Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
- Check if the reservoir tank engine coolant level within MIN to MAX When engine is cool.
- Adjust engine coolant if too much or too little.
Checking Cooling System For Leaks
| WARNING | Never remove the radiator or reservoir cap when the engine is hot. Serious burns could occur from high-pressure engine coolant escaping from the radiator or reservoir. |
Scheme 24
- To check for leakage, Using suitable tool apply pressure to the cooling system and reservoir cap. Testing pressure: 137 kPa (1.4 kg/cm, 20 psi) CAUTION: Higher pressure than specified may cause radiator damage. NOTE: In case that engine coolant decreases, replenish cooling system with engine coolant.
- If anything is found, repair or replace damaged parts.
Scheme 25
| WARNING | Never remove the radiator cap when the engine is hot. Serious burns could occur from high-pressure engine coolant escaping from the radiator. |
CHECKING RADIATOR
Check radiator for mud or clogging. If necessary, clean radiator as follows.
| CAUTION | Be careful not to bend or damage the radiator fins. When radiator is cleaned without removal, remove all surrounding parts such as cooling fan, radiator shroud and horns. Then tape the harness and electrical connectors to prevent water from entering. |
- Apply water by hose to the back side of the radiator core vertically downward.
- Apply water again to all radiator core surface once per minute.
- Stop washing when stains no longer flow out from the radiator.
- Blow air into the back side of radiator core vertically downward. Use compressed air lower than 490 kPa (5 kg/cm 2 , 71 psi) and keep distance more than 30 cm (11.8 in).
- Blow air again into all the radiator core surfaces once per minute until no water sprays out.
Scheme 26
Fan Coupling
Inspect fan coupling for oil leakage and bimetal conditions.
Scheme 27
Scheme 28
- Visually check that there is no significant looseness in the fan bracket shaft, and that it turns smoothly by hand.
- If there are any unusual concerns, replace the water pump assembly.
