Maintenance: Diagnosis Nissan Rogue I рестайлинг

RADIATOR : Inspection

Check radiator for mud or clogging. If necessary, clean radiator as follows.

1. Apply water by hose to the back side of the radiator core vertically downward.
2. Apply water again to all radiator core surfaces once per minute.
3. Stop washing if any stains no longer flow out from radiator.
4. Blow air into the back side of radiator core vertically downward. Use compressed air lower than 490 kPa (5 kg/cm 2 , 71 psi) and keep distance more than 30 cm (11.81 in).
5. Blow air again into all the radiator core surfaces once per minute until no water sprays out.

FUEL LINES : Inspection

Inspect fuel lines, fuel filler cap and, fuel tank for improper attachment, leakage, cracks, damage, loose connections, chafing or deterioration.

If necessary, repair or replace damaged parts.

Scheme 3

Scheme 4

Scheme 5

1. Push the tabs (A) of both ends of the air cleaner cover (1) into the inside (B).
2. Pull up the air cleaner cover forward (C) and remove it.
3. Remove the air cleaner filter (1) and holder (2) assembly from the air cleaner case.
4. Remove the air cleaner filter from the holder.

INSPECTION AFTER INSTALLATION

1. Check the engine oil level. Refer to " «INSPECTION»(ref-405863-S38900614132011062300000) ".
2. Start the engine, and check there is no leakage of engine oil.
3. Stop the engine and wait for 10 minutes.
4. Check the engine oil level, and adjust the level. Refer to " «INSPECTION»(ref-405863-S38900614132011062300000) ".

Scheme 6

1. Remove ignition coil. Refer to " «REMOVAL AND INSTALLATION»(ref-405857-S36413518662011062300000) ".
2. Remove spark plug with spark plug wrench (commercial service tool). CAUTION: Never drop or shock spark plug.

INSPECTION AFTER REMOVAL

Use standard type spark plug for normal condition.

Spark plug (standard) : Refer to " SPARK PLUG ".

Scheme 7

Scheme 8

EVAP VAPOR LINES : Inspection

For California, refer to " INSPECTION ".

For USA (Federal) and Canada, refer to " INSPECTION ".

For Mexico, refer to " INSPECTION ".

EXHAUST SYSTEM : Inspection

Check exhaust pipes, muffler, and mounting for improper attachment, leakage, cracks, damage or deterioration.

Scheme 9

1. If anything is found, repair or replace damaged parts.

AXLE AND SUSPENSION PARTS : Inspection

Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.

Scheme 10

Scheme 11

1. Shake each wheel to check for excessive play.
2. Check wheel bearings for smooth operation.
3. Check axle and suspension nuts and bolts for looseness.
4. Check strut (shock absorber) for oil leakage or other damage.
5. Check suspension ball joint for grease leakage and ball joint dust cover for cracks or other damage.

Scheme 12

1. Check boot and drive shaft for cracks, wear, damage and grease leakage.

SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS : Inspection

For front seat belt illustration. Refer to " SEAT BELT RETRACTOR : EXPLODED VIEW ".

For rear seat belt illustration. Refer to " SEAT BELT RETRACTOR : EXPLODED VIEW ".

For details, refer to " SEAT BELT RETRACTOR : INSPECTION ", " SEAT BELT RETRACTOR : INSPECTION " in Seat Belt article.

1. Check anchors for loose mounting
2. Check belts for damage
3. Check retractor for smooth operation
4. Check function of buckles and tongues when buckled and released
