REMOVAL

  1. Remove the glove box cover assembly. Refer to " «EXPLODED VIEW»(ref-405885-S19988295622011062300000) ".
  2. Disconnect AWD control unit harness connector.
  3. Remove AWD control unit (1) mounting bolts.
  4. Remove AWD control unit.

Scheme 3

Scheme 3

INSTALLATION

Install is the reverse order of removal.

Scheme 4

Scheme 4: Exploded View

Refer to " COMPONENTS " for symbols in the figure.

Scheme 5

Scheme 5: REMOVAL
  1. Remove the exhaust front tube. Refer to " «EXPLODED VIEW»(ref-405861-S15239320972011062300000) ".
  2. Remove the exhaust center tube. Refer to " «EXPLODED VIEW»(ref-405861-S15239320972011062300000) ".
  3. Separate the rear propeller shaft. Refer to " «EXPLODED VIEW»(ref-405869-S01756972202011062300000) ".
  4. Remove right side drive shaft and support bearing bracket. Refer to " «EXPLODED VIEW»(ref-405868-S23952762112011062300000) ".
  5. Remove the mounting bolts of transaxle assembly and transfer assembly. CAUTION: Never remove the mounting bolts (White arrows shown in illustration below) of adapter case.
  6. Remove transfer assembly from the vehicle.
CAUTIONNever damage ring gear shaft. Never damage air breather hose.

Note the following, and install in the reverse order of removal.

  1. Install mounting bolts according to the standard below when installing transfer assembly to the transaxle assembly. MOUNTING BOLTS REFERENCE CHART Bolt symbol A B Installation direction Transfer Transaxle Transaxle Transfer CAUTION: When installing transfer assembly to transaxle assembly, replace the side oil seal (transfer joint). Refer to " «AWD : EXPLODED VIEW»(ref-405866-S26287099632011062300000) ". Never damage side seal (the joint part of transfer) and dust cover of transaxle assembly.
  2. Check oil level and check for oil leakage after installation. Refer to " «INSPECTION»(ref-405886-S30431048442011062300000) ".

Scheme 6

Scheme 6

Scheme 7

Scheme 7: Exploded View

Refer to " COMPONENTS " for symbols not described above.

Scheme 8

Scheme 8: Disassembly

Scheme 9

Scheme 9
  1. Remove adapter case mounting bolts.
  2. Lightly tap adapter case with a plastic hammer to remove adapter case.
  3. Remove O-ring from adapter case.
  4. Remove adapter case oil seal with a screwdriver.
CAUTIONBe careful not to damage adapter case.

Scheme 10
