Security Control System: Overview Nissan Rogue I

Diagnosis And Repair Workflow Chart. Scheme 153

ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Description

Perform the system initialization when replacing BCM, ECM, Intelligent Key unit or steering lock unit with a used parts or registering an additional Intelligent Key or mechanical key.

ECM RE-COMMUNICATING FUNCTION : Description

Performing following procedure can automatically perform re-communication of ECM and BCM, but only when the ECM has been replaced with a new one (*1).

*1: New one means a virgin ECM which has never been energized on-board.

(In this step, initialization procedure by CONSULT-III is not necessary)

Note. When registering new Key IDs or replacing the ECM that is not brand new, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS. If multiple keys are attached to the key holder, separate them before work. Distinguish keys with unregistered key ID from those with registered ID.

SYSTEM DESCRIPTION

1. The engine start function of Intelligent Key system is a system that makes it possible to start and stop the engine without using the key. It verifies the electronic ID using two-way communications when pressing the ignition knob switch while carrying the Intelligent Key, which operates based on the results of electronic ID verification for Intelligent Key using two-way communications between the Intelligent Key and the vehicle. NOTE: The driver should carry the Intelligent Key at all times.
2. Intelligent Key has 2 IDs (for Intelligent Key and for NVIS/NATS). It can perform the door lock/unlock operation and the engine start operation when the registered Intelligent Key is carried.
3. When the Intelligent Key battery is discharged, it can be used as emergency back-up by inserting the mechanical key set in the Intelligent Key to the ignition key cylinder. At that time, perform the NVIS/NATS ID verification. If it is used when the Intelligent Key is carried, perform the Intelligent Key ID verification.
4. If the ID is successfully verified, and when the ignition knob switch is pressed, steering lock will be released and initiating the engine will be possible.
5. The door lock/unlock operation can be performed when the Intelligent Key battery is discharged, by operating the driver door key cylinder using the mechanical key set in the Intelligent Key.
6. Up to 4 Intelligent Keys can be registered (Including the standard Intelligent Key) on request from the owner. NOTE: Refer to " «INTELLIGENT KEY : SYSTEM DESCRIPTION»(ref-295116-S42040586632008081400000) " for any functions other than engine start function of Intelligent Key system.

OPERATION WHEN INTELLIGENT KEY IS CARRIED

1. When the ignition knob switch is ON, and Intelligent Key unit is transmit the request signal to the Intelligent Key.
2. The Intelligent Key receives the request signal and transmits the Intelligent Key ID signal to the Intelligent Key unit.
3. The Intelligent Key unit receives the Intelligent Key ID signal and verifies it with the registered ID.
4. Intelligent Key unit transmits the steering lock/unlock signal to steering lock unit and turn on the key warning lamp (green) if the verification results are OK. (The detail of key warning lamp operation, refer to " «SYSTEM DESCRIPTION»(ref-295116-S28244098212008081400000) ")
5. Release of the steering lock.
6. BCM transmits the starter request signal via CAN communication to IPDM E/R and turns the starter relay in IPDM E/R ON if BCM judges that the engine start condition is satisfied.
7. IPDM E/R turns the starter control relay ON when receiving the starter request signal.
8. When shift position is in P or N position, battery power is supplied through the starter relay and operate the starter motor and to start the cranking. CAUTION: If a malfunction is detected in the Intelligent Key system, the red "KEY" warning lamp in the combination meter illuminates. At that time, the engine cannot be started.

OPERATION RANGE

Engine can be started when Intelligent Key is inside the vehicle. However, sometimes engine might not start when Intelligent Key is on instrument panel or in glove box.

OPERATION WHEN MECHANICAL KEY IS USED

When the Intelligent Key battery is discharged, performs the NVIS/NATS ID verification between the integrated transponder and BCM by inserting the mechanical key into the key cylinder, and then the engine can be started.

For details relating to starting the engine using mechanical key, refer to " SYSTEM DESCRIPTION ".

STEERING LOCK OPERATION

Steering is locked by steering lock unit when ignition switch is in the OFF position (the ignition knob is released) and key switch is OFF (key is removed from ignition key cylinder).

Identifying Intelligent Key System/Engine Start Component Parts Location (1 Of 2). Scheme 154

Identifying Intelligent Key System/Engine Start Component Parts Location (2 Of 2). Scheme 155

Component Description

COMPONENT REFERENCE CHART

NVIS - System Diagram. Scheme 156

NVIS (NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS) has the following immobilizer functions

1. Engine immobilizer shows high anti-theft performance to prevent engine from starting by other than the owner.
2. Only a key with key ID registered in BCM and ECM can start engine, and shows high anti-theft performance to prevent key from being copied or stolen.
3. Therefore, NVIS/NATS warns outsiders that the vehicle is equipped with the anti-theft system. Refer to " «SYSTEM DESCRIPTION»(ref-295136-S19215060852008081400000) ".
4. If system detects malfunction, security indicator illuminates when ignition switch is turned to ON position.
5. If the owner requires, ignition key ID or mechanical key ID can be registered for up to 5 keys.

COMPONENT REFERENCE CHART

Vehicle Security System - System Diagram. Scheme 157

CANCELING THE ALARM OPERATION OF THE VEHICLE SECURITY SYSTEM

When unlocking the door with the key or Intelligent Key the alarm operation is canceled.

ACTIVATING THE ALARM OPERATION OF THE VEHICLE SECURITY SYSTEM

Check that the system is in the armed phase. (The security indicator lamp blinks every 2.4 seconds.)

When the following operation 1 or 2 is performed, the system sounds the horns and flashes the headlamps for approx. 50 seconds.

1. Hood or any door is opened during armed phase.
2. Disconnecting and connecting the battery connector before canceling armed phase.

PANIC ALARM OPERATION

Intelligent Key system may or may not operate vehicle security system (horn and headlamps) as required.

When the Intelligent Key system is triggered, ground is supplied intermittently to both headlamp relay and horn relay.

When headlamp relay and horn relay are energized, then power is supplied to headlamps (LH and RH) and horns (HIGH and LOW).

The headlamp flashes and the horn sounds intermittently.

The alarm automatically turns off after 50 seconds or when BCM receives any signal from Intelligent Key.

Identifying Vehicle Security System Component Parts Location (1 Of 2). Scheme 158

Identifying Vehicle Security System Component Parts Location (2 Of 2). Scheme 159

COMPONENT REFERENCE CHART

Description

CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Modern vehicle is equipped with many electronic control unit, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

CAN Communication Signal Chart. Refer to " CAN COMMUNICATION SIGNAL CHART ".

When the starting operation is carried more than 10 times consecutively under the following conditions, NVIS/ NATS will shift to the mode which prevents the engine from being started.

1. Unregistered mechanical key is used.
2. BCM or ECM's malfunctioning.

BCM performs the ID verification with ECM that allows the engine to start. BCM starts the communication with ECM if ignition switch is turned ON and starts the engine if the ID is OK. ECM prevents the engine from starting if the ID is not registered.

BCM performs the ID verification with ECM that allows the engine to start. BCM starts the communication with ECM if ignition switch is turned ON and starts the engine if the ID is OK. ECM prevents the engine from starting if the ID is not registered.

Performs ID verification through BCM and NVIS/NATS antenna amplifier when ignition knob switch is pressed. Prohibits the release of steering lock or start of engine when an unregistered ID of mechanical key is used.

Performs ID verification through BCM when ignition knob switch is pressed.

Prohibits the release of steering lock or start of engine when an unregistered ID of mechanical key is used.

Intelligent Key unit performs the ID verification with the steering lock unit and releases the steering lock if both Intelligent Key unit and steering lock unit ID are same. Intelligent Key unit starts the communication with the steering lock unit when Intelligent Key is carried into the vehicle and the ignition knob switch is pressed.

Intelligent key unit performs engine start operation and steering lock control by cross checking ID with the Intelligent key.

Intelligent Key unit performs the ID verification with BCM that allows the engine to start. BCM starts the engine if the ID is OK and prevents the engine from starting if the ID is not registered.

Detects door open/closed condition.

Key switch detects that mechanical key is inserted into the key cylinder, and then transmits the signal to BCM.

Ignition knob switch detects that ignition knob is pressed, and then transmits the signal to Intelligent Key unit.

Hood switch detects that hood is open/close condition, and then IPDM E/R detects the signal.

INSTRUMENT CENTER : Description

Detects whether Intelligent Key is inside the vehicle.

CONSOLE : Description

Detects whether Intelligent Key is inside the vehicle.

REAR SEAT : Description

Detects whether Intelligent Key is inside the vehicle.

EXCEPT FOR MEXICO : Description

Horn (high/low) is located inside of front bumper and operates when vehicle security system is in alarm phase.

FOR MEXICO : Description

Horn (high/low) is located inside of front bumper and operates when vehicle security system is in alarm phase.

1. Vehicle security indicator is built in combination meter.
2. NVIS/NATS and vehicle security system conditions are indicated by blink or illumination of vehicle security indicator.

HIGH FLASHER OPERATION

BCM detects the turn signal lamp circuit status by the current value.

BCM increases the turn signal lamp blinking speed if the bulb or harness open is detected with the turn signal lamp operating.

Note. The blinking speed is normal while activating the hazard warning lamp.

KEY WARNING LAMP (GREEN) ILLUMINATES : Description

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

KEY WARNING LAMP DOES NOT ILLUMINATE : Description

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

KEY WARNING LAMP (RED) ILLUMINATES : Description

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

OPERATION PROCEDURE

1. Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the "ACC" position. At this time, the steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-III.

1. Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the "ACC" position. At this time, the steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-III.

Identifying NATS Antenna Amp. And Steering Lock Assembly. Scheme 160

Scheme 161

1. Remove lower instrument panel (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-295100-S19847279492008081400000) ".
2. Remove the Intelligent Key unit mounting screw (A), and then remove Intelligent Key unit (1). NOTE: Perform the system initialization when replacing Intelligent Key unit. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: Special Repair Requirement»(ref-295136-S09062997692008081400000) ". see scheme 70: Identifying Intelligent Key Unit Mounting Screw And Intelligent Key Unit

Perform the system initialization when replacing BCM or ECM with a used parts or registering an additional ignition key.

Performing following procedure can automatically perform re-communication of ECM and BCM, but only when the ECM has been replaced with a new one (*1).

*1: New one means a virgin ECM which has never been energized on-board.

(In this step, initialization procedure by CONSULT-III is not necessary)

Note. When registering new Key IDs or replacing the ECM that is not brand new, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS. If multiple keys are attached to the key holder, separate them before work. Distinguish keys with unregistered key ID from those with registered ID.

COMPONENT REFERENCE CHART

Vehicle Security System - System Diagram. Scheme 162

When unlocking the door with the key or keyfob the alarm operation is canceled.

Check that the system is in the armed phase. (The security indicator lamp blinks every 2.4 seconds.)

When the following operation 1 or 2 is performed, the system sounds the horns and flashes the headlamps for approx. 50 seconds.

1. Any door is opened during armed phase.
2. Disconnecting and connecting the battery connector before canceling armed phase.

Remote keyless entry system may or may not operate vehicle security system (horn and headlamps) as required.

When the remote keyless entry system is triggered, ground is supplied intermittently to both headlamp relay and horn relay.

When headlamp relay and horn relay are energized, then power is supplied to headlamps (LH and RH) and horns (HIGH and LOW).

The headlamp flashes and the horn sounds intermittently.

The alarm automatically turns off after 50 seconds or when BCM receives any signal from keyfob.

Identifying Vehicle Security System Component Parts Location (1 Of 2). Scheme 163

Identifying Vehicle Security System Component Parts Location (2 Of 2). Scheme 164

COMPONENT REFERENCE CHART

CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Modern vehicle is equipped with many electronic control unit, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

CAN Communication Signal Chart. Refer to " CAN COMMUNICATION SIGNAL CHART ".

When the starting operation is carried more than 10 times consecutively under the following conditions, NVIS/NATS will shift to the mode which prevents the engine from being started.

1. Unregistered ignition key is used.
2. BCM or ECM's malfunctioning.

BCM performs the ID verification with ECM that allows the engine to start. BCM starts the communication with ECM if ignition switch is turned ON and starts the engine if the ID is OK. ECM prevents the engine from starting if the ID is not registered.

BCM performs the ID verification with ECM that allows the engine to start. BCM starts the communication with ECM if ignition switch is turned ON and starts the engine if the ID is OK. ECM prevents the engine from starting if the ID is not registered.

Performs ID verification through BCM and NATS antenna amplifier when ignition knob switch is pressed. Prohibits the release of steering lock or start of engine when an unregistered ID of ignition key is used.

Performs ID verification through BCM when ignition knob switch is pressed.

Prohibits the release of steering lock or start of engine when an unregistered ID of ignition key is used.

Detects door open/closed condition.

Horn (high/low) is located inside of front bumper and operates when vehicle security system is in alarm phase.

1. Vehicle security indicator is built in combination meter.
2. NVIS/NATS and vehicle security system conditions are indicated by blink or illumination of vehicle security indicator.

BCM detects the turn signal lamp circuit status by the current value.

BCM increases the turn signal lamp blinking speed if the bulb or harness open is detected with the turn signal lamp operating.

Note. The blinking speed is normal while activating the hazard warning lamp.

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".

Note. Before performing the diagnosis, check "Work Flow". Refer to " WORK FLOW ".
