FOR NORTH AMERICA : Special Service Tool
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
SPECIAL SERVICE TOOL CHART Tool number (Kent-Moore No.) Tool name Description KV10115801 (J-38956) Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in)
FOR NORTH AMERICA : Commercial Service Tool
COMMERCIAL SERVICE TOOL CHART (Kent-Moore No.) Tool name Description (-) Power tool Loosening nuts and bolts (-) Radiator cap tester Checking radiator and radiator cap (-) Radiator cap tester adapter Adapting radiator cap tester to radiator cap and radiator filler neck 28 (1.10) dia. 31.4 (1.236) dia. 41.3 (1.626) dia. Unit: mm (in) (-) Spark plug wrench Removing and installing spark plug
Scheme 33
Scheme 34
FOR MEXICO : Special Service Tool
SPECIAL SERVICE TOOL CHART Tool number Tool name Description KV10115801 Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in)
FOR MEXICO : Commercial Service Tool
COMMERCIAL SERVICE TOOL CHART Tool name Description Power tool Loosening nuts and bolts Radiator cap tester Checking radiator and radiator cap Radiator cap tester adapter Adapting radiator cap tester to radiator cap and radiator filler neck 28 (1.10) dia. 31.4 (1.236) dia. 41.3 (1.626) dia. Unit: mm (in) Spark plug wrench Removing and installing spark plug
General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or have their NISSAN dealers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
| Item | Reference Information | |
|---|---|---|
| Tires | Check the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the pressure specified. Check carefully for damage, cuts or excessive wear. | SERVICE DATA AND SPECIFICATIONS (SDS) |
| Wheel nuts | When checking the tires, make sure no nuts are missing, and check for any loose nuts. Tighten if necessary. | |
| Tire rotation | Tires should be rotated every 12,000 km (7,500 miles). | TIRE ROTATION |
| Tire Pressure Monitoring System (TPMS) transmitter components | Replace the TPMS transmitter grommet seal, valve core and cap when the tires are replaced due to wear or age. | SYSTEM DESCRIPTION |
| Wheel alignment and balance | If the vehicle should pull to either side while driving on a straight and level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be needed. | WHEEL ALIGNMENT WHEEL ALIGNMENT BALANCING WHEELS (BONDING WEIGHT TYPE) |
| Windshield | Clean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary. | |
| Windshield wiper blades | Check for cracks or wear if they do not wipe properly. | |
| Doors and engine hood | Check that all doors and the engine hood operate smoothly as well as the back door. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently. | LOCKS, HINGES AND HOOD LATCH |
| Lamps | Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. Clean the headlamps on a regular basis. | |
VEHICLE MAINTENANCE CHART
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.
| Item | Reference Information | |
|---|---|---|
| Warning lamps and chimes | Make sure that all warning lamps and chimes are operating properly. | |
| Windshield wiper and washer | Check that the wipers and washer operate properly and that the wipers do not streak. | |
| Windshield defroster | Check that the air comes out of the defroster outlets properly and in sufficient quantity when operating the heater or air conditioner. | |
| Steering wheel | Check that it has the specified play. Check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in) | |
| Seats | Check seat position controls such as seat adjusters, seatback recliner, etc. to make sure they operate smoothly and that all latches lock securely in every position. Check that the head restrains move up and down smoothly and that the locks (if equipped) hold securely in all latched positions. Check that the latches lock securely for folding-down rear seatbacks. | |
| Seat belts | Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly and are installed securely. Check the belt webbing for cuts, fraying, wear or damage. | SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS |
| Accelerator pedal | Check the pedal for smooth operation and make sure the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal. | |
| Brakes | Check that the brake does not pull the vehicle to one side when applied. | |
| Brake pedal and booster | Check the pedal for smooth operation and make sure it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep the floor mats away from the pedal. | PERIODIC MAINTENANCE BRAKE BOOSTER |
| Parking brake | Check that the lever or the pedal has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied. | PERIODIC MAINTENANCE |
| CVT P (Park) position mechanism | On a fairly steep hill check that the vehicle is held securely with the selector lever in the P (Park) position without applying any brakes. | |
VEHICLE MAINTENANCE CHART
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
| Item | Reference Information | |
|---|---|---|
| Windshield washer fluid | Check that there is adequate fluid in the tank. | |
| Engine coolant level | Check the coolant level when the engine is cold. | ENGINE COOLANT PERIODIC MAINTENANCE |
| Radiator and hoses | Check the front of the radiator and clean off any dirt, insects, leaves, etc., that may have accumulated. Make sure the hoses have no cracks, deformation, deterioration or loose connections. | RADIATOR |
| Brake fluid level | Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the reservoir. | BRAKE FLUID LEVEL AND LEAKS |
| Battery | Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level. | BASIC INSPECTION |
| Engine drive belts | Make sure that no belt is frayed, worn, cracked or oily. | DRIVE BELTS |
| Engine oil level | Check the level on the oil level gauge after parking the vehicle on a level spot and turning off the engine. | PERIODIC MAINTENANCE |
| Exhaust system | Make sure there are no loose supports, cracks or holes. If the sound of the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble and correct it. | EXHAUST SYSTEM |
| Underbody | The underbody is frequently exposed to corrosive substances such as those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt can easily accumulate. | |
| Fluid leaks | Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or gasoline fumes are evident, check for the cause and correct it immediately. | |
VEHICLE MAINTENANCE CHART
General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform the checks and inspections themselves or they can have their NISSAN dealers do them.
The maintenance items listed here should be performed from time to time, unless otherwise specified.
| Item | Reference Information | |
|---|---|---|
| Tires | Check the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the pressure specified. Check carefully for damage, cuts or excessive wear. | SERVICE DATA AND SPECIFICATIONS (SDS) |
| Windshield wiper blades | Check for cracks or wear if not functioning correctly. | |
| Doors and engine hood | Check that all doors and the engine hood operate smoothly as well as the back door. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check for lubrication frequently. | LOCKS, HINGES AND HOOD LATCH |
| Tire rotation | Tires should be rotated every 10,000 km (6,000 miles) for 2WD models and every 5,000 km (3,000 miles) for 4WD models. | TIRE ROTATION |
MAINTENANCE REFERENCE CHART
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.
| Item | Reference Information | |
|---|---|---|
| Lamps | Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. | |
| Warning lamps and chimes | Make sure that all warning lamps and chimes are operating properly. | |
| Steering wheel | Check that it has the specified play. Check for changes in the steering conditions, such as excessive free play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in) | |
| Seat belts | Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly, and are installed securely. Check the belt webbing for cuts, fraying, wear or damage. | SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS |
MAINTENANCE REFERENCE CHART
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
| Item | Reference Information | |
|---|---|---|
| Windshield washer fluid | Check that there is adequate fluid in the tank. | |
| Engine coolant level | Check the coolant level when the engine is cold. | ENGINE COOLANT |
| Engine oil level | Check the level after parking the vehicle on a level ground and turning off the engine. | PERIODIC MAINTENANCE |
| Brake fluid level | Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the reservoir. | BRAKE FLUID LEVEL AND LEAKS |
| Battery | Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. | BASIC INSPECTION |
MAINTENANCE REFERENCE CHART
Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals.
| Schedule 1 | Follow Periodic Maintenance Schedule 1 if the driving habits frequently include one or more of the following driving conditions: Repeated short trips of less than 5 miles (8 km). Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing. Operating in hot weather in stop-and-go "rush hour" traffic. Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery use. Driving in dusty conditions. Driving on rough, muddy, or salt spread roads. Towing a trailer, using a camper or a car-top carrier. | Emission Control System Maintenance | EMISSION CONTROL SYSTEM MAINTENANCE |
|---|---|---|---|
| Chassis and Body Maintenance | CHASSIS AND BODY MAINTENANCE | ||
| Schedule 2 | Follow Periodic Maintenance Schedule 2 if none of driving conditions shown in Schedule 1 apply to the driving habits. | Emission Control System Maintenance | EMISSION CONTROL SYSTEM MAINTENANCE |
| Chassis and Body Maintenance | CHASSIS AND BODY MAINTENANCE |
PERIODIC MAINTENANCE REFERENCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference Information or - Content Title | ||||||||
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 3.75 (6) 3 | 7.50 (12) 6 | 11.25 (18) 9 | 15 (24) 12 | 18.75 (30) 15 | 22.5 (36) 18 | 26.25 (42) 21 | 30 (48) 24 | |
| Drive belts | (1) | DRIVE BELTS | ||||||||
| Air cleaner filter | (2) | [R] | AIR CLEANER FILTER | |||||||
| EVAP vapor lines | I (6) | EVAP VAPOR LINES | ||||||||
| Fuel lines | I (6) | FUEL LINES | ||||||||
| Fuel filter | (3) | |||||||||
| Engine coolant (6) | (4) | ENGINE COOLANT | ||||||||
| Engine oil | R | R | R | R | R | R | R | R | ENGINE OIL | |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent.) | R | R | R | R | R | R | R | R | OIL FILTER | |
| Spark plugs (Iridium-tipped type) | Replace every 105,000 miles (168,000 km). | SPARK PLUG | ||||||||
| Intake & exhaust valve clearance (6) | (5) | CAMSHAFT VALVE CLEARANCE | ||||||||
| (1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged (or if the auto belt tensioner reading reaches maximum limit). (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (4) First replacement interval is 105,000 miles (168,000 km) or 84 months. After first replacement, replace every 75,000 miles (120,000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. | ||||||||||
| (1) | After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged (or if the auto belt tensioner reading reaches maximum limit). |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM . |
| (4) | First replacement interval is 105,000 miles (168,000 km) or 84 months. After first replacement, replace every 75,000 miles (120,000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (5) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (6) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
EMISSION CONTROL SYSTEM MAINTENANCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference Information or - Content Title | ||||||||
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 33.75 (54) 27 | 37.5 (60) 30 | 41.25 (66) 33 | 45 (72) 36 | 48.75 (78) 39 | 52.5 (84) 42 | 56.25 (90) 45 | 60 (96) 48 | |
| Drive belts | (1) | I (6) | DRIVE BELTS | |||||||
| Air cleaner filter | (2) | [R] | AIR CLEANER FILTER | |||||||
| EVAP vapor lines | I (6) | EVAP VAPOR LINES | ||||||||
| Fuel lines | I (6) | FUEL LINES | ||||||||
| Fuel filter | (3) | |||||||||
| Engine coolant (6) | (4) | ENGINE COOLANT | ||||||||
| Engine oil | R | R | R | R | R | R | R | R | ENGINE OIL | |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent.) | R | R | R | R | R | R | R | R | OIL FILTER | |
| Spark plugs (Iridium-tipped type) | Replace every 105,000 miles (168,000 km). | SPARK PLUG | ||||||||
| Intake & exhaust valve clearance (6) | (5) | CAMSHAFT VALVE CLEARANCE | ||||||||
| (1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged (or if the auto belt tensioner reading reaches maximum limit). (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (4) First replacement interval is 105,000 miles (168,000 km) or 84 months. After first replacement, replace every 75,000 miles (120,000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. | ||||||||||
| (1) | After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged (or if the auto belt tensioner reading reaches maximum limit). |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM . |
| (4) | First replacement interval is 105,000 miles (168,000 km) or 84 months. After first replacement, replace every 75,000 miles (120,000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (5) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (6) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
MAINTENANCE OPERATION CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference Information or - Content Title | ||||||||
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 3.75 (6) 3 | 7.50 (12) 6 | 11.25 (18) 9 | 15 (24) 12 | 18.75 (30) 15 | 22.5 (36) 18 | 26.25 (42) 21 | 30 (48) 24 | |
| Brake lines & cables | I | I | BRAKE LINES AND CABLES | |||||||
| Brake fluid | R | R | BRAKE FLUID | |||||||
| Brake pads & rotors | I | I | I | I | DISC BRAKE | |||||
| CVT fluid | (1) | I | I | CVT FLUID CVT FLUID CONDITION | ||||||
| Transfer oil & differential gear oil | (2) | I | I | TRANSFER OIL REAR DIFFERENTIAL GEAR OIL | ||||||
| Steering gear & linkage, axle & suspension parts | I | I | I | I | STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS | |||||
| Tire rotation | (3) | TIRE ROTATION | ||||||||
| Propeller shaft (AWD models) & drive shaft boots | I | I | I | I | REAR PROPELLER SHAFT DRIVE SHAFT | |||||
| Exhaust system | I | I | I | I | EXHAUST SYSTEM | |||||
| In-cabin microfilter | R | R | PERIODIC MAINTENANCE | |||||||
| (1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to " CONSULT-III FUNCTION (TRANSMISSION) ".) And if CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this Information. | ||||||||||
| (1) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to " CONSULT-III FUNCTION (TRANSMISSION) ".) And if CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. |
| (2) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. |
| (3) | Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this Information. |
CHASSIS AND BODY MAINTENANCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference Information or - Content Title | ||||||||
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 33.75 (54) 27 | 37.5 (60) 30 | 41.25 (66) 33 | 45 (72) 36 | 48.75 (78) 39 | 52.5 (84) 42 | 56.25 (90) 45 | 60 (96) 48 | |
| Brake lines & cables | I | I | BRAKE LINES AND CABLES | |||||||
| Brake fluid | R | R | BRAKE FLUID | |||||||
| Brake pads & rotors | I | I | I | I | DISC BRAKE | |||||
| CVT fluid | (1) | I | I | CVT FLUID CVT FLUID CONDITION | ||||||
| Transfer oil & differential gear oil | (2) | I | I | TRANSFER OIL REAR DIFFERENTIAL GEAR OIL | ||||||
| Steering gear & linkage, axle & suspension parts | I | I | I | I | STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS | |||||
| Tire rotation | (3) | TIRE ROTATION | ||||||||
| Propeller shaft (AWD models) & drive shaft boots | I | I | I | I | REAR PROPELLER SHAFT DRIVE SHAFT | |||||
| Exhaust system | I | I | I | I | EXHAUST SYSTEM | |||||
| In-cabin microfilter | R | R | PERIODIC MAINTENANCE | |||||||
| NOTE: (1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to " CONSULT-III FUNCTION (TRANSMISSION) ".) And if CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this Information. | ||||||||||
| NOTE |
|---|
| (1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to " CONSULT-III FUNCTION (TRANSMISSION) ".) And if CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this Information. |
| (1) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to " CONSULT-III FUNCTION (TRANSMISSION) ".) And if CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. |
| (2) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. |
| (3) | Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this Information. |
MAINTENANCE OPERATION CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference Information or - Content Title | ||||||||
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 7.5 (12) 6 | 15 (24) 12 | 22.5 (36) 18 | 30 (48) 24 | 37.5 (60) 30 | 45 (72) 36 | 52.5 (84) 42 | 60 (96) 48 | |
| Drive belts | (1) | I (5) | DRIVE BELTS | |||||||
| Air cleaner filter | [R] | [R] | AIR CLEANER FILTER | |||||||
| EVAP vapor lines | I (5) | I (5) | EVAP VAPOR LINES | |||||||
| Fuel lines | I (5) | I (5) | FUEL LINES | |||||||
| Fuel filter | (2) | |||||||||
| Engine coolant (5) | (3) | ENGINE COOLANT | ||||||||
| Engine oil | R | R | R | R | R | R | R | R | ENGINE OIL | |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent.) | R | R | R | R | R | R | R | R | OIL FILTER | |
| Spark plugs (Iridium-tipped type) | Replace every 105,000 miles (168,000 km). | SPARK PLUG | ||||||||
| Intake & exhaust valve clearance (5) | (4) | CAMSHAFT VALVE CLEARANCE | ||||||||
| (1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches maximum limit. (2) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (3) First replacement interval is 105,000 miles (168,000 km) or 84 months. After first replacement, replace every 75,000 miles (120,000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (4) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (5) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. | ||||||||||
| (1) | After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches maximum limit. |
| (2) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM . |
| (3) | First replacement interval is 105,000 miles (168,000 km) or 84 months. After first replacement, replace every 75,000 miles (120,000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (4) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (5) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
EMISSION CONTROL SYSTEM MAINTENANCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference Information or - Content Title | ||||||||
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 7.5 (12) 6 | 15 (24) 12 | 22.5 (36) 18 | 30 (48) 24 | 37.5 (60) 30 | 45 (72) 36 | 52.5 (84) 42 | 60 (96) 48 | |
| Brake lines & cables | I | I | I | I | BRAKE LINES AND CABLES | |||||
| Brake fluid | R | R | BRAKE FLUID | |||||||
| Brake pads & rotors | I | I | I | I | DISC BRAKE | |||||
| CVT fluid | (1) | I | I | I | I | CVT FLUID CVT FLUID CONDITION | ||||
| Transfer oil & differential gear oil | I | I | I | I | TRANSFER OIL REAR DIFFERENTIAL GEAR OIL | |||||
| Steering gear & linkage, axle & suspension parts | I | I | STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS | |||||||
| Tire rotation | (2) | TIRE ROTATION | ||||||||
| Propeller shaft (AWD models) & drive shaft boots | I | I | I | I | REAR PROPELLER SHAFT DRIVE SHAFT | |||||
| Exhaust system | I | I | EXHAUST SYSTEM | |||||||
| In-cabin microfilter | R | R | R | R | PERIODIC MAINTENANCE | |||||
| (1) Using transmission fluid other than Genuine Nissan CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (2) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this Information. | ||||||||||
| (1) | Using transmission fluid other than Genuine Nissan CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. |
| (2) | Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this Information. |
MAINTENANCE OPERATION CHART
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric conditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent maintenance may be required.
Periodic maintenance beyond the last period shown on the tables requires similar maintenance.
| Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, E = Check and correct the engine coolant mixture ratio. | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference Information | ||||||||
| Perform at number of kilometers (miles) or months, whichever comes first. | Km x 1,000 (Miles x 1,000) Months | 10 (6) 6 | 20 (12) 12 | 30 (18) 18 | 40 (24) 24 | 50 (30) 30 | 60 (36) 36 | 70 (42) 42 | 80 (48) 48 | |
| Underhood and under vehicle | ||||||||||
| Intake & exhaust valve clearance | See (2) | CAMSHAFT VALVE CLEARANCE | ||||||||
| Drive belts | See (3) | I | I | DRIVE BELTS | ||||||
| Engine oil (Use recommended oil.) (1) | R | R | R | R | R | R | R | R | ENGINE OIL | |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent) (1) | R | R | R | R | R | R | R | R | OIL FILTER | |
| Engine coolant (Use Genuine NISSAN Engine Coolant or equivalent in its quality.) | See (4) | E | R | ENGINE COOLANT | ||||||
| Cooling system | I | I | ENGINE COOLANT ENGINE COOLANT : DRAINING ENGINE COOLANT : REFILLING | |||||||
| Fuel lines | I | I | FUEL LINES | |||||||
| Air cleaner filter (Viscous paper type) (1) | R | R | AIR CLEANER FILTER | |||||||
| Fuel filter (In-tank type) | See (5) | |||||||||
| Spark plugs (Iridium-tipped type) | Replace every 100,000 km (60,000 miles) | SPARK PLUG | ||||||||
| EVAP vapor lines (With carbon canister) | I | I | EVAP VAPOR LINES | |||||||
| (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) Periodic maintenance is not required. However, if valve noise increases, check valve clearance. (3) Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (4) Use Genuine NISSAN Engine Coolant or equivalent in its quality, in order to avoid possible aluminum corrosion within the engine cooling system caused by the use of non-genuine engine coolant. After first replacement, replace every 40,000 km (24,000 miles) or 24 months. (5) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . | ||||||||||
| (1) | Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". |
| (2) | Periodic maintenance is not required. However, if valve noise increases, check valve clearance. |
| (3) | Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. |
| (4) | Use Genuine NISSAN Engine Coolant or equivalent in its quality, in order to avoid possible aluminum corrosion within the engine cooling system caused by the use of non-genuine engine coolant. After first replacement, replace every 40,000 km (24,000 miles) or 24 months. |
| (5) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM . |
ENGINE AND EMISSION CONTROL MAINTENANCE CHART
| Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L = Lubricate. | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference Information | ||||||||
| Perform at number of kilometers (miles) or months, whichever comes first. | Km x 1,000 (Miles x 1,000) Months | 10 (6) 6 | 20 (12) 12 | 30 (18) 18 | 40 (24) 24 | 50 (30) 30 | 60 (36) 36 | 70 (42) 42 | 80 (48) 48 | |
| Underhood and under vehicle | ||||||||||
| Brake line & cables | I | I | I | I | BRAKE LINES AND CABLES | |||||
| Brake fluid (For level & leaks) | I | I | I | I | BRAKE FLUID LEVEL AND LEAKS | |||||
| Brake fluid (1) | R | R | BRAKE FLUID | |||||||
| CVT fluid (For level & leaks) | See (2) | I | I | I | I | CVT FLUID CVT FLUID CONDITION | ||||
| Exhaust system | I | I | EXHAUST SYSTEM | |||||||
| Transfer oil (For level & leaks) | I | I | I | I | TRANSFER OIL | |||||
| Differential gear oil (For level & leaks) (1) | I | I | I | I | REAR DIFFERENTIAL GEAR OIL | |||||
| Propeller shaft & drive shafts (1) | I | I | I | I | REAR PROPELLER SHAFT DRIVE SHAFT | |||||
| Steering gear & linkage, axle & suspension parts (1) | I | I | STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS | |||||||
| Outside and inside | ||||||||||
| Wheel alignment (If necessary, rotate & balance wheels) | I | I | I | I | WHEELS (BONDING WEIGHT TYPE) WHEEL ALIGNMENT WHEEL ALIGNMENT | |||||
| Brake pads, rotors, drums & linings (1) | I | I | I | I | DISC BRAKE FRONT DISC BRAKE REAR DISC BRAKE | |||||
| Foot brake & parking brake (For free play, stroke & operation) | I | I | I | I | PERIODIC MAINTENANCE PERIODIC MAINTENANCE | |||||
| Air conditioner filter (1) | R | R | R | R | PERIODIC MAINTENANCE | |||||
| (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 100,000 km (60,000 miles), then change CVT fluid NS-2 if necessary. (Refer to " CONSULT-III FUNCTION (TRANSMISSION) ".) And if CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 100,000 km (60,000 miles). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the warranty. | ||||||||||
| (1) | Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". |
| (2) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 100,000 km (60,000 miles), then change CVT fluid NS-2 if necessary. (Refer to " CONSULT-III FUNCTION (TRANSMISSION) ".) And if CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 100,000 km (60,000 miles). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the warranty. |
MAINTENANCE OPERATION REFERENCE CHART
The maintenance intervals shown on the preceding information are for normal operating conditions. If the vehicle is mainly operated under severe driving conditions as shown below, more frequent maintenance must be performed on the following items as shown in the table.
Severe driving conditions
- Driving under dusty conditions
- Driving repeatedly short distances
- Towing a trailer or caravan
- Extensive idling
- Driving in extremely adverse weather conditions or in areas where ambient temperatures are either extremely low or extremely high
- Driving in high humidity or mountainous areas
- Driving in areas using salt or other corrosive areas
- Driving on rough and/or muddy roads or in the desert
- Driving with frequent use of braking or in mountainous areas
- Frequent driving in water MAINTENANCE OPERATION REFERENCE CHART Maintenance operation: Inspect. Correct or replace if necessary. Driving condition Maintenance item Maintenance operation Maintenance interval Reference Information A . . . . . . . . . Air cleaner filter Viscous paper type Replace More frequently «AIR CLEANER FILTER»(ref-405871-S11053862352011062300000) A B C D . . . . . . Engine oil & engine oil filter Replace Every 5,000 km (3,000 miles) or 3 months «ENGINE OIL»(ref-405871-S30335448402011062300000) «OIL FILTER»(ref-405871-S10049193772011062300000) . . . . . F . . . . Brake fluid Replace Every 20,000 km (12,000 miles) or 12 months «BRAKE FLUID»(ref-405871-S01114328632011062300000) . . C . . . . H . . Differential gear oil Replace Every 40,000 km (24,000 miles) or 24 months «REAR DIFFERENTIAL GEAR OIL»(ref-405871-S03191689922011062300000) . . . . . . G H . . Propeller shaft & drive shafts Inspect Every 10,000 km (6,000 miles) or 6 months «REAR PROPELLER SHAFT»(ref-405871-S38658930282011062300000) «DRIVE SHAFT»(ref-405871-S07263118222011062300000) . . . . . . G H . . Steering gear & linkage, axle & suspension parts Inspect Every 20,000 km (12,000 miles) or 12 months «STEERING GEAR AND LINKAGE»(ref-405871-S02797256082011062300000) «AXLE AND SUSPENSION PARTS»(ref-405871-S08611021612011062300000) A . C . . . G H I . Brake pads, rotors, drums & linings Inspect Every 5,000 km (3,000 miles) or 3 months «DISC BRAKE»(ref-405871-S40272031982011062300000) «FRONT DISC BRAKE»(ref-405850-S09230020522011062300000) «REAR DISC BRAKE»(ref-405850-S21689265782011062300000) A . . . . . . . . . Air conditioner filter Replace More frequently «PERIODIC MAINTENANCE»(ref-405879-S10671700862011062300000)
FOR NORTH AMERICA : Engine Oil Recommendation
NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.
Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.
Scheme 35
FOR NORTH AMERICA : Anti-Freeze Coolant Mixture Ratio
The engine cooling system is filled at the factory with a high-quality, year-round, anti-freeze coolant solution.
The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.
| For outside temperatures down to | Genuine NISSAN Anti-freeze Coolant (blue) or equivalent | Demineralized water or distilled water | |
|---|---|---|---|
| °C | °F | ||
| 35 | 30 | 50% | 50% |
ANTI-FREEZE COOLANT REFERENCE CHART
| CAUTION | When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with the proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
FOR MEXICO : Engine Coolant Mixture Ratio
The engine cooling system is filled at the factory with a high-quality, year-round and extended life engine coolant. The high quality engine coolant contains the specific solutions effective for the anti-corrosion and the anti-freeze function. Therefore, additional cooling system additives are not necessary.
| CAUTION | When adding or replacing coolant, be sure to use only Genuine NISSAN Engine Coolant or equivalent in its quality with the proper mixture ratio. See the examples shown. The use of other types of engine coolant may damage engine cooling system. |
- When checking the engine coolant mixture ratio by the coolant hydrometer, use the chart below to correct your hydrometer reading (specific gravity) according to coolant temperature. ENGINE COOLANT COMPOSITION CHART Outside temperature down to Composition °C °F Engine coolant (Concentrated) Demineralized water or distilled water -15 5 30% 70% -35 -30 50% 50%
Mixed coolant specific gravity
| Unit: specific gravity | ||||
|---|---|---|---|---|
| Engine coolant mixture ratio | Coolant temperature °C (°F) | |||
| 15 (59) | 25 (77) | 35 (95) | 45 (113) | |
| 30% | 1.046 - 1.050 | 1.042 - 1.046 | 1.038 - 1.042 | 1.033 - 1.038 |
| 50% | 1.076 - 1.080 | 1.070 - 1.076 | 1.065 - 1.071 | 1.059 - 1.065 |
MIXED COOLANT REFERENCE CHART
| WARNING | Never remove the radiator cap when the engine is hot. Serious burns could be caused by high pressure fluid escaping from the radiator. Wait until the engine and radiator cool down. |
Scheme 36
DRIVE BELTS : Checking
| WARNING | Be sure to perform this step when the engine is stopped. |
- Check that the indicator (notch on fixed side) of drive belt auto-tensioner is within the possible use range (between four line notches on moving side). NOTE: Check the drive belt auto-tensioner indication when the engine is cold. When new drive belt is installed, the indicator (notch on fixed side) should be within the range (C) in the figure.
- Visually check entire drive belt for wear, damage or cracks.
- If the indicator (notch on fixed side) is out of the possible use range or belt is damaged, replace drive belt.
OIL LEAKAGE
Check transfer surrounding area (oil seal, drain plug, filler plug, and transfer case, etc.) for oil leakage.
Scheme 37
- Remove filler plug (1) and gasket. Then check that oil is filled up (A) from mounting hole for the filler plug.
- Before installing filler plug, set a new gasket. Install filler plug on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-405886-S28115167772011062300000) ". CAUTION: Never reuse gaskets.
Scheme 38
- Run the vehicle to warm up the transfer unit sufficiently.
- Stop the engine and remove drain plug (1) and gaskets to drain the transfer oil. CAUTION: Never remove tooth contact test hole plug (2).
- Before installing drain plug, set a new gasket. Install drain plug on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-405886-S28115167772011062300000) ". CAUTION: Never reuse gaskets.
RUNOUT MEASURING POINT
Propeller shaft runout measuring point (Point "b").
Dimension A: 501 mm (19.72 in)
B: 445 mm (17.52 in)
Scheme 39
Make sure that oil is not leaking from final drive assembly or around it.
Scheme 40
- Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure. CAUTION: Never start engine while checking oil level.
- Set a new gasket on filler plug and install it on final drive assembly. Refer to " «EXPLODED VIEW»(ref-405883-S21069930292011062300000) ". CAUTION: Never reuse gasket.
Scheme 41
- Stop engine.
- Remove drain plug (1) and drain gear oil.
- Set a new gasket on drain plug and install it to final drive assembly and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-405883-S21069930292011062300000) ". CAUTION: Never reuse gasket.
BALANCING WHEELS (BONDING WEIGHT TYPE)
Preparation Before Adjustment
Using releasing agent, remove double-faced adhesive tape from the road wheel.
| CAUTION | Be careful not scratch the road wheel during removal. After removing double-faced adhesive tape, wipe clean traces of releasing agent from the road wheel. |
Wheel Balance Adjustment
- If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting, select and adjust a drive-in weight mode suitable for road wheels.
Scheme 42
Scheme 43
Scheme 44
- Set road wheel on tire balance machine using the center hole as a guide. Start the tire balance machine.
- When inner and outer unbalance values are shown on the tire balance machine indicator, multiply outer unbalance value by 5/3 to determine balance weight that should be used. Select the outer balance weight with a value closest to the calculated value above and install in to the designated outer position of, or at the designated angle in relation to the road wheel. CAUTION: Do not install the inner balance weight before installing the outer balance weight. Before installing the balance weight, be sure to clean the mating surface of the road wheel. Indicated unbalance value x 5/3 = balance weight to be installed Calculation example: 23 g (0.81 oz.) x 5/3 = 38.33 g (1.35 oz.) => 40 g (1.41 oz.) balance weight (closer to calculated balance weight value) NOTE: Note that balance weight value must be closer to the calculated balance weight value. Example: 37.4 => 35 g (1.23 oz.) 37.5 => 40 g (1.41 oz.) Installed balance weight in the position. When installing balance weight (1) to road wheels, set it into the grooved area (A) on the inner wall of the road wheel as shown in the figure so that the balance weight center (B) is aligned with the tire balance machine indication position (angle) (C). CAUTION: Always use genuine NISSAN adhesion balance weights. Balance weights are non-reusable; always replace with new ones. Do not install more than three sheets of balance weight. If calculated balance weight value exceeds 50 g (1.76 oz.), install two balance weight sheets in line with each other as shown in the figure. CAUTION: Do not install one balance weight sheet on top another.
- Start tire balance machine again.
- Install drive-in balance weight on inner side of road wheel in the tire balance machine indication position (angle). CAUTION: Do not install more than two balance weight.
- Start tire balance machine. Make sure that inner and outer residual unbalance values are 5 g (0.17 oz.) each or below.
- If either residual unbalance value exceeds 5 g (0.17 oz.), repeat installation procedures. WHEEL BALANCE REFERENCE CHART Wheel balance Dynamic (At flange) Static (At flange) Maximum allowable unbalance Refer to " «ROAD WHEEL : ROAD WHEEL»(ref-405871-S26003200872011062300000) ".
Scheme 45
- Follow the maintenance schedule for tire rotation service intervals. Refer to " «FOR NORTH AMERICA : SCHEDULE 1»(ref-405871-S02300589032011062300000) ".
- When installing the wheel, tighten wheel nuts to the specified torque. CAUTION: Do not include the T-type spare tire when rotating the tires. When installing wheels, tighten them diagonally by dividing the work two to three times in order to prevent the wheels from developing any distortion. Be careful not to tighten wheel nut at torque exceeding the criteria for preventing strain of disc rotor. Use NISSAN genuine wheel nuts for aluminum wheels. Wheel nuts tightening torque : Refer to " «ROAD WHEEL : ROAD WHEEL»(ref-405871-S26003200872011062300000) ".
- Perform the ID registration, after tire rotation. Refer to " «ID REGISTRATION PROCEDURE : SPECIAL REPAIR REQUIREMENT»(ref-405888-S18845495722011062300000) ".
Scheme 46
- If fluid level is extremely low, check brake system for leaks.
Scheme 47
- Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc.
Scheme 48
- Drain brake fluid from each bleed valve.
- Refill until new brake fluid comes out from each bleed valve. Use same procedure as in bleeding hydraulic system to refill brake fluid. Refer to " «REFILLING»(ref-405850-S10916580042011062300000) ". Refill with recommended brake fluid. Refer to " «FOR NORTH AMERICA : FLUIDS AND LUBRICANTS»(ref-405871-S03029356842011062300000) "(FOR NORTH AMERICA), " «FOR MEXICO : FLUIDS AND LUBRICANTS»(ref-405871-S19632586962011062300000) " (FOR MEXICO). Never reuse drained brake fluid. Be careful not to splash brake fluid on painted areas.
DISC ROTOR
Check condition, wear, and damage.
Scheme 49
- Check for leakage.
Scheme 50
- Check for wear or damage.
DISC BRAKE : Front Disc Brake
| Unit: mm (in) | ||
|---|---|---|
| Brake pad | Standard thickness | 11.0 (0.433) |
| Wear limit thickness | 2.0 (0.079) | |
| Disc rotor | Standard thickness | 26.0 (1.024) |
| Wear limit thickness | 24.0 (0.945) | |
| Thickness variation (measured at 8 positions) | 0.020 (0.0008) | |
| Runout limit (with it attached to the vehicle) | 0.035 (0.0014) | |
FRONT DISC BRAKE REFERENCE CHART
DISC BRAKE : Rear Disc Brake
| Unit: mm (in) | ||
|---|---|---|
| Brake pad | Standard thickness | 8.5 (0.335) |
| Wear limit thickness | 1.5 (0.059) | |
| Disc rotor | Standard thickness | 16.0 (0.630) |
| Wear limit thickness | 14.0 (0.551) | |
| Thickness variation (measured at 8 positions) | 0.020 (0.0008) | |
| Runout limit (with it attached to the vehicle) | 0.070 (0.0028) | |
REAR DISC BRAKE REFERENCE CHART
Scheme 51
- Check gear housing and boots for looseness, damage and grease leakage.
- Check connection with steering column for looseness.
STEERING LINKAGE
Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.
WITH INTELLIGENT KEY SYSTEM
For hood and hood lock illustration.
- Hood: Refer to " «HOOD ASSEMBLY : EXPLODED VIEW»(ref-405893-S25923189952011062300000) ".
- Hood lock control: Refer to " «HOOD LOCK CONTROL : EXPLODED VIEW»(ref-405893-S19470710452011062300000) ".
For front door and front door lock illustration.
- Front door: Refer to " «DOOR ASSEMBLY : EXPLODED VIEW»(ref-405893-S24838617982011062300000) ".
- Front door lock: Refer to " «DOOR LOCK : EXPLODED VIEW»(ref-405893-S34354905842011062300000) ".
- Rear door: Refer to " «DOOR ASSEMBLY : EXPLODED VIEW»(ref-405893-S22372388332011062300000) ".
- Rear door lock: Refer to " «DOOR LOCK : EXPLODED VIEW»(ref-405893-S01011789232011062300000) ".
For back door and back door lock illustration.
- Back door: Refer to " «BACK DOOR ASSEMBLY : EXPLODED VIEW»(ref-405893-S06776215002011062300000) ".
- Back door lock: Refer to " «DOOR LOCK : EXPLODED VIEW»(ref-405893-S18246686172011062300000) ".
WITHOUT INTELLIGENT KEY SYSTEM
For hood and hood lock illustration.
- Hood: Refer to " «HOOD ASSEMBLY : EXPLODED VIEW»(ref-405893-S03638112342011062300000) ".
- Hood lock control: Refer to " «HOOD LOCK CONTROL : EXPLODED VIEW»(ref-405893-S10403166662011062300000) ".
For front door and front door lock illustration.
- Front door: Refer to " «DOOR ASSEMBLY : EXPLODED VIEW»(ref-405893-S00999404992011062300000) ".
- Front door lock: Refer to " «DOOR LOCK : EXPLODED VIEW»(ref-405893-S00077559212011062300000) ".
- Rear door: Refer to " «DOOR ASSEMBLY : EXPLODED VIEW»(ref-405893-S11833034072011062300000) ".
- Rear door lock: Refer to " «DOOR LOCK : EXPLODED VIEW»(ref-405893-S06858948612011062300000) ".
For back door and back door lock illustration.
- Back door: Refer to " «BACK DOOR ASSEMBLY : EXPLODED VIEW»(ref-405893-S01399161232011062300000) ".
- Back door lock: Refer to " «DOOR LOCK : EXPLODED VIEW»(ref-405893-S11226980092011062300000) ".
DRIVE BELT
| Tension of drive belt | Belt tension is not necessary, as it is automatically adjusted by drive belt auto-tensioner. |
DRIVE BELT SPECIFICATIONS CHART
SPARK PLUG
| Unit: mm (in) | |
|---|---|
| Make | NGK |
| Standard type | DILKAR6A-11 |
| Spark plug gap (Nominal) | 1.1 (0.043) |
SPARK PLUG SPECIFICATIONS
ROAD WHEEL : Road Wheel
| Kind of wheel | Aluminum | Steel | |
|---|---|---|---|
| Maximum radial runout limit | Lateral deflection | Less than 0.3 mm (0.012 in) | Less than 0.8 mm (0.031) |
| Vertical deflection | Less than 0.3 mm (0.012 in) | Less than 0.5 mm (0.020) | |
| Maximum allowable unbalance limit | Dynamic (At flange) | Less than 5 g (0.17 oz.) (one side) | |
| Static (At flange) | Less than 10 g (0.35 oz.) | ||
| Wheel nuts tightening torque | 108 N.m (11 kg-m, 80 ft-lb) | ||
ROAD WHEEL SPECIFICATIONS
