Reference Value Nissan Rogue I

Security Control System 1 illustration

Reference Value

VALUES ON THE DIAGNOSIS TOOL

Monitor ItemConditionValue/Status
MOTOR FAN REQEngine idle speedChanges depending on engine coolant temperature, air conditioner operation status, vehicle speed, etc.1 - 4
AC COMP REQEngine runningA/C switch OFFOff
A/C switch ON (Compressor is operating)On
TAIL&CLR REQLighting switch OFFOff
Lighting switch 1ST or 2NDOn
HL LO REQLighting switch OFFOff
Lighting switch 2NDOn
HL HI REQLighting switch OFFOff
Lighting switch HI (Light is illuminated)On
FR FOG REQ NOTE: This item is monitored only on the vehicle with front fog lamp.Lighting switch 2NDFront fog lamp switch OFFOff
Front fog lamp switch ONOn
FR WIP REQIgnition switch ONFront wiper switch OFFStop
Front wiper switch INT1LOW
Front wiper switch LOLow
Front wiper switch HIHi
WIP AUTO STOPIgnition switch ONFront wiper stop positionSTOP P
Any position other than front wiper stop positionACT P
WIP PROTIgnition switch ONFront wiper operates normallyOff
Front wiper stops at fail-safe operationBLOCK
ST RLY REQ NOTE: Vehicle without Intelligent Key system indicates only "ON", and it does not change.When Intelligent Key is outside the vehicle, and the push switch is pushedOff
When Intelligent Key is inside the vehicle, and the push switch is pushedOn
IGN RLYIgnition switch OFF or ACCOff
Ignition switch ONOn
RR DEF REQIgnition switch ONRear window defogger switch OFFOff
Rear window defogger switch ON (Rear window defogger is operating)On
OIL P SWIgnition switch OFF, ACC or engine runningOpen
Ignition switch ONClose
DTRL REQ NOTE: This item is monitored only on the vehicle with the daytime running light system.Daytime running light system is not operated.Off
Daytime running light system is operated.On
HOOD SW NOTE: This item is monitored only the vehicle for Mexico.Close the hoodOff
Open the hoodOn
THFT HRN REQNot operationOff
Horn is activated with vehicle security system or panic alarm system.On
HORN CHIRPNot operationOff
Horn is activated with key fob LOCK operation.On
NOTE
This item is monitored only on the vehicle with front fog lamp.
NOTE
Vehicle without Intelligent Key system indicates only "ON", and it does not change.
NOTE
This item is monitored only on the vehicle with the daytime running light system.
NOTE
This item is monitored only the vehicle for Mexico.

MONITOR ITEM CONDITION CHART

Scheme 210: Identifying IPDM E/R Connector Terminal
Scheme 210: Identifying IPDM E/R Connector Terminal
Terminal No. (Wire color)DescriptionConditionValue (Approx.)
+Signal nameInput/ Output
1 (R)GroundBattery power supplyInputIgnition switch OFFBattery voltage
2 (G)GroundBattery power supplyInputIgnition switch OFFBattery voltage
3 (O)GroundStarter relay power supplyOutputWhen engine is clankingBattery voltage
When engine is not clanking0 V
4 (W)GroundCooling fan relay-1 power supplyOutputCooling fan operationOFF0 V
MID or HIBattery voltage
5 (R)GroundIgnition switch STARTInputIgnition switch OFF, ACC or ON0 V
Ignition switch STARTBattery voltage
6 (BR)GroundBattery power supply (Cooling fan relay)InputIgnition switch OFFBattery voltage
7 (P)GroundCooling fan motor-2 (HI) groundCooling fan operationOFFBattery voltage
HI0 V
8 (G)GroundCooling fan relay-2 power supplyOutputCooling fan operationOFF0 V
HIBattery voltage
11 (B)GroundGroundIgnition switch ON0 V
12 (O)GroundRear window defogger relay power supplyOutputIgnition switch ONRear window defogger switch OFF0 V
Rear window defogger switch ONBattery voltage
15 (1) (SB)GroundDaytime running light relay controlOutputDaytime running light systemNot operatedBattery voltage
Operated0 V
16 (2) (Y)GroundFront fog lamp (LH)OutputLighting switch 2NDFront fog lamp switch OFF0 V
Front fog lamp switch ONBattery voltage
17 (2) (W)GroundFront fog lamp (RH)OutputLighting switch 2NDFront fog lamp switch OFF0 V
Front fog lamp switch ONBattery voltage
18 (L)GroundHeadlamp LO (LH)OutputLighting switch OFF0 V
Lighting switch 2NDBattery voltage
20 (SB)GroundHeadlamp LO (RH)OutputLighting switch OFF0 V
Lighting switch 2NDBattery voltage
21 (G)GroundHeadlamp HI (LH)OutputLighting switch OFF0 V
Lighting switch 2ND and HI Lighting switch PASSBattery voltage
22 (LG)GroundHeadlamp HI (RH)OutputLighting switch OFF0 V
Lighting switch 2ND and HI Lighting switch PASSBattery voltage
23 (W)GroundOil pressure switchInputIgnition switch ONEngine stopped0 V
Engine runningBattery voltage
24 (Y)GroundFront wiper auto stopInputIgnition switch ONFront wiper stop position0 V
Any position other than front wiper stop positionBattery voltage
25 (B)GroundGroundIgnition switch ON0 V
26 (P)CAN-LInput/Output
27 (L)CAN-HInput/Output
31 (LG)GroundCooling fan relay-4 controlOutputCooling fan operationOFFBattery voltage
LO0 - 1.0 V
32 (V)GroundETC relay controlInputAfter passing approximately 2 seconds or more after turning the ignition switch from ON to OFFBattery voltage
Ignition switch ON For approximately 2 seconds after turning ignition switch from ON to OFF0 - 1.0 V
33 (GR)GroundFuel pump relay controlInputIgnition switch OFF0 V
Ignition switch ONEngine stoppedBattery voltage
Engine running0.8 V
34 (3) (W)GroundHood switchInputClose the hoodBattery voltage
Open the hood0 V
37 (R)GroundTail, license plate lamps and illuminationsOutputLighting switch OFF0 V
Lighting switch 1STBattery voltage
38 (R)GroundParking lamp (LH)OutputLighting switch OFF0 V
Lighting switch 1STBattery voltage
39 (GR)GroundParking lamp (RH)OutputLighting switch OFF0 V
Lighting switch 1STBattery voltage
40 (BR)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
41 (O)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
42 (L)GroundFront wiper HIOutputIgnition switch ONFront wiper switch OFF0 V
Front wiper switch HIBattery voltage
43 (G)GroundFront wiper LOOutputIgnition switch ONFront wiper switch OFF0 V
Front wiper switch LOBattery voltage
45 (Y)GroundStarter relay power supplyInputIgnition switch ONSelector lever "P" or "N"Battery voltage
Selector lever in any position other than "P" or "N"0 V
46 (W)GroundFuel pump relay power supplyOutputIgnition switch OFF or ACC After passing approximately 1 second or more after turning the ignition switch ON0 V
For approximately 1 second after turning the ignition switch ON Engine runningBattery voltage
47 (BR)GroundECM relay power supplyOutputAfter passing approximately 4 seconds or more after turning the ignition switch from ON to OFF0 V
Ignition switch ON For approximately 4 seconds after turning ignition switch from ON to OFFBattery voltage
48 (R)GroundECM relay power supplyOutputAfter passing approximately 4 seconds or more after turning the ignition switch from ON to OFF0 V
Ignition switch ON For approximately 4 seconds after turning ignition switch from ON to OFFBattery voltage
50 (G)GroundCooling fan relay-5 controlOutputCooling fan operationOFFBattery voltage
MID or HI0 - 1.0 V
51 (L)GroundECM relay controlOutputAfter passing approximately 4 seconds or more after turning the ignition switch from ON to OFFBattery voltage
Ignition switch ON For approximately 4 seconds after turning ignition switch from ON to OFF0 - 1.0 V
52 (P)GroundETC relay power supplyOutputAfter passing approximately 2 seconds or more after turning the ignition switch from ON to OFF0 V
Ignition switch ON For approximately 2 seconds after turning ignition switch from ON to OFFBattery voltage
55 (O)GroundA/C relay power supplyOutputEngine stopped0 V
Engine runningA/C switch OFF0 V
A/C switch ON (A/C compressor is operating)Battery voltage
56 (L)GroundIgnition switch ONInputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
57 (V)GroundHorn relay controlOutputThe horn is not activatedBattery voltage
The horn is activated0 V
58 (LG)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
59 (BR)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
60 (SB)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
61 (R)GroundECM power supplyOutputIgnition switch OFFBattery voltage
(1) With daytime running light system (2) With front fog lamp system (3) For Mexico
(1)With daytime running light system
(2)With front fog lamp system
(3)For Mexico

CONNECTOR TERMINAL REFERENCE CHART
