Wiper & Washer: Overview Nissan Versa II

Wiper/washer Systems 3 illustrations ~879 words

Component Description

ComponentFunction
BCMMonitors combination switch status by performing the combination switch reading function. Sends front wiper relay and front wiper high relay ON signals to IPDM E/R.
IPDM E/RControls front wiper relay and front wiper high relay. Performs the auto stop control of the front wiper.
Combination switch (Wiper and washer switch)Provides input for wiper and washer control to BCM. Refer to " SYSTEM DESCRIPTION " for more information.
Front wiper motorDrives windshield wipers in HI or LO mode. Sends wiper stop signal to IPDM E/R.
Front washer motorPumps windshield washer fluid to windshield in wash mode.

Scheme 1

Scheme 1: System Diagram

LOW SPEED OPERATION

  1. Ignition switch ON.
  2. Front wiper switch in LO or MIST position.
  3. BCM reads the combination switch position and transmits the front wiper request signal (LO) to IPDM E/R using CAN communication.
  4. IPDM E/R turns ON the front wiper relay.

HIGH SPEED OPERATION

  1. Ignition switch ON.
  2. Front wiper switch in HI.
  3. BCM reads the combination switch position and transmits the front wiper request signal (HI) to IPDM E/R using CAN communication.
  4. IPDM E/R turns ON the front wiper relay and the front wiper high relay.

Scheme 2

Scheme 2: INTERMITTENT OPERATION
  1. Ignition switch ON.
  2. Front wiper switch INT.
  3. BCM reads the combination switch position. BCM calculates the delay interval based on the table below and then transmits the front wiper request signal (INT) to IPDM E/R using CAN communication.
  4. IPDM E/R turns ON the front wiper relay only once.
  5. BCM detects stop position of the front wiper motor based on the front wiper stop position signal received from the IPDM E/R.
  6. BCM transmits the front wiper request signal (INT) again after the delay interval.
Intermittent switch positionLength of delayDelay interval (s)
7Short ↑ ↓ Long0.4
61
52
43
35
210
116

Scheme 3

Scheme 3: AUTO STOP OPERATION
  1. Front wiper switch is turned OFF.
  2. BCM monitors wiper switch position by combination switch reading position function.
  3. BCM stops transmitting the front wiper request signal to the IPDM E/R.
  4. IPDM E/R detects the front wiper auto stop signal from the position of the front wiper motor (stop position/except stop position).
  5. When the front wiper request signal is stopped, IPDM E/R turns ON the front wiper relay until the front wiper motor returns to the stop position.
  6. IPDM E/R turns the front wiper relay OFF when the front wiper motor has reached the stop position.

MIST OPERATION

  1. Ignition switch ON.
  2. Front washer switch in OFF position.
  3. Front wiper switch in MIST position.
  4. BCM reads the combination switch position and transmits the front wiper request signal (LO) to IPDM E/R using CAN communication.
  5. IPDM E/R turns ON the front wiper relay.
  6. The front wiper operates once after the front washer operation.

WIPER/WASHER OPERATION

  1. Ignition switch ON.
  2. Front washer switch ON.
  3. The front washer switch provides ground for the front washer motor.
  4. BCM reads the combination switch position and transmits the front wiper request signal (LO) to IPDM E/R using CAN communication.
  5. BCM transmits the front wiper request signal (LO) to IPDM E/R using CAN communication.
  6. IPDM E/R turns ON the front wiper relay.
  7. The front wiper operates.

Note. BCM transmits the front wiper request signal (LO) so that the front wiper operates approximately 3 times after front washer switch OFF is detected.

FAIL-SAFE OPERATION

IPDM E/R performs the fail-safe function when the front wiper auto stop circuit is malfunctioning. Refer to " FAIL-SAFE ".

Description

In auto active test, the IPDM E/R sends a drive signal to the following systems to check their operation.

  1. Front wiper (LO, HI)
  2. Parking lamp
  3. License plate lamp
  4. Tail lamp
  5. Front fog lamp
  6. Headlamp (LO, HI)
  7. A/C compressor (magnet clutch)
  8. Cooling fan

Operation Procedure

Note. Never perform auto active test in the following conditions. Passenger door is open CONSULT is connected

  1. Close the hood and lift the wiper arms from the windshield. (Prevent windshield damage due to wiper operation) NOTE: When auto active test is performed with hood opened, sprinkle water on windshield beforehand.
  2. Turn the ignition switch OFF.
  3. Turn the ignition switch ON, and within 20 seconds, press the driver door switch 10 times. Then turn the ignition switch OFF.
  4. Turn the ignition switch ON within 10 seconds. After that the horn sounds once and the auto active test starts.
  5. After a series of the following operations is repeated 3 times, auto active test is completed.

Note. When auto active test has to be cancelled halfway through test, turn the ignition switch OFF. When auto active test is not activated, door switch may be the cause. Check door switch. Refer to " COMPONENT FUNCTION CHECK ".

ECU IDENTIFICATION

The IPDM E/R part number is displayed.

In auto active test, the IPDM E/R sends a drive signal to the following systems to check their operation.

  1. Front wiper (LO, HI)
  2. Parking lamp
  3. License plate lamp
  4. Tail lamp
  5. Front fog lamp
  6. Headlamp (LO, HI)
  7. A/C compressor (magnet clutch)
  8. Cooling fan

Note. Never perform auto active test in the following conditions. Passenger door is open CONSULT is connected

  1. Close the hood and lift the wiper arms from the windshield. (Prevent windshield damage due to wiper operation) NOTE: When auto active test is performed with hood opened, sprinkle water on windshield beforehand.
  2. Turn the ignition switch OFF.
  3. Turn the ignition switch ON, and within 20 seconds, press the driver door switch 10 times. Then turn the ignition switch OFF.
  4. Turn the ignition switch ON within 10 seconds. After that the horn sounds once and the auto active test starts.
  5. After a series of the following operations is repeated 3 times, auto active test is completed.

Note. When auto active test has to be cancelled halfway through test, turn the ignition switch OFF. When auto active test is not activated, door switch may be the cause. Check door switch. Refer to " COMPONENT FUNCTION CHECK ".

The IPDM E/R part number is displayed.

ComponentCapacityFuse No.Location
Front wiper motor30 A39IPDM E/R
Front washer motor10 A6Fuse block (J/B)
  1. Washer switch is integrated with combination switch.
  2. Washer switch supplies ground for the front washer motor.

The front wiper does not operate under any operation conditions.
