Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS article of this Service Information.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery and wait at least three minutes before performing any service. |
Procedure without Cowl Top Cover
When performing the procedure after removing cowl top cover, cover the lower end of windshield with urethane, etc. to prevent damage to the windshield.
Scheme 120
Precaution for Work
- When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
- When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
- Protect the removed parts with a shop cloth and prevent them from being dropped.
- Replace a deformed or damaged clip.
- If a part is specified as a non-reusable part, always replace it with a new one.
- Be sure to tighten bolts and nuts securely to the specified torque.
- After installation is complete, be sure to check that each part works properly.
- Follow the steps below to clean components: Water soluble dirt
- Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
- Then rub with a soft, dry cloth. Oily dirt
- Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
- Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
- Then rub with a soft, dry cloth. Do not use organic solvent such as thinner, benzene, alcohol or gasoline. For genuine leather seats, use a genuine leather seat cleaner.
Special Service Tool
The actual shapes of tools may differ from those illustrated here.
Tool number (TechMate No.) Tool name Description - (J-46534) Trim Tool Set Removing trim components
Scheme 121
Commercial Service Tool
(TechMate No.) Tool name Description (-) Power Tool Loosening nuts, screws and bolts
Scheme 122
- Release the tab and remove the in-cabin microfilter cover (1) from under the RH side of the instrument panel. CAUTION: Use care when lifting up on the tab to avoid damaging it.
- Remove the in-cabin microfilter (2). CAUTION: If the filter is deformed/damaged when removing, replace it with a new one. A deformed or damaged filter may affect the dust collecting performance.
Automatic A/C
The ventilation system is controlled by the A/C switch assembly. For details of the automatic air conditioner system, refer to " SYSTEM DESCRIPTION ".
Manual A/C
The ventilation system is controlled by the front air control. For details of the manual air conditioner system, refer to " SYSTEM DESCRIPTION ".
Scheme 123
Scheme 124
| Discharge air flow | ||||||||
|---|---|---|---|---|---|---|---|---|
| Mode position | Condition | Air outlet/distribution | ||||||
| DEF (1) | VENT | FOOT | ||||||
| Side (2) | Center (3) | Front (4) | Center (5) | |||||
| Upper Vent: ON | Temperature control switch | 18°C (60°F) | X | X | ||||
| Other than 18°C (60°F) (1) | X | X | ||||||
| X | X | X | X | |||||
| X | X | |||||||
| X | X | X | ||||||
| X | ||||||||
| (2) | X | |||||||
| (1) Air flow is also supplied to front foot until passenger room temperature stabilizes when temperature setting is other than 18°C (60°F). At that time, air flowing is the same as 18°C (60°F) setting. (2) During automatic defogging control. | ||||||||
| (1) | Air flow is also supplied to front foot until passenger room temperature stabilizes when temperature setting is other than 18°C (60°F). At that time, air flowing is the same as 18°C (60°F) setting. |
| (2) | During automatic defogging control. |
Scheme 125
Scheme 126
- Remove side defroster ducts (LH/RH). Refer to " «SIDE DEFROSTER DUCT: REMOVAL AND INSTALLATION»(ref-616760-S26194936692014051900000) ".
- Remove screws (A) and defroster nozzle (1).
In-cabin Microfilter
| Replacement interval | Refer to " INTRODUCTION OF PERIODIC MAINTENANCE ". |
