DETAILED FLOW

1. GET INFORMATION FOR SYMPTOM Get the detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurred). GO TO 2.
2. CHECK DTC Check BCM for DTCs. Perform the following procedure if DTC is displayed. Erase DTC. Study the relationship between the cause detected by DTC and the symptom described by the customer. Check related service bulletins for information. Is any symptom described and any DTC detected? Symptom is described, DTC is displayed: GO TO 3. Symptom is described, DTC is not displayed: GO TO 4 . Symptom is not described, DTC is displayed: GO TO 5 .
3. CONFIRM THE SYMPTOM Confirm the symptom described by the customer. Connect CONSULT-III to the vehicle in "DATA MONITOR" mode and check real-time diagnosis results. Verify relation between the symptom and the condition when the symptom is detected. GO TO 5 .
4. CONFIRM THE SYMPTOM Confirm the symptom described by the customer. Connect CONSULT-III to the vehicle in "DATA MONITOR" mode and check real-time diagnosis results. Verify relation between the symptom and the condition when the symptom is detected. GO TO 6 .
5. PERFORM DTC CONFIRMATION PROCEDURE Perform DTC Confirmation Procedure for the displayed DTC, and then check that DTC is detected again. If two or more DTCs are detected, refer to " «DTC INSPECTION PRIORITY CHART»(ref-396327-S41360212262011050400000) " (BCM) and determine trouble diagnosis order. Is DTC detected? YES: GO TO 8 . NO: Refer to " «INTERMITTENT INCIDENT»(ref-396282-S12471740572011050400000) ".
6. PERFORM BASIC INSPECTION Perform Basic Inspection. Refer to " «BASIC INSPECTION»(ref-396327-S40102766952011050400000) ". GO TO 7.
7. DETECT MALFUNCTIONING SYSTEM BY SYMPTOM TABLE Detect malfunctioning system according to Symptom Table based on the confirmed symptom in step 4. GO TO 8.
8. DETECT MALFUNCTIONING PART BY DIAGNOSTIC PROCEDURE Inspect according to Diagnostic Procedure of the system. NOTE: The Diagnostic Procedure is described based on open circuit inspection. A short circuit inspection is also required for the circuit check in the Diagnostic Procedure. GO TO 9.
9. REPAIR OR REPLACE THE MALFUNCTIONING PART Repair or replace the malfunctioning part. Reconnect parts or connectors disconnected during Diagnostic Procedure again after repair and replacement. Check DTC. If DTC is displayed, erase it. GO TO 10.
10. FINAL CHECK When DTC was detected in step 9, perform DTC Confirmation Procedure or Component Function Check again, and then check that the malfunctions have been fully repaired. When symptom was described by the customer, refer to the confirmed symptom in step 3 or 4 , and check that the symptom is not detected. Does the symptom reappear? YES (DTC is detected): GO TO 8 . YES (Symptom remains): GO TO 6 . NO: Inspection End.

ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Requirement

Refer to CONSULT-III Operation Manual.

ECM RE-COMMUNICATING FUNCTION : Special Repair Requirement

1. PERFORM ECM RE-COMMUNICATING FUNCTION Install ECM. Using a registered key (*2), turn ignition switch to "ON". *2: To perform this step, use the key that has been used before performing ECM replacement. Maintain ignition switch in "ON" position for at least 5 seconds. Turn ignition switch to "OFF". Start engine. Can engine be started? YES: Procedure is completed. NO: Initialize control unit. Refer to CONSULT-III Operation Manual.

Scheme 26

INPUT/OUTPUT SIGNAL CHART

BCM

INPUT/OUTPUT SIGNAL CHART

PRECAUTIONS FOR KEY REGISTRATION

1. The key registration is a procedure that erases the current NATS ID once, and then re-registers a new ID. Therefore the registered key is necessary for this procedure. Before starting the registration operation collect all registered Keys from the customer.
2. The NATS ID registration is the procedure that registers the ID stored into the transponder (integrated in mechanical key) to BCM. The key ID registration is the procedure that registers the ID to the BCM.
3. When performing the key system registration only, the engine cannot be started by inserting the key into the key cylinder. When performing the NATS registration only, the engine cannot be started by using the ignition key.

SECURITY INDICATOR

1. Always flashes with ignition key in the OFF position.

Disarmed Phase

When the vehicle is being driven or when doors are open, the theft warning system is set in the disarmed phase on the assumption that the owner is inside or near the vehicle.

Pre-Armed Phase And Armed Phase

The vehicle security system turns into the pre-armed phase when ignition switch is in OFF position, all doors are closed and locked (using keyfob, door lock/unlock switch, driver key cylinder or auto relock function). The system automatically shifts into the armed phase.

Condition of Activating The System

When the following condition is performed in armed phase, the system sounds the horns and flashes the headlamps for about 50 seconds.

1. Any door is opened.

Condition of Deactivating The System

When one of the following operations is performed, the armed phase is canceled.

1. Unlock the doors with keyfob.
2. Use the mechanical key to unlock the driver door using the door key cylinder.

Scheme 27

DATA MONITOR

MONITOR ITEM REFERENCE

WORK SUPPORT

TEST ITEM REFERENCE

MONITOR ITEM REFERENCE

Special Repair Requirement

1. REQUIRED WORK WHEN REPLACING BCM Initialize BCM. Refer to CONSULT-III Operation Manual. Inspection End.

KING CAB : Component Function Check

1. CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL Check "KEY CYL LK-SW" AND "KEY CYL UN-SW" in DATA MONITOR mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. MONITOR ITEM REFERENCE Monitor item Condition KEY CYL LK-SW Lock : ON Neutral/Unlock : OFF KEY CYL UN-SW Unlock : ON Neutral/Lock : OFF Is the inspection result normal? YES: Key cylinder switch is OK. NO: Refer to " «KING CAB : DIAGNOSIS PROCEDURE»(ref-396327-S20456780672011050400000) ".

CREW CAB : Component Function Check

1. CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL Check "KEY CYL LK-SW" AND "KEY CYL UN-SW" in DATA MONITOR mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. MONITOR ITEM REFERENCE Monitor item Condition KEY CYL LK-SW Lock ON Neutral/Unlock OFF KEY CYL UN-SW Unlock ON Neutral/Lock OFF Is the inspection result normal? YES: Key cylinder switch is OK. NO: Refer to " «CREW CAB : DIAGNOSIS PROCEDURE»(ref-396327-S06850365582011050400000) ".

Component Function Check

1. CHECK FUNCTION Select "VEHICLE SECURITY HORN" in "ACTIVE TEST" mode with CONSULT-III. Check the horn (high/low) operation. TEST ITEM REFERENCE Test item Description HORN ON Horn relay ON (for 20 ms) Is the operation normal? YES: Inspection End. NO: Go to " «DIAGNOSIS PROCEDURE»(ref-396327-S29503561322011050400000) ".

1. CHECK FUNCTION Perform "THEFT IND" in the "Active Test" mode with CONSULT-III. Check vehicle security indicator operation. TEST ITEM DESCRIPTION Test item Description THEFT IND ON Vehicle security indicator ON OFF OFF Is the inspection result normal? YES: Inspection End. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-396327-S27958755602011050400000) ".

Physical Values

CONNECTOR TERMINALS REFERENCE Terminal Wire color Signal name Signal input/output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition 1 BR/W Ignition keyhole illumination Output OFF Door is locked (SW OFF) Battery voltage Door is unlocked (SW OFF) 0V 2 SB Combination switch input 5 Input ON Lighting, turn, wiper OFF Wiper dial position 4 3 G/Y Combination switch input 4 Input ON Lighting, turn, wiper OFF Wiper dial position 4 4 Y Combination switch input 3 Input ON Lighting, turn, wiper OFF Wiper dial position 4 5 G/B Combination switch input 2 Input ON Lighting, turn, wiper OFF Wiper dial position 4 6 V Combination switch input 1 9 Y/B Rear window defogger switch (Crew Cab) Input ON Rear window defogger switch ON 0V Rear window defogger switch OFF 5V 11 O Ignition switch (ACC or ON) Input ACC or ON Ignition switch ACC or ON Battery voltage 12 R/L Front door switch RH (All) Input OFF ON (open) 0V Rear door switch lower RH (King Cab) Rear door switch upper RH (King Cab) OFF (closed) Battery voltage 13 GR Rear door switch RH (Crew Cab) Input OFF ON (open) 0V OFF (closed) Battery voltage 15 L/W Tire pressure warning check connector Input OFF - 5V 18 P Remote keyless entry receiver and optical sensor (ground) Output OFF - 0V 19 V/W Remote keyless entry receiver (power supply) Output OFF Ignition switch OFF 20 G/W Remote keyless entry receiver (signal) Input OFF Stand-by (keyfob buttons released) When remote keyless entry receiver receives signal from keyfob (keyfob buttons pressed) 21 G NATS antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move for Approx. 1 second, then return to battery voltage. 22 G BUS - - Ignition switch ON or power window timer operates 23 G/O Security indicator lamp Output OFF Goes OFF --> illuminates (Every 2.4 seconds) Battery voltage --> 0V 25 BR NATS antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move for Approx. 1 second, then return to battery voltage. 27 W/R Compressor ON signal Input ON A/C switch OFF 5V A/C switch ON 0V 28 L/R Front blower monitor Input ON Front blower motor OFF Battery voltage Front blower motor ON 0V 29 W/B Hazard switch Input OFF ON 0V OFF 5V 31 P/L Cargo lamp switch Input OFF Cargo lamp switch ON 0 Cargo lamp switch OFF Battery voltage 32 R/G Combination switch output 5 Output ON Lighting, turn, wiper OFF Wiper dial position 4 33 R/Y Combination switch output 4 Output ON Lighting, turn, wiper OFF Wiper dial position 4 34 L Combination switch output 3 Output ON Lighting, turn, wiper OFF Wiper dial position 4 35 O/B Combination switch output 2 Output ON Lighting, turn, wiper OFF Wiper dial position 4 36 R/W Combination switch output 1 37 B/R Key switch and key lock solenoid Input OFF Key inserted Battery voltage Key inserted 0V 38 W/L Ignition switch (ON) Input ON - Battery voltage 39 L CAN-H - - - - 40 P CAN-L - - - - 47 SB Front door switch LH (All) Input OFF ON (open) 0V Rear door switch lower LH (King Cab) Rear door switch upper LH (King Cab) OFF (closed) Battery voltage 48 R/Y Rear door switch LH (Crew Cab) Input OFF ON (open) 0V OFF (closed) Battery voltage 50 R/Y Cargo bed lamp control Output OFF Cargo lamp switch (ON) 0V Cargo lamp switch (OFF) Battery voltage 51 G/Y Trailer turn signal (right) Output ON Turn right ON 52 G/B Trailer turn signal (left) Output ON Turn left ON 56 R/G Battery saver output Output OFF 30 minutes after ignition switch is turned OFF 0V ON - Battery voltage 57 Y/R Battery power supply Input OFF - Battery voltage 58 W/R Optical sensor Input ON When optical sensor is illuminated 3.1V or more When optical sensor is not illuminated 0.6V or less 59 G Front door lock assembly LH actuator (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 60 G/B Turn signal (left) Output ON Turn left ON 61 G/Y Turn signal (right) Output ON Turn right ON 62 R/W Step lamp LH and RH Output OFF ON (any door open) 0V OFF (all doors closed) Battery voltage 63 L Interior room/map lamp Output OFF Any door switch ON (open) 0V OFF (closed) Battery voltage 65 V All door lock actuators (lock) Output OFF OFF (neutral) 0V ON (lock) Battery voltage 66 G/Y Front door lock actuator RH and rear door lock actuators LH/RH (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 67 B Ground Input ON - 0V 68 W/L Power window power supply (RAP) Output - Ignition switch ON Battery voltage Within 45 seconds after ignition switch OFF Battery voltage More than 45 seconds after ignition switch OFF 0V When front door LH or RH is open or power window timer operates 0V 69 W/R Power window power supply Output - - Battery voltage 70 W/B Battery power supply Input OFF - Battery voltage

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Fail-safe index

BCM performs fail-safe control when any DTC listed below is detected.

FAIL SAFE CHART

CONNECTOR TERMINALS REFERENCE Terminal Wire color Signal name Signal input/output Measuring condition Reference value (Approx.) Ignition switch Operation or condition 1 B/Y Battery power supply Input OFF - Battery voltage 2 R Battery power supply Input OFF - Battery voltage 3 BR ECM relay Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 4 W/L ECM relay Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 6 L Throttle control motor relay Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 7 W/B ECM relay control Input - Ignition switch ON or START 0V Ignition switch OFF or ACC Battery voltage 8 R/B Fuse 54 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 10 G Fuse 45 (Canada only) Output ON Daytime light system active 0V Daytime light system inactive Battery voltage 11 Y/B A/C compressor Output ON or START A/C switch ON or defrost A/C switch Battery voltage A/C switch OFF or defrost A/C switch 0V 12 L/W Ignition switch supplied power Input - OFF or ACC 0V ON or START Battery voltage 13 B/Y Fuel pump relay Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 14 Y/R Fuse 49 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 15 LG/B Fuse 50 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 16 G Fuse 51 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 17 W Fuse 55 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 19 W/R Starter motor Output START - Battery voltage 21 BR Ignition switch supplied power Input - OFF or ACC 0V START Battery voltage 22 G Battery power supply Output OFF - Battery voltage 23 GR/W Door mirror defogger output signal (if equipped) Output - When rear defogger switch is ON Battery voltage When rear defogger switch is OFF 0V 27 W/B Fuse 38 (With trailer tow) Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 30 W Fuse 53 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 32 L Wiper low speed signal Output ON or START Wiper switch OFF Battery voltage LO or INT 0V 35 L/B Wiper high speed signal Output ON or START Wiper switch OFF, LO, INT Battery voltage HI 0V 37 Y Power generation command signal Output - Ignition switch ON 6.3 V 40% is set on "Active test," "ALTERNATOR DUTY" of "ENGINE" 3.8 V 40% is set on "Active test," "ALTERNATOR DUTY" of "ENGINE" 1.4 V 38 B Ground Input - - 0V 39 L CAN-H - ON - - 40 P CAN-L - ON - - 42 GR Oil pressure switch Input - Engine running Battery voltage Engine stopped 0V 43 L/Y Wiper auto stop signal Input ON or START Wiper switch OFF, LO, INT Battery voltage 44 BR Daytime light relay control (Canada only) Input ON Daytime light system active 0V Daytime light system inactive Battery voltage 45 G/W Horn relay control Input ON When door locks are operated using keyfob (OFF --> ON) () Battery voltage --> 0V 46 GR Fuel pump relay control Input - Ignition switch ON or START 0V Ignition switch OFF or ACC Battery voltage 47 O Throttle control motor relay control Input - Ignition switch ON or START 0V Ignition switch OFF or ACC Battery voltage 48 B/R Starter relay (inhibit switch) Input ON or START Selector lever in "P" or "N" 0V Selector lever any other position Battery voltage 49 R/L Trailer tow relay (With trailer tow) Illumination (Without trailer tow) Output ON Lighting switch must be in the 1st position OFF 0V ON Battery voltage 50 W/R Front fog lamp (LH) (if equipped) Output ON or START Lighting switch must be in the 2nd position (LOW beam is ON) and the front fog lamp switch OFF 0V ON Battery voltage 51 W/R Front fog lamp (RH) (if equipped) Output ON or START Lighting switch must be in the 2nd position (LOW beam is ON) and the front fog lamp switch OFF 0V ON Battery voltage 52 L LH low beam headlamp Output - Lighting switch in 2nd position Battery voltage 54 R/Y RH low beam headlamp Output - Lighting switch in 2nd position Battery voltage 55 G LH high beam headlamp Output - Lighting switch in 2nd position and placed in HIGH or PASS position Battery voltage 56 Y (With DTRL) L/W (Without DTRL) RH high beam headlamp Output - Lighting switch in 2nd position and placed in HIGH or PASS position Battery voltage 57 R/L Parking, license, tail lamp and rear audio remote control unit Output ON Lighting switch 1st position OFF 0V ON Battery voltage 59 B Ground Input - - 0V 60 B/W Rear window defogger relay (if equipped) Output ON or START Rear defogger switch ON Battery voltage Rear defogger switch OFF 0V 61 BR Fuse 32 (With trailer tow) Output OFF - Battery voltage (1) When horn reminder is ON

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53
