Maintenance Information: Overview Oldsmobile Silhouette II

SERVICE PARTS IDENTIFICATION LABEL

The service parts identification label, located on the inside cover of the jack storage compartment, lists the vehicle's VIN, model designation, paint information, and all production options and special equipment fitted to vehicle at time of production.

Fuse & Circuit Breaker Identification - 1997 Models

1. FRT HVAC HI BLWR Blower Motor Resistor
2. HEADLAMP DRL Control Module, Headlamp Dimmer Switch & Headlamp Switch
3. PWR SEAT/PSD 6-Way Power Seats & Rear Side Door Actuator Motor
4. PWR WDO/RR VENT Front Power Windows
5. ABS MDL BATT Electronic Brake Tranction Control Module (EBTCM)
6. ABS SOL LH & RH Front Brake Solenoid Valve
7. ABS/TCS IGN Electronic Brake Control Relay & EBTCM
8. BCM PRGRM Body Control Module (BCM)
9. CIGAR/DLC Cigarette Lighter & Data Link Connector
10. CRUISE Cruise Control Module, Switch & Release Switch
11. CTSY LAMP BCM
12. DRL DRL Control Module
13. ELC Electronic Level Control (ELC), Air Compressor & ELC Relay
14. ELEC PRNDL Instrument Cluster To PRNDL Indicators
15. FRT HVAC LOW/MED BLWR Heater-A/C Control
16. FRT PWR SCKT Front Electric Accessory Plug Housing
17. FRT WPR/WSHER Windshield Wiper/Washer Motor & Switch
18. HAZARD Turn Signal Switch
19. HVAC/DRL Air Recirculation Motor, DRL Control Module, Heater-A/C Control, Temperature Door Actuator (Front), Rear Window Defogger Relay
20. IGN 1 ELC Sensor, BCM, Electronic Brake Control Indicator Lamp Driver Module, Instrument Panel Cluster, Rear Side Door Actuator Motor, Rear Window Wiper/Washer, Mutltifunction Switch (Foglamp Switch/TCS Enable Switch), Stoplamp/Torque Converter Clutch (TCC) Switch
21. MALL/RADIO/DIC BCM, Driver Information Display, Radio, Radio Rear Speaker Amplifier
22. PCM IGN MAIN Relay & PCM
23. PSD Rear Side Door Actuator Motor
24. PWR LOCK BCM
25. PWR MIRROR Power Remote Control Mirror Switch
26. PWR QTR VENT Interior Lamps, Multifunction Switch (Power Vent Switch)
27. RR HVAC Rear Blower Motor, Rear Heater-A/C Control, Temperature Door Actuator (Rear)
28. RR DEFOG Rear Window Defogger Relay
29. RR PWR SCKT Rear Electric Accessory Plug Housing
30. RR WPR/WSHR Rear Window Wiper Motor, Rear Window Wiper/Washer, Multifunction Switch (Rear Window Wiper/Washer Switch)
31. SIR Inflatable Restraint Control Module
32. STOP LAMP Stoplamp Switch To Stoplamp
33. SUNROOF Sunroof Control Module
34. SWC ACCY Steering Wheel Radio Control Switches
35. SWC BACKLIGHT Steering Wheel Radio Control Switches (Illumination)
36. T/SIG Turn Signal Switch

Fuse & Circuit Breaker Identification - 1998 Models

1. HEADLAMP DRL Control Module, Headlamp & I/P Dimmer Switch
2. PWR WDO/RR VENT Front Power Windows
3. PWR SEAT/PSD 6-Way Power Seats & Rear Side Door Actuator Motor
4. FRT HVAC HI BLWR Blower Motor Hi Speed Relay In Module
5. SWC BACKLIGHT Steering Wheel Radio Control Switches (Illumination)
6. ELEC PRNDL Instrument Cluster To PRNDL Indicators
7. PWR MIRROR Power Remote Control Mirror Switch
8. CRUISE Cruise Control Module, Switch & Release Switch
9. PWR QTR VENT Interior Lamps, Multifunction Switch (Power Vent Switch)
10. FRT WPR/WSHER Windshield Wiper/Washer Motor & Switch
11. PWR LOCK BCM
12. RH T/LP Not Used
13. RR FOG LP Not Used
14. CIGAR/DLC Cigarette Lighter & Data Link Connector
15. T/SIG Turn Signal Switch
16. RR HVAC Rear Blower Motor, Rear Heater-A/C Control, Temperature Door Actuator (Rear)
17. SWC ACCY Steering Wheel Radio Control Switches
18. HAZARD Turn Signal Switch
19. RR PWR SCKT Rear Electric Accessory Plug Housing
20. DRL DRL Control Module
21. LH T/LP Not Used
22. RR DEFOG Rear Window Defogger Relay
23. FRT PWR SCKT Front Electric Accessory Plug Housing
24. SIR Inflatable Restraint Control Module
25. FRT HVAC LOW/MED BLWR Heater-A/C Control
26. MALL/RADIO/DIC BCM, Driver Information Display, Radio, Radio Rear Speaker Amplifier
27. STOP LAMP Stoplamp Switch To Stoplamp
28. ABS MOD BATT Electronic Brake Tranction Control Module (EBTCM)
29. CAN VENT SOL Evaporative Emissions (EVAP) Canister Vent Solenoid Valve
30. ELC Electronic Level Control (ELC), Air Compressor & ELC Relay
31. CTSY LAMP BCM
32. IGN 1 ELC Sensor, BCM, Electronic Brake Control Indicator Lamp Driver Module, Instrument Panel Cluster, Rear Side Door Actuator Motor, Rear Window Wiper/Washer, Mutltifunction Switch (Foglamp Switch/TCS Enable Switch), Stoplamp/Torque Converter Clutch (TCC) Switch
33. SUNROOF Sunroof Control Module
34. RR WPR/WSHR Rear Window Wiper Motor, Rear Window Wiper/Washer, Multifunction Switch (Rear Window Wiper/Washer Switch)
35. LH HEADLP LOW Not Used
36. LH HEADLP HIGH Not Used
37. ABS/TCS IGN Electronic Brake Control Relay & EBTCM
38. ABS SOL LH & RH Front Brake Solenoid Valve
39. HVAC/DRL Air Recirculation Motor, DRL Control Module, Heater-A/C Control, Temperature Door Actuator (Front), Rear Window Defogger Relay
40. BCM PRGRM Body Control Module (BCM)
41. RH HEADLP LOW Not Used
42. RH HEADLP HIGH Not Used
43. PCM IGN MAIN Relay & PCM

Scheme 1
