SERVICE AFTER REPLACING TCM AND TRANSAXLE ASSEMBLY
Perform the applicable service in the following sheet when replacing TCM or transaxle assembly
| CAUTION | Do not start the engine until the service is completed. "A/T C/U POWER SUPPLY [P1701]" may be indicated soon after replacing TCM or transaxle assembly (after erasing the memory at the pattern B). Restart the self-diagnosis after erasing the self-diagnosis result. Check that no error is detected. |
| TCM | CVT assembly | Service pattern |
|---|---|---|
| Replace the new unit. | Do not replace the unit. | " PATTERN A " |
| Do not replace the unit. | Replace the new or old unit. | " PATTERN B " |
| Replace the old unit. | Do not replace the unit. | |
| Replace the new or old unit. | ||
| Replace the new unit. | Replace the new or old unit. | " PATTERN C " |
TCM SERVICE PATTERN CHART
Note. Old unit means that the unit has been already used for another vehicle.
DISASSEMBLY
Note. Refer to " CONTROL DEVICE COMPONENTS " to disassemble.
Scheme 52
Scheme 53
- Remove selector lever knob from control device assembly. Refer to " «SELECTOR LEVER KNOB REMOVAL AND INSTALLATION»(ref-337628-S18831652492009080600000) ".
- Remove position lamp from position indicator plate (1).
- Insert a flat-bladed screwdriver to (A) (at 4 locations) as shown, and bend each hook slightly to raise position indicator plate (1) and remove from control device assembly (2).
- Remove bracket from control device assembly (2).
- Remove CVT device harness connector from control device assembly (2).
- Release tabs (A) on shift lock solenoid and park position switch assembly from hooks (B) on control device assembly to shift lock solenoid and park position switch assembly.
ASSEMBLY
Assembly is in the reverse order of disassembly.
