CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment.
Note. This chart is used if CONSULT-III does not automatically recognize CAN system type. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 1
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 2
CAN System Specification Chart
Determine CAN system type from the following specification chart.
Note. Refer to " CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART) " for how to use CAN system specification chart.
| Body type | Sedan | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Axle | 2WD | ||||||||||||
| Engine | MR20DE | QR25DE | |||||||||||
| Transmission | M/T | CVT | M/T | CVT | |||||||||
| Brake control | ABS | ABS | |||||||||||
| Mid/premium audio system | X | X | X | X | X | X | X | X | X | ||||
| Intelligent Key system | X | X | X | ||||||||||
| Double meter | X | X | X | ||||||||||
| CAN system type | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 12 | 15 | 16 |
| CAN communication signal chart | " TYPE 1/TYPE 2/TYPE 3/TYPE 4 " | " TYPE 5/TYPE 6/TYPE 7/TYPE 8/TYPE 9/TYPE 10 " | " TYPE 1/TYPE 2/TYPE 3/TYPE 4 " | ||||||||||
| X: Applicable | |||||||||||||
CAN SYSTEM SPECIFICATION CHART
