Component Description
| Component | Function |
|---|---|
| BCM | Supplies power to power window switches. Controls retained power. |
| Main power window and door lock/unlock switch | Directly controls power window motor of all doors. |
| Power window and door lock/unlock switch RH | Controls front power window motor RH. |
| Rear power window switch | Controls rear power window motors LH and RH. |
| Front power window motor LH | Starts operating with signals from main power window and door lock/unlock switch. |
| Front power window motor RH | Starts operating with signals from main power window and door lock/unlock switch & power window switch RH. |
| Rear power window motor | Starts operating with signals from main power window and door lock/unlock switch & rear power window switch. |
| Front door switch LH or RH | Detects door open/close condition and transmits to the BCM. |
Scheme 1
BASIC OPERATION
- Power window system is activated by power window switch when ignition switch turns ON.
- Power window main switch opens/closes all door glass.
- Front and rear power window switch opens/closes the corresponding door glass.
- AUTO DOWN operation can be performed when power window main switch is depressed to the second detent.
- Power window lock switch can lock all power windows other than driver seat.
POWER WINDOW AUTO-OPERATION (FRONT DRIVER SIDE)
AUTO DOWN operation can be performed when power window main switch is depressed to the second detent.
RETAINED POWER OPERATION
- Retained power operation is an additional power supply function that enables power window system to operate for an additional 45 seconds after the ignition switch is turned OFF.
