Power Window System: Overview Nissan Titan I

Windows 23 illustrations ~371 words

Scheme 1

Scheme 1: Component Parts and Harness Connector Location

MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OPERATION

Signal is sent

  1. through main power window and door lock/unlock switch terminal 12
  2. to power window and door lock/unlock switch RH terminal 16.

The operation of power window after receiving the signal is the same as operating the power window with power window and door lock/unlock switch RH.

Signal is sent

  1. through main power window and door lock/unlock switch terminal 14
  2. to power window and door lock/unlock switch RH terminal 16.

The operation of power window after receiving the signal is the same as operating the power window with power window and door lock/unlock switch RH.

AUTO OPERATION

The power window AUTO feature enables the driver to open or close the window without holding the window switch in the down or up position.

RETAINED POWER OPERATION

When the ignition switch is turned to the OFF position from ON or START position.

Power is supplied for 45 seconds

  1. to main power window and door lock/unlock switch terminal 10
  2. from BCM terminal 68.

When power and ground are supplied, the BCM continues to be energized, and the power window can be operated.

The retained power operation is canceled when the front LH or front RH door is opened.

RAP signal period can be changed by CONSULT-II. Refer to , " CONSULT-II INSPECTION PROCEDURE ".

CAN Communication System Description

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only. Refer to CAN COMMUNICATION

Scheme 2

Scheme 2: Schematic (King Cab)

Scheme 3

Scheme 3: Wiring Diagram - WINDOW - (King Cab)

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8: Terminal and Reference Value for Main Power Window and Door Lock/Unlock Switch/King Cab

Scheme 9

Scheme 9: Terminal and Reference Value for Power Window and Door Lock/Unlock Switch RH/King Cab

Scheme 10

Scheme 10

Scheme 11

Scheme 11: Terminal and Reference Value for BCM/King Cab

Scheme 12

Scheme 12: Schematic (Crew Cab)

Scheme 13

Scheme 13: Wiring Diagram - WINDOW - (Crew Cab)

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20: Terminal and Reference Value for Main Power Window and Door Lock/Unlock Switch/Crew Cab

Scheme 21

Scheme 21

Scheme 22

Scheme 22: Terminal and Reference Value for Power Window and Door Lock/Unlock Switch RH/Crew Cab

Scheme 23

Scheme 23: Terminal and Reference Value for BCM/Crew Cab
