Replace Light Switch Unit Opel Astra H

Remove

1. 1. Release light switch centre

Note. To release the light switch unit, press in rotary switch (1) in position "0", move depressed rotary switch to centre position (3), light switch unit (2) is released.

2. 2. Withdraw light switch unit
3. 3. Disconnect wiring harness plug for light switch unit • Disconnect wiring harness plug – Press down secondary retainer (2) – Release retainer (1)

4. 4. Remove decor strip • Unclip 8x clip (arrows)

Note. Only when replacing the light switch unit.

Install

5. 5. Connect wiring harness plug for light switch unit
6. 6. Insert light switch unit
7. 7. Release light switch unit

Note. Turn rotary switch (1) to position "0", light switch lock (2) protrudes.
