Ventilation System: Removal & Installation Nissan Rogue II

Automatic HVAC System 19 illustrations ~611 words

INSTALLATION

Installation is in the reverse order of removal.

CAUTIONWhen installing, handle the filter with extreme care to avoid deforming or damaging the filter.

Installation is in the reverse order of removal.

Scheme 101

Scheme 101: REMOVAL
Scheme 101: REMOVAL
  1. Remove the instrument panel assembly. Refer to " «INSTRUMENT PANEL ASSEMBLY: REMOVAL AND INSTALLATION»(ref-616753-S34962989632014051900000) ".
  2. Remove the screws (A) and the side defroster duct (1). NOTE: LH side shown below; RH similar.

Installation is in the reverse order of removal.

Scheme 102

Scheme 102: REMOVAL
Scheme 102: REMOVAL
  1. Remove instrument panel assembly. Refer to " «INSTRUMENT PANEL ASSEMBLY: REMOVAL AND INSTALLATION»(ref-616753-S34962989632014051900000) ".
  2. Remove screws (A) and center ventilator duct (1).

Installation is in the reverse order of removal.

REMOVAL

Front foot duct (LH)

Scheme 103

Scheme 103: REMOVAL
Scheme 103: REMOVAL
  1. Remove instrument lower panel LH. Refer to " «REMOVAL AND INSTALLATION»(ref-616753-S27331657232014051900000) ".
  2. Remove front foot duct (LH) screws (A).
  3. Release the pawl and remove front foot duct (LH) (1).

Front foot duct (RH)

Scheme 104

Scheme 104
Scheme 104
  1. Remove glove box assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-616753-S23839766482014051900000) ".
  2. Remove front foot duct (RH) screws (A).
  3. Release the pawl and remove front foot duct (RH) (1).

Installation is in the reverse order of removal.

Scheme 105

Scheme 105: REMOVAL
Scheme 105: REMOVAL
  1. Remove the center console side finisher. Refer to " «EXPLODED VIEW»(ref-616753-S40890498532014051900000) ".
  2. Release the pawls and remove front floor connecting duct (1). NOTE: LH side shown below; RH similar.

Installation is in the reverse order of removal.

Scheme 106

Scheme 106: REMOVAL
Scheme 106: REMOVAL
  1. Partially remove front floor trim.
  2. Remove front floor duct screws.
  3. Release clips using a suitable tool and remove front foot duct (1). NOTE: RH side shown below; LH similar.

Installation is in the reverse order of removal.

  1. Remove inside key antenna (instrument center). Refer to " «INSTRUMENT CENTER: REMOVAL AND INSTALLATION»(ref-616728-S09060301692014051900000) ".
  2. Remove shift selector finisher. Refer to " «EXPLODED VIEW»(ref-616753-S40890498532014051900000) ".
  3. Remove the adaptor duct.

Installation is in the reverse order of removal.

Scheme 107

Scheme 107: REMOVAL
Scheme 107: REMOVAL
  1. Remove center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-616753-S21533936492014051900000) ".
  2. Remove screws (A) and rear center ventilator duct (1).

Installation is in the reverse order of removal.

Scheme 108

Scheme 108: Exploded View
Scheme 108: Exploded View
  1. Remove front pillar finishers (LH/RH). Refer to " «FRONT PILLAR FINISHER: REMOVAL AND INSTALLATION»(ref-616755-S05364433802014051900000) ".
  2. Release defroster grille clips using a suitable tool.
  3. Disconnect the harness connectors and remove defroster grille.

Installation is in the reverse order of removal.

Scheme 109

Scheme 109: REMOVAL
Scheme 109: REMOVAL

Scheme 110

Scheme 110
Scheme 110

Scheme 111

Scheme 111
Scheme 111
  1. Release the pawls using a suitable tool, disconnect the harness connector and remove center ventilator grille assembly from instrument panel.
  2. Disconnect the harness connector (A) from hazard switch (1).
  3. Release the pawls to remove the center ventilator grilles (LH/RH).

Installation is in the reverse order of removal.

Side ventilator grille (LH)

Scheme 112

Scheme 112: REMOVAL
Scheme 112: REMOVAL

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114
  1. Release the pawls using a suitable tool and remove instrument side finisher (LH) (1).
  2. Insert a suitable tool (A) at the top of the side ventilator grille (1) and release as shown below.
  3. Remove side ventilator grille (1) in the direction shown below (<==).

Side ventilator grille (RH)

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116
  1. Release the pawls using a suitable tool and remove instrument side finisher (1).
  2. Remove side ventilator grille (RH) screw (A).
  3. Insert a suitable tool (A) at the top of the side ventilator grille (1) and release as shown below.
  4. Remove side ventilator grille (1) in the direction shown below (<==).

Installation is in the reverse order of removal.

Scheme 117

Scheme 117: REMOVAL
Scheme 117: REMOVAL
  1. Remove center console rear finisher. Refer to " «EXPLODED VIEW»(ref-616753-S40890498532014051900000) ".
  2. Remove screws (A) and rear center ventilator grille (1).

Installation is in the reverse order of removal.

Scheme 118

Scheme 118: Exploded View
Scheme 118: Exploded View

Scheme 119

Scheme 119: REMOVAL
Scheme 119: REMOVAL
  1. Remove glove box assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-616753-S23839766482014051900000) ".
  2. Disconnect the harness connector from the blower motor.
  3. Remove blower motor screw (B).
  4. Release hook (A) then rotate the blower motor (1) counterclockwise and remove.

Installation is in the reverse order of removal.
