WIPER BLADE POSITION ADJUSTMENT
Clearance between the end of cowl top cover/front fender cover and the top of wiper blade center
Scheme 4
Standard clearance
R: 44.2 ± 7.5 mm (1.74 ± 0.30 in)
L: 67.1 ± 7.5 mm (2.64 ± 0.30 in)
Scheme 5
- Lift up wiper arm and set to the position where wiper arm can be locked back.
- Press and hold lever (A) of wiper blade (1). Pull in the direction indicated by the arrow as shown below and remove wiper blade from wiper arm (2). CAUTION: Wrap wiper arm using a shop cloth so that wiper blade does not damage windshield glass.
ADJUSTMENT
Washer Nozzle Spray Position Adjustment
Adjust spray positions to match the positions shown below.
Scheme 6
| Unit: mm (in) | ||||||||
|---|---|---|---|---|---|---|---|---|
| Passenger side | Driver side | |||||||
| A | B | C | D | E | F | G | H | |
| X | 321 (12.64) | 343 (13.50) | 60 (2.36) | 5 (0.20) | 60 (2.36) | 5 (0.20) | 321 (12.64) | 343 (13.50) |
| Y | 62 (2.44) | 129 (5.08) | 80 (3.15) | 184 (7.24) | 80 (3.15) | 184 (7.24) | 62 (2.44) | 129 (5.08) |
Scheme 7
- If washer nozzle (1) spray pattern is not within specification adjust using suitable tool (A). CAUTION: Do not use needle or small pin to adjust the washer nozzle. NOTE: Washer nozzle adjuster is included with shipment of washer nozzle. If wax or dust gets into the nozzle, remove wax or dust with a needle or small pin.
