Charge and Bleed", group "J", of the corresponding Service Instruction.
Spare-Parts: Part-No.: Catalogue-No.:
Astra-G: Repair kit, turbocharger 93188799 58 49 933
Astra-H / Zafira-B: Repair kit, turbocharger 93188801 58 49 935
Zafira-A: Repair kit, turbocharger 93188800 58 49 934
Please note: Turbocharger repair kit fits only to turbocharger with P/N 55 559 848 / Cat.No. 5849040. (Need to be installed for vehicles prior MY 2006)
Labour Times: TC: Hours:
Astra-G: U3 195 80 Install repair kit 90 1.7 turbocharger Astra-H: U3 195 81 Install repair kit 90 1.7 turbocharger
Zafira-A: U3 195 82 Install repair kit 90 1.7 turbocharger
Zafira-B: U3 195 83 Install repair kit 90 1.8 turbocharger
The costs for this repair will be covered during the normal warranty. The regular warranty procedure should be used for claiming Set-up-time.
| FunctionalGroup: | J - Engine |
|---|---|
| Complaint Group: | 10 - Leakages,14 - Noises or Vibrations,20 - Poor Performance |
| Trouble Code: | Non |
