Security Control System: Removal & Installation Nissan Titan I рестайлинг

Removal

1. Remove the lower instrument panel RH. Refer to " «REMOVAL AND INSTALLATION»(ref-396292-S39118079492011050400000) ".
2. Remove the side ventilator assembly RH. Refer to " «EXPLODED VIEW»(ref-396292-S29032199542011050400000) ".
3. Disconnect the wire harness (1), remove the bolt (A), and the RKE receiver (2).

Scheme 23

Installation

Installation is in the reverse order of removal.

1. Disconnect the battery negative terminal.
2. Remove the lower instrument panel LH. Refer to " «EXPLODED VIEW»(ref-396292-S29032199542011050400000) ".
3. Remove the steering column covers.
4. Remove the knee bolster.
5. Lower the steering column assembly.
6. Remove cluster lid A.
7. Remove the bolt (A), disconnect the electrical connector (1), and remove the NATS antenna amp (2).

Scheme 24

Installation is in the reverse order of removal.
