Maintenance: Other Nissan Rogue I

FOR NORTH AMERICA : Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

SPECIAL SERVICE TOOL Tool number (Kent-Moore No.) Tool name Description KV10115801 (J38956) Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in)

FOR NORTH AMERICA : Commercial Service Tool

COMMERCIAL SERVICE TOOL (Kent-Moore No.) Tool name Description ( - ) Power tool Loosening nuts and bolts ( - ) Spark plug wrench Removing and installing spark plug (BT3373-F) Belt tension gauge Checking drive belt tension

Scheme 30

Scheme 31

FOR MEXICO : Special Service Tool

SPECIAL SERVICE TOOL Tool number Tool name Description EG17650301 Radiator cap tester adapter Adapting radiator cap tester to radiator cap and radiator filler neck 28 (1.10) dia. 31.4 (1.236) dia. 41.3 (1.626) dia. Unit: mm (in) KV10115801 Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in)

Scheme 32

FOR MEXICO : Commercial Service Tool

COMMERCIAL SERVICE TOOL Tool name Description Power tool Loosening nuts and bolts Radiator cap tester Checking radiator and radiator cap Spark plug wrench Removing and installing spark plug

Scheme 33

UNDER HOOD - engine off

1. Radiator coolant level and coolant hose connections for leaks
2. Battery fluid level, specific gravity and conditions of battery terminals
3. Drive belts tension
4. Fuel filter for water or dusts (Diesel only), and fuel lines and connections for leaks
5. Engine oil level and oil leaks
6. Clutch and brake reservoir fluid level and fluid lines for leaks
7. Windshield and rear window washer and headlamp cleaner reservoir fluid level
8. Power steering reservoir fluid level and hose connections for leaks

ON INSIDE AND OUTSIDE

1. Remove front spring/strut spacer (If applicable)
2. Operation of all instruments, gauges, lights and accessories
3. Operation of horn(s), wiper and washer
4. Steering lock for operation
5. Check air conditioner for gas leaks
6. Front and rear seats, and seat belts for operation
7. All moldings, trims and fittings for fit and alignment
8. All windows for operation and alignment
9. Hood, trunk lid, door panels for fit and alignment
10. Latches, keys and locks for operation
11. Weatherstrips for adhesion and fit
12. Headlamp aiming
13. Tighten wheel nuts (Inc. inner nuts if applicable)
14. Tire pressure (Inc. spare tire)
15. Check front wheels for toe-in
16. Install clock/voltmeter/room lamp fuse (If applicable)
17. Install deodorizing filter to air conditioner (If applicable)
18. Remove wiper blade protectors (If applicable)

UNDER BODY

1. Manual transmission/transaxle, transfer and differential gear oil level
2. Brake and fuel lines and oil/fluid reservoirs for leaks
3. Tighten bolts and nuts of steering linkage and gear box, suspension, propeller shafts and drive shafts
4. Tighten rear body bolts and nuts (Models with wooden bed only)

ENGINE OPERATING AND HOT

1. Adjust idle speed
2. Automatic transmission/transaxle fluid level
3. Engine idling and stop knob operation (Diesel only)

FOR NORTH AMERICA : Engine Oil Recommendation

NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.

Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.

Scheme 34

FOR NORTH AMERICA : Anti-Freeze Coolant Mixture Ratio

The engine cooling system is filled at the factory with a high-quality, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.

Scheme 35

GASOLINE ENGINE

1. 10W-30 is preferable.

5W-30 is also preferable and will improve fuel economy.

If 10W-30 or 5W-30 is not available, select the viscosity, from the chart, that is suitable for the outside temperature range.

Scheme 36

FOR MEXICO : Engine Coolant Mixture Ratio

The engine cooling system is filled at the factory with a high-quality, year-round and extended life engine coolant. The high quality engine coolant contains the specific solutions effective for the anti-corrosion and the anti-freeze function. Therefore, additional cooling system additives are not necessary.

Scheme 37

1. When checking the engine coolant mixture ratio by the coolant hydrometer, use the chart below to correct your hydrometer reading (specific gravity) according to coolant temperature.

Mixed coolant specific gravity

COOLANT SPECIFIC GRAVITY SPECIFICATION

Scheme 38

DRIVE BELTS : Checking

1. Check that the indicator (notch on fixed side) of drive belt auto-tensioner is within the possible use range (between four line notches on moving side). NOTE: Check the drive belt auto-tensioner indication when the engine is cold. When new drive belt is installed, the indicator (notch on fixed side) should be within the range (C) in the figure.
2. Visually check entire drive belt for wear, damage or cracks.
3. If the indicator (notch on fixed side) is out of the possible use range or belt is damaged, replace drive belt.

OIL LEAKAGE

Check transfer surrounding area (oil seal, drain plug, filler plug, and transfer case, etc.) for oil leakage.

Scheme 39

1. Remove filler plug (1) and gasket. Then check that oil is filled up (A) from mounting hole for the filler plug.
2. Before installing filler plug, set a new gasket. Install filler plug on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-295114-S05020645472008081400000) ". CAUTION: Never reuse gaskets. see scheme 33: Identifying Filler Plug

Scheme 40

1. Run the vehicle to warm up the transfer unit sufficiently.
2. Stop the engine and remove drain plug (1) and gaskets to drain the transfer oil. CAUTION: Never remove tooth contact test hole plug (2).
3. Before installing drain plug, set a new gasket. Install drain plug on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-295114-S05020645472008081400000) ". CAUTION: Never reuse gaskets. see scheme 34: Identifying Drain Plug And Test Hole Plug

RUNOUT MEASURING POINT

Propeller shaft runout measuring point (Point "triangle").

Dimension A: 498 mm (19.61 in)

B: 416 mm (16.38 in)

Scheme 41

Make sure that oil is not leaking from final drive assembly or around it.

Scheme 42

1. Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure. CAUTION: Never start engine while checking oil level.
2. Set a new gasket on filler plug and install it on final drive assembly. Refer to " «EXPLODED VIEW»(ref-295114-S29785163022008081400000) ". CAUTION: Never reuse gasket. (Scheme 39): Checking Oil Level From Filler Plug Mounting Hole

Scheme 43

1. Stop engine.
2. Remove drain plug (1) and drain gear oil.
3. Set a new gasket on drain plug and install it to final drive assembly and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-295114-S29785163022008081400000) ". CAUTION: Never reuse gasket. (Scheme 40): Identifying Drain Plug

BALANCING WHEELS (BONDING WEIGHT TYPE)

Preparation Before Adjustment

Using releasing agent, remove double-faced adhesive tape from the road wheel.

Wheel Balance Adjustment

1. If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting, select and adjust a drive-in weight mode suitable for road wheels.

Scheme 44

Scheme 45

Scheme 46

1. Set road wheel on tire balance machine using the center hole as a guide. Start the tire balance machine.
2. When inner and outer unbalance values are shown on the tire balance machine indicator, multiply outer unbalance value by 5/3 to determine balance weight that should be used. Select the outer balance weight with a value closest to the calculated value above and install in to the designated outer position of, or at the designated angle in relation to the road wheel. CAUTION: Do not install the inner balance weight before installing the outer balance weight. Before installing the balance weight, be sure to clean the mating surface of the road wheel. Indicated unbalance value X 5/3 = balance weight to be installed Calculation example: 23 g (0.81 oz.) X 5/3 = 38.33 g (1.35 oz.) ==> 40 g (1.41 oz.) balance weight (closer to calculated balance weight value) NOTE: Note that balance weight value must be closer to the calculated balance weight value. Example: 37.4 ==> 35 g (1.23 oz.) 37.5 ==> 40 g (1.41 oz.) see scheme 41: Identifying Balance Weight Installed balance weight in the position. When installing balance weight (1) to road wheels, set it into the grooved area (A) on the inner wall of the road wheel as shown in the figure so that the balance weight center (B) is aligned with the tire balance machine indication position (angle) (C). CAUTION: Always use genuine NISSAN adhesion balance weights. Balance weights are non-reusable; always replace with new ones. Do not install more than three sheets of balance weight. (Scheme 41): Identifying Balance Weight Installing Position If calculated balance weight value exceeds 50 g (1.76 oz.), install two balance weight sheets in line with each other as shown in the figure. CAUTION: Do not install one balance weight sheet on top another.
3. Start tire balance machine again.
4. Install drive-in balance weight on inner side of road wheel in the tire balance machine indication position (angle). CAUTION: Do not install more than two balance weight. (Scheme 42): Identifying Wheel Weight Indication Position
5. Start tire balance machine. Make sure that inner and outer residual unbalance values are 5 g (0.17 oz.) each or below.
6. If either residual unbalance value exceeds 5 g (0.17 oz.), repeat installation procedures. WHEEL BALANCE REFERENCE Wheel balance Dynamic (At flange) Static (At flange) Maximum allowable unbalance Refer to " «ROAD WHEEL»(ref-295121-S16004550822008081400000) ".

Scheme 47

1. Follow the maintenance schedule for tire rotation service intervals. Refer to " «FOR NORTH AMERICA: Explanation of General Maintenance»(ref-295130-S01336108972008081400000) ".
2. When installing the wheel, tighten wheel nuts to the specified torque. CAUTION: Do not include the T-type spare tire when rotating the tires. When installing wheels, tighten them diagonally by dividing the work two to three times in order to prevent the wheels from developing any distortion. Be careful not to tighten wheel nut at torque exceeding the criteria for preventing strain of disc rotor. (Scheme 43): Identifying Wheels Rotation Use NISSAN genuine wheel nuts for aluminum wheels. Wheel nuts tightening torque: Refer to " «ROAD WHEEL»(ref-295121-S16004550822008081400000) ".
3. Perform the ID registration, after tire rotation. Refer to " «ID REGISTRATION PROCEDURE: SPECIAL REPAIR REQUIREMENT»(ref-295121-S10791823542008081400000) ".

Scheme 48

1. If fluid level is extremely low, check brake system for leaks. see scheme 45: Checking Brake Fluid Level And Leaks

Scheme 49

1. Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc. (Scheme 44): Checking Brake Fluid Lines And Parking Brake Cables

Scheme 50

1. Drain brake fluid from each bleed valve.
2. Refill until new brake fluid comes out from each bleed valve. Use same procedure as in bleeding hydraulic system to refill brake fluid. Refer to " «REFILLING»(ref-295127-S33972476012008081400000) ". Refill with recommended brake fluid. Refer to " «FOR NORTH AMERICA: Fluids and Lubricants»(ref-295130-S34661417002008081400000) "(FOR NORTH AMERICA), " «FOR MEXICO: Fluids and Lubricants»(ref-295130-S06898715472008081400000) " (FOR MEXICO). Never reuse drained brake fluid. (Scheme 45): Draining Brake Fluid From Bleed Valve Be careful not to splash brake fluid on painted areas.

DISC ROTOR

Check condition, wear, and damage.

Scheme 51

1. Check for leakage. (Scheme 46): Checking Caliper For Fluid Leakage

Scheme 52

1. Check for wear or damage. (Scheme 47): Locating Brake Pads

DISC BRAKE : Front Disc Brake

FRONT DISC BRAKE SPECIFICATION

DISC BRAKE : Rear Disc Brake

REAR DISC BRAKE SPECIFICATION

Scheme 53

1. Check gear housing and boots for looseness, damage and grease leakage.
2. Check connection with steering column for looseness. (Scheme 48): Locating Gear Housing And Boots For Checking Leakage

STEERING LINKAGE

Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.

DRIVE BELT

DRIVE BELT SPECIFICATION

SPARK PLUG

SPARK PLUG SPECIFICATION

ROAD WHEEL : Road Wheel

ROAD WHEEL SPECIFICATION
