Automatic Transmission: Adjustments Nissan Rogue I

Automatic Trans 7 illustrations ~409 words

ADJUSTMENT

  1. Move selector lever to "P" position. CAUTION: Turn wheels more than 1/4 rotations and apply the park lock.
  2. Loosen nut (A).
  3. Place manual lever (B) to "P" position. CAUTION: Never apply any force to manual lever.
  4. Tighten nut. Refer to " «EXPLODED VIEW»(ref-295118-S26156265452008081400000) ". CAUTION: Fix manual lever when tightening. see scheme 94: Identifying Manual Lever

Scheme 12

Fig. 95: Exploded View Of Transmission Control Module With Torque Specifications
Scheme 95: Exploded View Of Transmission Control Module With Torque Specifications

ADJUSTMENT AFTER INSTALLATION

After TCM is replaced. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SERVICE AFTER REPLACING TCM AND TRANSAXLE ASSEMBLY ".

Scheme 13

Fig. 97: Exploded View Of Control Device (Without Manual Mode) With Torque Specifications
Scheme 97: Exploded View Of Control Device (Without Manual Mode) With Torque Specifications

Scheme 14

Scheme 14: REMOVAL
Scheme 14: REMOVAL

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Disconnect the battery cable from the negative terminal.
  2. Move selector lever to "N" position.
  3. Slide knob cover (1) below selector lever downward. CAUTION: Be careful not to damage knob cover.
  4. Pull lock pin (2) out of selector lever knob (3).
  5. Remove selector lever knob and knob cover. (Scheme 12): Identifying Knob Cover, Lock Pin And Selector Lever Knob
  6. Remove knob fin (1) using a flat-bladed screwdriver (A). CAUTION: Be careful not to damage selector lever knob.
  7. Remove overdrive control switch (2).
  8. Remove center console assembly. Refer to " «EXPLODED VIEW»(ref-295100-S00523524042008081400000) ". see scheme 99: Removing Knob Fin Using Flat-Bladed Screwdriver
  9. Disconnect shift lock solenoid connector (A).
  10. Remove shift lock solenoid (1) using a feeler gauge (B). (Scheme 13): Removing Shift Lock Solenoid Using Feeler Gauge
  11. Disconnect control device connector (A).
  12. Move selector lever to "P" position.
  13. Remove key interlock cable (1) from control device assembly. Refer to " «EXPLODED VIEW»(ref-295118-S00169310212008081400000) ".
  14. Remove control cable (2) from control device assembly. Refer to " «EXPLODED VIEW»(ref-295118-S26156265452008081400000) ".
  15. Remove control device assembly. <--: Bolt (Scheme 14): Identifying Control Cable, Control Device Connector And Key Interlock Cable
  16. Remove position lamp.
  17. Unhook (<--) position indicator plate (1) for removal. Driver side Passenger side (Scheme 15): Identifying Position Indicator Plate

Adjust the CVT positions after installing control device. Refer to " WITHOUT MANUAL MODE : INSPECTION AND ADJUSTMENT ".

Adjust the CVT positions after installing control device. Refer to " WITH MANUAL MODE : INSPECTION AND ADJUSTMENT ".

Adjust the CVT positions after installing control cable. Refer to " WITHOUT MANUAL MODE : INSPECTION AND ADJUSTMENT " (without manual mode), " WITH MANUAL MODE : INSPECTION AND ADJUSTMENT " (with manual mode).

Adjust the CVT positions after installing control device. Refer to " WITHOUT MANUAL MODE : INSPECTION AND ADJUSTMENT " (without manual mode), " WITH MANUAL MODE : INSPECTION AND ADJUSTMENT " (with manual mode).
