Engine Cooling System: Maintenance Nissan Rogue II

Draining

Scheme 12

Scheme 13

1. Open radiator drain plug at the bottom of radiator, and then remove radiator cap. CAUTION: Do not allow engine coolant to contact the drive belt. Perform this step when the engine is cold.
2. Follow this step for heater core removal/replacement only. Disconnect the upper heater hose at the engine side and apply moderate air pressure [103.46 kPa (1.055 kg/cm 2 , 15 psi) maximum air pressure] into the hose for 30 seconds to blow the excess engine coolant out of the heater core.
3. When draining all of the engine coolant in the system, remove the reservoir tank and drain the engine coolant, then clean the reservoir tank before installation. CAUTION: Do not allow the engine coolant to contact the drive belt. Perform this step when engine is cold.
4. When draining all of the engine coolant in the system for engine removal or repair, remove the engine coolant drain plugs (A/B) from the cylinder block.
5. Check the drained engine coolant for contaminants such as rust, corrosion or discoloration. If the engine coolant is contaminated, flush the engine cooling system. Refer to " «FLUSHING»(ref-616716-S31329121452014051900000) ".

Refilling

Scheme 14

Scheme 15

1. Install the radiator drain plug. Install the reservoir tank and cylinder block drain plug, if removed for a total system drain or for engine removal or repair. The radiator must be completely empty of coolant and water. Apply sealant to the threads of the cylinder block drain plug. Use recommended coolant or equivalent. Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-616719-S31709126332014051900000) ". Radiator drain plug: Refer to " «EXPLODED VIEW»(ref-616716-S40161393792014051900000) ". Cylinder block drain plug (A): 53.9 Nm (5.5 kg-m, 40 ft-lb) Cylinder block drain plug (B): 9.8 N.m (1.0 kg-m, 87 in-lb)
2. If disconnected, reattach the upper radiator hose at the engine side.
3. Set the vehicle heater controls to the full HOT and heater ON position. Turn the vehicle ignition ON with the engine OFF as necessary to activate the heater mode.
4. Install the Tool by installing the radiator cap adapter onto the radiator neck opening. Then attach the gauge body assembly with the refill tube and the venturi assembly to the radiator cap adapter. Tool number: KV991J0070 (J-45695)
5. Insert the refill hose into the coolant mixture container that is placed at floor level. Make sure the ball valve is in the closed position. Use recommended coolant or equivalent. Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-616719-S31709126332014051900000) ". Engine coolant capacity (with reservoir tank): Refer to " «PERIODICAL MAINTENANCE SPECIFICATION»(ref-616716-S38675679252014051900000) ". CAUTION: Do not use any cooling system additives such as radiator sealer. Additives may clog the cooling system and cause damage to the engine, transmission and/or cooling system.
6. Install an air hose to the venturi assembly, the air pressure must be within specification. Compressed air supply pressure: 549 - 824 kPa (5.6 - 8.4 kg/cm 2 , 80 - 119 psi) CAUTION: The compressed air supply must be equipped with an air dryer.
7. The vacuum gauge will begin to rise and there will be an audible hissing noise. During this process open the ball valve on the refill hose slightly. Coolant will be visible rising in the refill hose. Once the refill hose is full of coolant, close the ball valve. This will purge any air trapped in the refill hose.
8. Continue to draw the vacuum until the gauge reaches 28 inches of vacuum. The gauge may not reach 28 inches in high altitude locations, use the vacuum specifications based on the altitude above sea level. Altitude above sea level Vacuum gauge reading 0 - 100 m (328 ft): 28 inches of vacuum 300 m (984 ft): 27 inches of vacuum 500 m (1, 641 ft): 26 inches of vacuum 1, 000 m (3, 281 ft): 24 - 25 inches of vacuum
9. When the vacuum gauge has reached the specified amount, disconnect the air hose and wait 20 seconds to see if the system loses any vacuum. If the vacuum level drops, perform any necessary repairs to the system and repeat steps 6 - 8 to bring the vacuum to the specified amount. Recheck for any leaks.
10. Place the coolant container (with the refill hose inserted) at the same level as the top of the radiator. Then open the ball valve on the refill hose so the coolant will be drawn up to fill the cooling system. The cooling system is full when the vacuum gauge reads zero. CAUTION: Do not allow the coolant container to get too low when filling, to avoid air from being drawn into the cooling system.
11. Remove the Tool from the radiator neck opening.
12. Fill the cooling system reservoir tank to the specified level and install the radiator cap. Run the engine to warm up the cooling system and top up the system as necessary.

Flushing

1. Install reservoir tank, if removed, and radiator drain plug. CAUTION: Be sure to clean drain plug. Do not reuse O-ring. Radiator drain plug: Refer to " «EXPLODED VIEW»(ref-616716-S40161393792014051900000) ". If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «EXPLODED VIEW»(ref-616715-S37969382852014051900000) ".
2. Run the engine and warm it up to normal operating temperature.
3. Rev the engine two or three times under no-load.
4. Stop the engine and wait until it cools down.
5. Drain water from the system. Refer to " «DRAINING»(ref-616716-S22959837822014051900000) ".
6. Repeat steps 1 through 5 until clear water begins to drain from radiator.

Scheme 16

Scheme 17

1. Inspect the radiator cap. Replace the cap if the metal plunger cannot be seen around the edge of the black rubber gasket. Replace the cap if deposits of waxy residue or other foreign material are on the black rubber gasket or the metal retainer. NOTE: Thoroughly wipe out the radiator filler neck to remove any waxy residue or foreign material.
2. Pull the negative-pressure valve to open it and check that it closes completely when released. Check that there is no dirt or damage on the valve seat of the radiator cap negative-pressure valve. Check that there are no abnormalities in the opening and closing conditions of the negative-pressure valve.
3. Check radiator cap relief pressure using suitable tool (A/B). Standard: Refer to " «RADIATOR»(ref-616716-S36725234022014051900000) ". Apply water or engine coolant to the cap seal surface before connecting the radiator cap to the tester. Replace the radiator cap if there is an abnormality in the negative-pressure valve, or if the open-valve pressure is outside of the standard values.
