DESCRIPTION
"Diag on CAN" is a diagnosis using CAN communication instead of previous DDL1 and DDL2 communication lines, between control units and diagnosis unit.
Scheme 3
| Name | Harness | Description |
|---|---|---|
| DDL1 | Tx Rx | It is used for trouble diagnosis. (CAN-H and CAN-L are used for controlling) |
| DDL2 | K-LINE | It is used for trouble diagnosis. (CAN-H and CAN-L are used for controlling) |
| Diag on CAN | CAN-H CAN-L | It is used for trouble diagnosis and control. |
HARNESS DESCRIPTION
Abbreviation List
Unit name abbreviations in CONSULT-III CAN diagnosis and in this service information are as per the following list.
| Abbreviation | Unit name |
|---|---|
| A-BAG | Air bag diagnosis sensor unit |
| ABS | ABS actuator and electric unit (control unit) |
| AV | Audio unit |
| BCM | BCM |
| DLC | Data link connector |
| ECM | ECM |
| EPS | EPS control unit |
| I-KEY | Intelligent Key unit |
| IPDM-E | IPDM E/R |
| M&A | Combination meter |
| M&A2 | Double meter |
| TCM | TCM |
ABBREVIATION LIST
VEHICLE EQUIPMENT IDENTIFICATION INFORMATION
Note. Check CAN system type from the vehicle shape and equipment.
