Automatic Transmission: Other Nissan Rogue I

DETAILED FLOW

1. COLLECT THE INFORMATION FROM THE CUSTOMER Get the detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurred) using the diagnosis work sheet. Refer to " «DIAGNOSTIC WORK SHEET»(ref-295118-S23497347442008081400000) ". GO TO 2.
2. CHECK SYMPTOM 1 Check the following items based on the information obtained from the customer. Fail-safe. Refer to " «FAIL-SAFE»(ref-295118-S19664430032008081400000) ". CVT fluid inspection. Refer to " «INSPECTION»(ref-295118-S07522509662008081400000) ". Line pressure test. Refer to " «INSPECTION AND JUDGMENT»(ref-295118-S23661163012008081400000) ". Stall test. Refer to " «INSPECTION AND JUDGMENT»(ref-295118-S09989729472008081400000) ". GO TO 3.
3. CHECK DTC Check DTC. Perform the following procedure if DTC is detected. Record DTC. Erase DTC. Refer to " «DIAGNOSIS DESCRIPTION»(ref-295118-S30579587782008081400000) ". Is any DTC detected? YES: GO TO 4. NO: GO TO 5 .
4. PERFORM DIAGNOSTIC PROCEDURE Perform "Diagnostic Procedure" for the displayed DTC. GO TO 5.
5. PERFORM DTC CONFIRMATION PROCEDURE Perform "DTC CONFIRMATION PROCEDURE" for the displayed DTC. Is DTC detected? YES: GO TO 4 . NO: GO TO 6.
6. CHECK SYMPTOM 2 Confirm the symptom described by the customer. Is any malfunction present? YES: GO TO 7. NO: INSPECTION END
7. ROAD TEST Perform "ROAD TEST". Refer to " «DESCRIPTION»(ref-295118-S05075214042008081400000) ". GO TO 8.
8. CHECK SYMPTOM 3 Confirm the symptom described by the customer. Is any malfunction present? YES: GO TO 2 . NO: INSPECTION END

INFORMATION FROM CUSTOMER

KEY POINTS

Scheme 98

1. WHAT..... Vehicle & CVT model
2. WHEN..... Date, Frequencies
3. WHERE..... Road conditions
4. HOW..... Operating conditions, Symptoms (Scheme 98): Identifying Key Points

Diagnostic Work Sheet. Scheme 99

PATTERN A

1. Shift selector lever to "P" position after replacing TCM. Turn ignition switch ON.
2. Check that shift position indicator in the combination meter turns ON (It indicates approximately 1 or 2 seconds after turning ignition switch ON.) Check the following items if shift position indicator does not turn ON. Repair or replace shift position indicator if necessary. The harness between TCM and ROM ASSY in transaxle assembly is open or shorted. Cable disconnected, loose, or bent from connector housing.

PATTERN B

1. Turn ignition switch ON after replacing each part.
2. Start engine. CAUTION: Never start driving.
3. Select "DATA MONITOR".
4. Warm up transaxle assembly until "ATFTEMP COUNT" indicates 47 [approximately 20°C (68°F)] or more. Turn ignition switch OFF.
5. Turn ignition switch ON. CAUTION: Never start engine.
6. Select "SELF-DIAG RESULTS".
7. Shift selector lever to "R" position.
8. Depress slightly accelerator pedal (Pedal angle: 2/8) while depressing brake pedal.
9. Perform "ERASE".
10. Shift selector lever to "R" position after replacing TCM. Turn ignition switch OFF.
11. Wait approximately 10 seconds after turning ignition switch OFF.
12. Turn ignition switch ON while shifting selector lever to "R" position. CAUTION: Never start engine.
13. Select "Special function".
14. Check that the value on "CALIBRATION DATA" is the same as the data after erasing "Calibration Data". Restart the procedure from step 3 if the values are not the same.
15. Shift selector lever to "P" position.
16. Check that shift position indicator in combination meter turns ON. (It indicates approximately 1 or 2 seconds after shifting selector lever to "P" position.) Check the following items if shift position indicator does not turn ON. Repair or replace shift position indicator if necessary. The harness between TCM and ROM ASSY in transaxle assembly is open or shorted. Cable disconnected, loose, or bent from connector housing. Power supply and ground of TCM. Refer to " «DESCRIPTION»(ref-295118-S25526448492008081400000) ".

Calibration Data

Data after deletion

CALIBRATION DATA

PATTERN C

1. Replace transaxle assembly first, and then replace TCM.
2. Perform the service of "PATTERN A". (Perform the service of "PATTERN B" if TCM is replaced first.)

CVT System Diagram. Scheme 100

Identifying CVT System Components Location (Without Manual Mode). Scheme 101

Identifying CVT System Components Location (With Manual Mode). Scheme 102

Cross-Sectional View Of Mechanical System. Scheme 103

TCM FUNCTION

The function of the TCM is to

1. Receive input signals sent from various switches and sensors.
2. Determine required line pressure, shifting point, and lock-up operation.
3. Send required output signals to the step motor and the respective solenoids.

INPUT/OUTPUT SIGNAL CHART

INPUT/OUTPUT SIGNAL OF TCM

INPUT/OUTPUT SIGNAL CHART

"D" POSITION

Shifting over all the ranges of gear ratios from the lowest to the highest.

Gear Ratio Graph (D Position). Scheme 104

OVERDRIVE OFF CONDITION (WITHOUT MANUAL MODE)

Use this position for improved engine braking.

"L" POSITION (WITHOUT MANUAL MODE)

By limiting the gear range to the lowest position, the strong driving force and the engine brake can be secured.

Gear Ratio Graph (L Position). Scheme 105

"M" POSITION (WITH MANUAL MODE)

When the selector lever is put in the manual shift gate side, the fixed changing gear line is set. By moving the selector lever to + side or - side, the manual mode switch is changed over, and shift change like M/T becomes possible following the changing gear set line step by step.

Gear Ratio Graph (M Position). Scheme 106

DOWNHILL ENGINE BRAKE CONTROL (AUTO ENGINE BRAKE CONTROL)

When a downhill slope is detected with the accelerator pedal released, the engine brake will be strengthened up by downshifting so as not to accelerate the vehicle more than necessary.

ACCELERATION CONTROL

According to vehicle speed and a change of accelerator pedal angle, driver's request for acceleration and driving scene are judged. This function assists improvement in the acceleration feeling by making the engine speed proportionate to the vehicle speed. And a shift map that can gain a larger driving force is available for compatibility of mileage with driveability.

P POSITION HOLD MECHANISM (IGNITION SWITCH LOCK)

The shift lock solenoid (1) is not energized when the ignition switch is in any position other than ON. In this condition, the shift mechanism is locked and P position is held. The operation cannot be performed from P position if the brake pedal is depressed with the ignition switch ON when the operation system of shift lock solenoid is malfunctioning. However, the lock lever (A) is forcibly rotated and the shift lock is released when the shift lock release button (B) is pressed from above. Then the selector operation from P position can be performed.

Shift Lock Operation Diagram At P Position. Scheme 107

KEY LOCK MECHANISM

The key cannot be set to LOCK when the selector lever is not selected to P position. This prevents the key from being removed from the key cylinder.

Key Lock Status

The slider (A) in the key cylinder (B) is moved to the left side of the figure when the selector lever is in any position other than P position. The rotator (C) that rotates together with the key (D) cannot be rotated for this reason. The key cannot be removed from the key cylinder because it cannot be turned to LOCK (E).

Key Lock Mechanism - Key Lock Status. Scheme 108

Key Unlock Status

The slider (A) in the key cylinder (B) is moved to the right side of the figure when the selector lever is in P position and the finger is removed from the selector button. The rotator (C) can be rotated for this reason. The key (D) can be removed from the key cylinder because it can be turned to LOCK (E).

Key Lock Mechanism - Key Unlock Status. Scheme 109

Identifying Shift Lock System Components Location. Scheme 110

SHIFT LOCK

COMPONENTS FUNCTION REFERENCE

KEY LOCK

COMPONENTS FUNCTION REFERENCE

OBD-II FUNCTION

The ECM provides emission-related on board diagnostic (OBD-II) functions for the CVT system. One function is to receive a signal from the TCM used with OBD-related parts of the CVT system. The signal is sent to the ECM when a malfunction occurs in the corresponding OBD-related part. The other function is to indicate a diagnostic result by means of the MIL (Malfunction Indicator Lamp) on the instrument panel. Sensors, switches and solenoid valves are used as sensing elements.

The MIL automatically illuminates in "One or Two Trip Detection Logic" when a malfunction is sensed in relation to CVT system parts.

ONE OR TWO TRIP DETECTION LOGIC OF OBD-II

One Trip Detection Logic

If a malfunction is sensed during the first test drive, the MIL illuminates and the ECM memory stores the malfunction as a DTC. The TCM is not provided with such a memory function.

Two Trip Detection Logic

When a malfunction is sensed during the first test drive, it is stored in the ECM memory as a 1st trip DTC (diagnostic trouble code) or 1st trip freeze frame data. At this point, the MIL does not illuminate. - 1st trip If the same malfunction as that experienced during the first test drive is sensed during the second test drive, the MIL will illuminate. - 2nd trip

The "trip" in the "One or Two Trip Detection Logic" means a driving mode in which self-diagnosis is performed during vehicle operation.

MALFUNCTION INDICATOR LAMP (MIL)

Description

The MIL is located on the instrument panel.

Scheme 111

1. The MIL is turned ON when the ignition switch is turned ON without the engine running. This is a bulb check. If the MIL is not turned ON, refer to " «COMPONENT FUNCTION CHECK»(ref-295105-S03782486282008081400000) " (for California), " «COMPONENT FUNCTION CHECK»(ref-295106-S20293056142008081400000) " [for USA (federal) and Canada], " «COMPONENT FUNCTION CHECK»(ref-295107-S37522339592008081400000) " (for Mexico).
2. Turn OFF the MIL when the engine is started. If the MIL remains ON, the on board diagnostic system has detected an engine system malfunction. (Scheme 111): Identifying Malfunction Indicator Lamp

FUNCTION

CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.

DIAGNOSTIC TEST MODES FUNCTION REFERENCE

WORK SUPPORT MODE

Display Item List

DISPLAY ITEM LIST - WORK SUPPORT MODE

Engine Brake Adjustment

"ENGINE BRAKE LEVEL"

0 : Initial set value (Engine brake level control is activated)

OFF : Engine brake level control is deactivated.

Check CVT Fluid Deterioration Date

"CVTF DETERIORATION DATE"

More than 210000 : It is necessary to change CVT fluid.

Less than 210000 : It is not necessary to change CVT fluid.

DATA MONITOR MODE

Display Items List

DISPLAY ITEMS LIST - DATA MONITOR MODE

WITHOUT MANUAL MODE : Component Function Check

1. CHECK SHIFT POSITION INDICATOR CAUTION: Always drive vehicle at a safe speed. Start engine. Check that correct selector lever position ("P", "R", "N", "D", "L") is displayed as selector lever is moved into each position. Is the inspection result normal? YES: INSPECTION END NO: Go to " «WITHOUT MANUAL MODE : DIAGNOSIS PROCEDURE»(ref-295118-S19877424492008081400000) ".

WITH MANUAL MODE : Component Function Check

1. CHECK SHIFT POSITION INDICATOR CAUTION: Always drive vehicle at a safe speed. Start engine. Check that correct selector lever position ("P", "N", "R" or "D") is displayed as selector lever is moved into each position. Drive vehicle in the manual mode, and confirm that the actual gear position and the meter's indication of the position mutually coincide when the selector lever is shifted to the "UP (+ side)" or "DOWN (- side)" side (1st <=> 6th gear). Is the inspection result normal? YES: INSPECTION END NO: Go to " «WITH MANUAL MODE : DIAGNOSIS PROCEDURE»(ref-295118-S40598079482008081400000) ".

Component Function Check

1. CHECK CVT SHIFT LOCK OPERATION Turn ignition switch ON. Move selector lever to "P" position. Attempt to shift selector lever to any other position with brake pedal released. Can selector lever be shifted to any other position? YES: INSPECTION END NO: GO TO 2.
2. CHECK CVT SHIFT LOCK OPERATION Attempt to shift selector lever to any other position with brake pedal depressed. Can the selector lever be shifted to any other position? YES: INSPECTION END NO: Go to " «DIAGNOSIS PROCEDURE»(ref-295118-S16731532422008081400000) ".

1. CHECK OVERDRIVE CONTROL SWITCH SIGNAL Turn ignition switch ON. Select "DATA MONITOR". Check the ON/OFF operations of monitor item. MONITOR ITEMS CONDITION AND STATUS Monitor item Condition Status SPORT MODE SW While pushing overdrive control switch On Other conditions Off Is the inspection result normal? YES: INSPECTION END. NO: Go to " «DIAGNOSIS PROCEDURE»(ref-295118-S23854025482008081400000) ".

PHYSICAL VALUES

VOLTAGE SPECIFICATION

CVT Control System - Wiring Diagram (1 Of 2). Scheme 112

CVT Control System - Wiring Diagram (2 Of 2). Scheme 113

Identifying CVT Control System Connector Terminals (1 Of 3). Scheme 114

Identifying CVT Control System Connector Terminals (2 Of 3). Scheme 115

Identifying CVT Control System Connector Terminals (3 Of 3). Scheme 116

Fail-safe P

The TCM has an electrical fail-safe mode. In this mode TCM operates even if there is an error in a main electronic control input/output signal circuit.

FAIL-SAFE FUNCTION

If any malfunction occurs in a sensor or solenoid valve, this function controls the CVT to make driving possible.

Output Speed Sensor (Secondary Speed Sensor)

The shift pattern is changed in accordance with throttle position when an unexpected signal is sent from the output speed sensor (secondary speed sensor) to the TCM. The manual mode and overdrive control mode are inhibited, and the transaxle is put in "D".

Input Speed Sensor (Primary Speed Sensor)

The shift pattern is changed in accordance with throttle position and secondary speed (vehicle speed) when an unexpected signal is sent from the input speed sensor (primary speed sensor) to the TCM. The manual mode and overdrive control mode are inhibited, and the transaxle is put in "D".

PNP Switch

If an unexpected signal is sent from the PNP switch to the TCM, the transaxle is put in "D".

Manual Mode Switch

If an unexpected signal is sent from the manual mode switch to the TCM, the transaxle is put in "D".

CVT Fluid Temperature Sensor

If an unexpected signal is sent from the CVT fluid temperature sensor to the TCM, the gear ratio in use before receiving the unexpected signal is maintained or the gear ratio is controlled to keep engine speed under 5,000 rpm.

Transmission Fluid Pressure Sensor A (Secondary Pressure Sensor)

1. If an unexpected signal is sent from the transmission fluid pressure sensor A (secondary pressure sensor) to the TCM, the secondary pressure feedback control is stopped and the offset value obtained before the nonstandard condition occurs is used to control line pressure.
2. If transmission fluid pressure sensor A (secondary pressure sensor) error signal is input to TCM, secondary pressure feedback control stops, but line pressure is controlled normally.

Pressure Control Solenoid A (Line Pressure Solenoid Valve)

If an unexpected signal is sent from the solenoid valve to the TCM, the pressure control solenoid A (line pressure solenoid valve) is turned OFF to achieve the maximum fluid pressure.

Pressure Control Solenoid B (Secondary Pressure Solenoid Valve)

If an unexpected signal is sent from the solenoid valve to the TCM, the pressure control solenoid B (secondary pressure solenoid valve) is turned OFF to achieve the maximum fluid pressure.

Torque Converter Clutch Solenoid Valve

If an unexpected signal is sent from the solenoid valve to the TCM, the torque converter clutch solenoid valve is turned OFF to cancel the lock-up.

Step Motor

If an unexpected signal is sent from the step motor to the TCM, the step motor coil phases "A" through "D" are all turned OFF to hold the gear ratio used just before the non-standard condition occurred.

CVT Lock-up Select Solenoid Valve

If an unexpected signal is sent from the solenoid valve to the TCM, the CVT lock-up select solenoid valve is turned OFF to cancel the lock-up.

TCM Power Supply (Memory Back-up)

Transaxle assembly is protected by limiting the engine torque when the memory back-up power supply (for controlling) from the battery is not supplied to TCM. Normal status is restored when turning the ignition switch OFF to ON after the normal power supply.

FOR USA AND CANADA : Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS .

FOR USA AND CANADA : Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

Note. This Procedure is applied only to models with Intelligent Key system and NVIS/IVIS (NISSAN/INFINITI VEHICLE IMMOBILIZER SYSTEM - NATS). Remove and install all control units after disconnecting both battery cables with the ignition knob in the "LOCK" position. Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.

For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock mechanism is adopted on the key cylinder.

For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and steering wheel rotation will become impossible.

If steering wheel rotation is required when battery power is interrupted, follow the procedure below before starting the repair operation.

FOR USA AND CANADA : Precaution for Procedure without Cowl Top Cover

When performing the procedure after removing cowl top cover, cover the lower end of windshield with urethane, etc.

Identifying Windshield Precaution. Scheme 117

EEPROM ERASING PATTERNS

EEPROM ERASING REFERENCE

FOR USA AND CANADA : Precaution

Note. If any malfunction occurs in the RE0F10A model transaxle, replace the entire transaxle assembly.

Scheme 118

Scheme 119

Scheme 120

Scheme 121

1. Turn ignition switch OFF and disconnect negative battery cable before connecting or disconnecting the TCM harness connector. Because battery voltage is applied to TCM even if ignition switch is turned OFF. (Scheme 118): Disconnecting Negative Battery Terminal
2. When connecting or disconnecting pin connectors into or from TCM, do not damage pin terminals (bend or break). Check that there are not any bends or breaks on TCM pin terminal, when connecting pin connectors. (Scheme 119): Locating Damage Pin Terminals
3. Perform TCM input/output signal inspection and check whether TCM functions normally or not before replacing TCM. " «REFERENCE VALUE»(ref-295118-S17282534432008081400000) ". (Scheme 120): Precaution For Handling TCM
4. Perform "DTC Confirmation Procedure" after performing each TROUBLE DIAGNOSIS. If the repair is completed the DTC should not be displayed in the "DTC Confirmation Procedure".
5. Always use the specified brand of CVT fluid. Refer to " «FOR NORTH AMERICA: FLUIDS AND LUBRICANTS»(ref-295130-S34661417002008081400000) " (for north America), " «FOR MEXICO: FLUIDS AND LUBRICANTS»(ref-295130-S06898715472008081400000) " (for Mexico).
6. Use lint-free paper, not cloth rags, during work.
7. Dispose of the waste oil using the methods prescribed by law, ordinance, etc. after replacing the CVT fluid. (Scheme 121): Identifying Malfunction Indicator Lamp

FOR USA AND CANADA : ATFTEMP COUNT Conversion Table

ATFTEMP COUNT CONVERSION TABLE FOR USA AND CANADA

FOR MEXICO : Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS .

FOR MEXICO : Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

Note. This Procedure is applied only to models with Intelligent Key system and NVIS/IVIS (NISSAN/INFINITI VEHICLE IMMOBILIZER SYSTEM - NATS). Remove and install all control units after disconnecting both battery cables with the ignition knob in the "LOCK" position. Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.

For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock mechanism is adopted on the key cylinder.

For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and steering wheel rotation will become impossible.

If steering wheel rotation is required when battery power is interrupted, follow the procedure below before starting the repair operation.

FOR MEXICO : Precaution for Procedure without Cowl Top Cover

When performing the procedure after removing cowl top cover, cover the lower end of windshield with urethane, etc.

EEPROM ERASING REFERENCE

FOR MEXICO : Precaution

Note. If any malfunction occurs in the RE0F10A model transaxle, replace the entire transaxle assembly.

Scheme 122

1. Turn ignition switch OFF and disconnect negative battery cable before connecting or disconnecting the TCM harness connector. Because battery voltage is applied to TCM even if ignition switch is turned OFF. see scheme 60: Disconnecting Negative Battery Terminal
2. When connecting or disconnecting pin connectors into or from TCM, do not damage pin terminals (bend or break). Check that there are not any bends or breaks on TCM pin terminal, when connecting pin connectors. see scheme 61: Locating Damage Pin Terminals
3. Perform TCM input/output signal inspection and check whether TCM functions normally or not before replacing TCM. " «REFERENCE VALUE»(ref-295118-S17282534432008081400000) ". see scheme 62: Precaution For Handling TCM
4. Perform "DTC Confirmation Procedure" after performing each TROUBLE DIAGNOSIS. If the repair is completed the DTC should not be displayed in the "DTC Confirmation Procedure".
5. Always use the specified brand of CVT fluid. Refer to " «FOR NORTH AMERICA: FLUIDS AND LUBRICANTS»(ref-295130-S34661417002008081400000) " (for north America), " «FOR MEXICO: FLUIDS AND LUBRICANTS»(ref-295130-S06898715472008081400000) " (for Mexico).
6. Use lint-free paper, not cloth rags, during work.
7. Dispose of the waste oil using the methods prescribed by law, ordinance, etc. after replacing the CVT fluid. (Scheme 122): Identifying Malfunction Indicator Lamp

FOR MEXICO : ATFTEMP COUNT Conversion Table

ATFTEMP COUNT CONVERSION TABLE FOR MEXICO

Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

SPECIAL SERVICE TOOLS DESCRIPTION Tool number (Kent-Moore No.) Tool name Description - (OTC3492) Oil pressure gauge set Measuring line pressure

Scheme 123

Commercial Service Tools

COMMERCIAL SERVICE TOOLS DESCRIPTION Tool number Tool name Description Power tool Loosening nuts and bolts 31197CA000 Drive plate location guide 14 mm (0.55 in) dia. Installing transaxle assembly Drift 54 mm (2.13 in) dia. 47 mm (1.85 in) dia. Installing differential side oil seal Drift 70 mm (2.76 in) dia. 56 mm (2.20 in) dia. Installing side oil seal (transfer joint) Drift 65 mm (2.56 in) dia. 60 mm (2.36 in) dia. Installing converter housing oil seal

Scheme 124

Scheme 125

Changing

1. Remove drain plug from oil pan.
2. Remove drain plug gasket from drain plug.
3. Install drain plug gasket to drain plug CAUTION: Never reuse drain plug gasket.
4. Install drain plug to oil pan. Refer to " «EXPLODED VIEW»(ref-295118-S29873134952008081400000) ".
5. Fill CVT fluid from CVT fluid charging pipe to the specified level. CVT fluid : Refer to " «GENERAL SPECIFICATION»(ref-295118-S12151711392008081400000) ". Fluid capacity : Refer to " «GENERAL SPECIFICATION»(ref-295118-S12151711392008081400000) ". CAUTION: Use only Genuine NISSAN CVT Fluid NS-2. Never mix with other fluid. Using CVT fluid other than Genuine NISSAN CVT Fluid NS-2 will deteriorate in driveability and CVT durability, and may damage the CVT, which is not covered by the warranty. When filling CVT fluid, take care not to scatter heat generating parts such as exhaust. Sufficiently shake the container of CVT fluid before using. Delete CVT fluid deterioration date with CONSULT-III after changing CVT fluid. Refer to " «CONSULT-III FUNCTION (TRANSMISSION)»(ref-295118-S42129815212008081400000) ".
6. With the engine warmed up, drive the vehicle in an urban area. NOTE: When ambient temperature is 20°C (68°F), it takes about 10 minutes for the CVT fluid to warm up to 50 to 80°C (122 to 176°F).
7. Check CVT fluid level and condition.
8. Repeat steps 1 to 5 if CVT fluid has been contaminated.

Cleaning

Whenever an automatic transaxle is repaired, overhauled, or replaced, the CVT fluid cooler mounted in the radiator must be inspected and cleaned.

Metal debris and friction material, if present, can be trapped or be deposited in the CVT fluid cooler. This debris can contaminate the newly serviced CVT or, in severe cases, can block or restrict the flow of CVT fluid.

In either case, malfunction of the newly serviced CVT may occur.

Debris, if present, may deposit as CVT fluid enters the cooler inlet. It will be necessary to back flush the cooler through the cooler outlet in order to flush out any built up debris.

Scheme 126

Scheme 127

Scheme 128

1. Position an oil pan under the transaxle's inlet and outlet cooler hoses.
2. Identify the inlet and outlet fluid cooler hoses.
3. Disconnect the fluid cooler inlet and outlet rubber hoses from the steel cooler tubes or bypass valve. NOTE: Replace the cooler hoses if rubber material from the hose remains on the tube fitting.
4. Allow any CVT fluid that remains in the cooler hoses to drain into the oil pan. see scheme 69: Draining CVT Fluid Into Oil Pan
5. Insert the extension adapter hose of a can of Transmission Cooler Cleaner (Nissan P/N 999MP-AM006) into the cooler outlet hose. CAUTION: Wear safety glasses and rubber gloves when spraying the Transmission Cooler Cleaner. Spray Transmission Cooler Cleaner only with adequate ventilation. Avoid contact with eyes and skin. Do not breath vapors or spray mist.
6. Hold the hose and can as high as possible and spray Transmission Cooler Cleaner in a continuous stream into the cooler outlet hose until CVT fluid flows out of the cooler inlet hose for 5 seconds.
7. Insert the tip of an air gun into the end of the cooler outlet hose.
8. Wrap a shop rag around the air gun tip and end of the cooler outlet hose. see scheme 70: Inserting Extension Adapter Hose Of Transmission Cooler Cleaner Into Cooler Outlet Hose
9. Blow compressed air regulated to 5 to 9 kg/cm 2 (70 to 130 psi) through the cooler outlet hose for 10 seconds to force out any remaining CVT fluid.
10. Repeat steps 5 through 9 three additional times.
11. Position an oil pan under the banjo bolts that connect the CVT fluid cooler steel lines to the transaxle. see scheme 71: Blowing Compressed Air Into Cooler Outlet Hose
12. Remove the banjo bolts.
13. Flush each steel line from the cooler side back toward the transaxle by spraying Transmission Cooler Cleaner in a continuous stream for 5 seconds.
14. Blow compressed air regulated to 5 to 9 kg/cm 2 (70 to 130 psi) through each steel line from the cooler side back toward the transaxle for 10 seconds to force out any remaining CVT fluid.
15. Ensure all debris is removed from the steel cooler lines.
16. Ensure all debris is removed from the banjo bolts and fittings.
17. Perform "CVT FLUID COOLER DIAGNOSIS PROCEDURE".

JUDGMENT

STALL TEST JUDGMENT CHART

LINE PRESSURE TEST JUDGMENT CHART

CONSULT-III SETTING PROCEDURE

1. Using CONSULT-III, perform a cruise test and record the result.
2. Print the result and ensure that shifts and lock-ups take place as per Shift Schedule.

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch "MAIN SIGNALS" to set recording condition.
3. See "Numerical Display", "Barchart Display" or "Line Graph Display".
4. Touch "START".
5. When performing cruise test. Refer to " «CRUISE TEST»(ref-295118-S31713488572008081400000) ".
6. After finishing cruise test part, touch "RECORD".
7. Touch "STORE".
8. Touch "BACK".
9. Touch "DISPLAY".
10. Touch "PRINT".
11. Check the monitor data printed out.

Check before Engine Is Started

1. CHECK OD OFF INDICATOR LAMP Park vehicle on flat surface. Move selector lever to "P" position. Turn ignition switch OFF. Wait at least 5 seconds. Turn ignition switch ON. (Do not start engine.) Has OD OFF indicator lamp been turned ON for about 2 seconds? YES: Turn ignition switch OFF. Perform self-diagnosis and note NG items. Refer to " «DTC INDEX»(ref-295118-S03170427972008081400000) ". Go to " «CHECK AT IDLE»(ref-295118-S10317316202008081400000) ". NO: Stop "Road Test". Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ".

Check at Idle

1. CHECK STARTING THE ENGINE (PART 1) Park vehicle on flat surface. Move selector lever to "P" or "N" position. Turn ignition switch OFF. Turn ignition switch to "START" position. Is engine started? YES: GO TO 2. NO: Stop "Road Test". Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ".
2. CHECK STARTING THE ENGINE (PART 2) Without manual mode Turn ignition switch ON. Move selector lever to "D", "L" or "R" position. Turn ignition switch to "START" position. With manual mode Turn ignition switch ON. Move selector lever to "D", "M" or "R" position. Turn ignition switch to "START" position. Is engine started? YES: Stop "Road Test". Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". NO: GO TO 3.
3. CHECK "P" POSITION FUNCTION Move selector lever to "P" position. Turn ignition switch OFF. Release parking brake. Push vehicle forward or backward. Apply parking brake. Does vehicle move forward or backward? YES: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 4. NO: GO TO 4.
4. CHECK "N" POSITION FUNCTION Start engine. Move selector lever to "N" position. Release parking brake. Does vehicle move forward or backward? YES: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 5. NO: GO TO 5.
5. CHECK SHIFT SHOCK Apply foot brake. Move selector lever to "R" position. Is there large shock when changing from "N" to "R" position? YES: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 6. NO: GO TO 6.
6. CHECK "R" POSITION FUNCTION Release foot brake for several seconds. Does vehicle creep backward when foot brake is released? YES: GO TO 7. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 7.
7. CHECK "D" POSITION FUNCTION Without manual mode Move selector lever to "D" and "L" position and check if vehicle creeps forward. With manual mode Move selector lever to "D" position and check if vehicle creeps forward. Does vehicle creep forward in all positions? YES: Go to " «CRUISE TEST»(ref-295118-S31713488572008081400000) ". NO: Stop "Road Test". Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ".

Scheme 129

Scheme 130

1. CHECK VEHICLE SPEED WHEN SHIFTING GEARS (PART 1) Drive vehicle for approximately 10 minutes to warm engine oil and CVT fluid up to operating temperature. CVT fluid operating temperature: 50 - 80°C (122 - 176°F) Park vehicle on flat surface. Move selector lever to "P" position. Start engine. Move selector lever to "D" position. Accelerate vehicle at 2/8 throttle opening and check "Vehicle Speed When Shifting Gears". With CONSULT-III Read vehicle speed and engine speed. Refer to " «VEHICLE SPEED WHEN SHIFTING GEARS»(ref-295118-S31865214022008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 2. see scheme 85: Checking Vehicle Speed When Shifting Gears (Part 1)
2. CHECK VEHICLE SPEED WHEN SHIFTING GEARS (PART 2) Park vehicle on flat surface. Move selector lever to "D" position. Accelerate vehicle at 8/8 throttle opening and check "Vehicle Speed When Shifting Gears". With CONSULT-III Read vehicle speed and engine speed. Refer to " «VEHICLE SPEED WHEN SHIFTING GEARS»(ref-295118-S31865214022008081400000) ". Is the inspection result normal? YES-1 (Without manual mode): GO TO 3. YES-2 (With manual mode): GO TO 8. NO-1 (Without manual mode): Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 3. NO-2 (With manual mode): Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 8. see scheme 86: Checking Vehicle Speed When Shifting Gears (Part 2)
3. CHECK OVERDRIVE OFF CONDITION (PART 1) Park vehicle on flat surface. Push overdrive control switch. Accelerate vehicle at 2/8 throttle opening and check "Vehicle Speed When Shifting Gears". With CONSULT-III Read vehicle speed and engine speed. Refer to " «VEHICLE SPEED WHEN SHIFTING GEARS»(ref-295118-S31865214022008081400000) ". Is the inspection result normal? YES: GO TO 4. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 4. see scheme 87: Checking Vehicle Speed When Shifting Gears (Part 1)
4. CHECK OVERDRIVE OFF CONDITION (PART 2) Park vehicle on flat surface. Push overdrive control switch. Accelerate vehicle at 8/8 throttle opening and check "Vehicle Speed When Shifting Gears". With CONSULT-III Read vehicle speed and engine speed. Refer to " «VEHICLE SPEED WHEN SHIFTING GEARS»(ref-295118-S31865214022008081400000) ". Is the inspection result normal? YES: GO TO 5. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 5. (Scheme 129): Checking Vehicle Speed When Shifting Gears (Part 2)
5. CHECK "L" POSITION FUNCTION (PART 1) Park vehicle on flat surface. Move selector lever to "L" position. Accelerate vehicle at 2/8 throttle opening and check "Vehicle Speed When Shifting Gears". With CONSULT-III Read vehicle speed and engine speed. Refer to " «VEHICLE SPEED WHEN SHIFTING GEARS»(ref-295118-S31865214022008081400000) ". Is the inspection result normal? YES: GO TO 6. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 6. (Scheme 130): Checking Vehicle Speed When Shifting Gears (Part 1)
6. CHECK "L" POSITION FUNCTION (PART 2) Park vehicle on flat surface. Move selector lever to "L" position. Accelerate vehicle at 8/8 throttle opening and check "Vehicle Speed When Shifting Gears". With CONSULT-III Read vehicle speed and engine speed. Refer to " «VEHICLE SPEED WHEN SHIFTING GEARS»(ref-295118-S31865214022008081400000) ". Is the inspection result normal? YES: GO TO 7. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 7. see scheme 90: Checking Vehicle Speed When Shifting Gears (Part 2)
7. CHECK ENGINE BRAKE FUNCTION Check engine brake. Does engine braking effectively reduce vehicle speed in "L" position? YES: Stop the vehicle. Perform "SELF-DIAG RESULT" mode for "TRANSMISSION". NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". Then continue trouble diagnosis.
8. CHECK MANUAL MODE FUNCTION Move to manual mode from "D" position. Does it switch to manual mode? YES: GO TO 9. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 9.
9. CHECK SHIFT-UP FUNCTION During manual mode driving, is upshift from M1 --> M2 --> M3 --> M4 --> M5 --> M6 performed? With CONSULT-III Read gear position. Refer to " «CONSULT-III FUNCTION (TRANSMISSION)»(ref-295118-S42129815212008081400000) ". Is upshifting correctly performed? YES: GO TO 10. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 10.
10. CHECK SHIFT-DOWN FUNCTION During manual mode driving, is downshift from M6 --> M5 --> M4 --> M3 --> M2 --> M1 performed? With CONSULT-III Read gear position. Refer to " «CONSULT-III FUNCTION (TRANSMISSION)»(ref-295118-S42129815212008081400000) ". Is downshifting correctly performed? YES: GO TO 11. NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". GO TO 11.
11. CHECK ENGINE BRAKE FUNCTION Check engine brake. Does engine braking effectively reduce vehicle speed in M1 position? YES: Stop the vehicle. Perform "SELF-DIAG RESULT" mode for "TRANSMISSION". NO: Refer to " «SYMPTOM TABLE»(ref-295118-S33315709672008081400000) ". Then continue trouble diagnosis.

Scheme 131

1. Move selector lever to "P" position, and turn ignition switch ON (engine stop).
2. Check that selector lever can be shifted to other than "P" position when brake pedal is depressed. Also check that selector lever can be shifted from "P" position only when brake pedal is depressed.
3. Move selector lever and check for excessive effort, sticking, noise or rattle.
4. Check that selector lever stops at each position with the feel of engagement when it is moved through all the positions. Check that the actual position of selector lever matches the position shown by shift position indicator and manual lever on the transaxle.
5. The method of operating selector lever to individual positions correctly should be as shown.
6. When selector button is pressed in "P", "R", "N", "D" or "L" position without applying forward/backward force to selector lever, check button operation for sticking.
7. Check that back-up lamps illuminate only when selector lever is placed in the "R" position.
8. When in "R" position, check that back-up lamps do not illuminate even when the selector lever is in the "P" position. CAUTION: Check the lighting without pressing shift button. see scheme 91: Identifying Selector Lever Positions
9. Check that back-up lamps do not illuminate when selector lever is pushed toward the "R" position when in the "P" or "N" position. CAUTION: Check the lighting without pressing shift button.
10. Check that the engine can only be started with selector lever in the "P" and "N" positions.
11. Check that transaxle is locked completely in "P" position.

Scheme 132

1. Move selector lever to "P" position. CAUTION: Turn wheels more than 1/4 rotations and apply the park lock.
2. Loosen nut (A).
3. Place manual lever (B) to "P" position. CAUTION: Never apply any force to manual lever.
4. Tighten nut. Refer to " «EXPLODED VIEW»(ref-295118-S26156265452008081400000) ". CAUTION: Fix manual lever when tightening. see scheme 92: Identifying Manual Lever

Scheme 133

1. Move selector lever to "P" position, and turn ignition switch ON (engine stop).
2. Check that selector lever can be shifted to other than "P" position when brake pedal is depressed. Also check that selector lever can be shifted from "P" position only when brake pedal is depressed.
3. Move selector lever and check for excessive effort, sticking, noise or rattle.
4. Check that selector lever stops at each position with the feel of engagement when it is moved through all the positions. Check that the actual position of selector lever matches the position shown by shift position indicator and manual lever on the transaxle.
5. The method of operating selector lever to individual positions correctly should be as shown.
6. When selector button is pressed in "P", "R" or "N" position without applying forward/backward force to selector lever, check button operation for sticking.
7. Check that back-up lamps illuminate only when selector lever is placed in the "R" position.
8. When in "R" position, check that back-up lamps do not illuminate even when the selector lever is in the "P" position. CAUTION: Check the lighting without pressing shift button. see scheme 93: Identifying Selector Lever Position
9. Check that back-up lamps do not illuminate when selector lever is pushed toward the "R" position when in the "P" or "N" position. CAUTION: Check the lighting without pressing shift button.
10. Check that the engine can only be started with selector lever in the "P" and "N" positions.
11. Check that transaxle is locked completely in "P" position.
12. When selector lever is set to manual shift gate, check that manual mode is displayed on combination meter. Shift selector lever to "+" and "-" sides, and check that set shift position changes.

INSTALLTION

Note the following, and install in the reverse order of removal.

Note the following, and install in the reverse order of removal.

1. Drive each differential side oil seal evenly using a commercial service tool so that differential side oil seal protrudes by the dimension (A) or (B) respectively. DIFFERENTIAL SIDE OIL SEAL PROTRUDES DIMENSION SPECIFICATION Unit: mm (in) Dimension A (transaxle case side) 1.8 ± 0.5 (0.071 ± 0.020) Dimension B (converter housing side) 2.2 ± 0.5 (0.087 ± 0.020)

Note. Differential side oil seal pulling direction is used as the reference.

Identifying Differential Side Oil Seal Protrudes Dimension. Scheme 134

Drift to be used

COMMERCIAL SERVICE TOOL REFERENCE

Note the following, and install in the reverse order of removal.

1. Drive each differential side oil seal and side oil seal (transfer joint) evenly using a commercial service tool so that differential side oil seal and side oil seal (transfer joint) protrudes by the dimension (A), (B), or (C) respectively.

DIFFERENTIAL SIDE OIL SEAL PROTRUDES DIMENSION SPECIFICATION

Note. Differential side oil seal and side oil seal (transfer joint) pulling direction is used as the reference.

Drift to be used

COMMERCIAL SERVICE TOOL REFERENCE

Vehicle Speed When Shifting Gears

Numerical value data are reference values.

VEHICLE SPEED SPECIFICATION

Stall Speed

STALL SPEED SPECIFICATION

Line Pressure

LINE PRESSURE SPECIFICATION

Solenoid Valves

SOLENOID VALVES SPECIFICATION

Primary Speed Sensor

PRIMARY SPEED SENSOR SPECIFICATION

Secondary Speed Sensor

SECONDARY SPEED SENSOR SPECIFICATION
