Audio, Visual & Navigation System: Removal & Installation Nissan Rogue I

Antenna Systems 17 illustrations ~528 words

REMOVAL

  1. Remove cluster lid C and cluster lid D. Refer to " «EXPLODED VIEW»(ref-295100-S38104805562008081400000) ".
  2. Remove audio unit with bracket.
  3. Remove bracket screws, and then remove audio unit.

INSTALLATION

Install in the reverse order of removal.

Scheme 19

Scheme 19: Exploded View
Scheme 19: Exploded View
  1. Remove instrument panel. Refer to " «REMOVAL AND INSTALLATION»(ref-295100-S19847279492008081400000) ".
  2. Remove tweeter from instrument panel.

Installation is the reverse order of removal.

Scheme 20

Scheme 20: Exploded View
Scheme 20: Exploded View
  1. Remove front door finisher. Refer to " «FRONT DOOR FINISHER : REMOVAL AND INSTALLATION»(ref-295101-S09685986852008081400000) ".
  2. Remove front door speaker from bracket.

Install in the reverse order of removal.

Scheme 21

Scheme 21: Exploded View
Scheme 21: Exploded View
  1. Remove rear door finisher. Refer to " «REAR DOOR FINISHER : REMOVAL AND INSTALLATION»(ref-295101-S30798392352008081400000) ".
  2. Remove rear speaker.

Installation is the reverse order of removal.

Refer to " REMOVAL AND INSTALLATION ".

Installation is the reverse order of removal.

Scheme 22

Scheme 22: Exploded View
Scheme 22: Exploded View
  1. Remove headlining assembly. Refer to " «NORMAL ROOF : REMOVAL AND INSTALLATION»(ref-295101-S37003057162008081400000) " (normal roof models) or " «SUNROOF : REMOVAL AND INSTALLATION»(ref-295101-S32009175352008081400000) " (sunroof models).
  2. Remove nuts, and then remove radio antenna.

Installation is the reverse order of removal.

CAUTIONBe careful about tightening torque. Antenna sensitivity becomes poor, and when it is excessive, roof panel may be deformed, when roof antenna mounting nut tightening torque is loose.

Scheme 23

Scheme 23: Location of Antenna
Scheme 23: Location of Antenna
  1. Remove cluster lid C and cluster lid D. Refer to " «EXPLODED VIEW»(ref-295100-S38104805562008081400000) ".
  2. Remove audio unit with bracket.
  3. Remove bracket screws, and then remove audio unit.

Install in the reverse order of removal.

Scheme 24

Scheme 24: Exploded View
Scheme 24: Exploded View
  1. Remove luggage floor spacer assembly (FR, RH). Refer to " «REMOVAL AND INSTALLATION»(ref-295101-S24778847662008081400000) ".
  2. Remove BOSE amp.

Install in the reverse order of removal.

Scheme 25

Scheme 25: Exploded View
Scheme 25: Exploded View
  1. Remove instrument panel. Refer to " «REMOVAL AND INSTALLATION»(ref-295100-S19847279492008081400000) ".
  2. Remove tweeter from instrument panel.

Installation is the reverse order of removal.

Scheme 26

Scheme 26: Exploded View
Scheme 26: Exploded View
  1. Remove center speaker grille. Refer to " «EXPLODED VIEW»(ref-295100-S38104805562008081400000) ".
  2. Remove center speaker.

Installation is the reverse order of removal.

Scheme 27

Scheme 27: Exploded View
Scheme 27: Exploded View
  1. Remove front door finisher. Refer to " «FRONT DOOR FINISHER : REMOVAL AND INSTALLATION»(ref-295101-S09685986852008081400000) ".
  2. Remove front door speaker from bracket.

Install in the reverse order of removal.

Scheme 28

Scheme 28: Exploded View
Scheme 28: Exploded View
  1. Remove rear door finisher. Refer to " «REAR DOOR FINISHER : REMOVAL AND INSTALLATION»(ref-295101-S30798392352008081400000) ".
  2. Remove rear speaker.

Installation is the reverse order of removal.

Scheme 29

Scheme 29: Exploded View
Scheme 29: Exploded View
  1. Remove luggage floor center box. Refer to " «REMOVAL AND INSTALLATION»(ref-295101-S24778847662008081400000) ".
  2. Remove clamp, and then remove woofer.

Install in the reverse order of removal.

Scheme 30

Scheme 30: Exploded View
Scheme 30: Exploded View
  1. Remove luggage side lower finisher (LH). Refer to " «REMOVAL AND INSTALLATION»(ref-295101-S24778847662008081400000) ".
  2. Remove satellite radio tuner.

Install in the reverse order of removal.

Scheme 31

Scheme 31: Exploded View
Scheme 31: Exploded View
  1. Remove headlining assembly. Refer to " «NORMAL ROOF : REMOVAL AND INSTALLATION»(ref-295101-S37003057162008081400000) " (normal roof models) or " «SUNROOF : REMOVAL AND INSTALLATION»(ref-295101-S32009175352008081400000) " (sunroof models).
  2. Remove nuts, and then remove radio & satellite radio antenna.

Installation is the reverse order of removal.

CAUTIONBe careful about tightening torque. Antenna sensitivity becomes poor, and when it is excessive, roof panel may be deformed, when roof antenna mounting nut tightening torque is loose.

Refer to " REMOVAL AND INSTALLATION ".

Installation is the reverse order of removal.

Scheme 32

Scheme 32: Exploded View
Scheme 32: Exploded View
  1. Remove map lamp. Refer to " «REMOVAL AND INSTALLATION»(ref-295122-S23321511812008081400000) ".
  2. Remove microphone from map lamp.

Installation is the reverse order of removal.

Scheme 33

Scheme 33: Exploded View
Scheme 33: Exploded View
  1. Remove luggage side lower finisher (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-295101-S24778847662008081400000) ".
  2. Remove TEL adapter unit.

Install in the reverse order of removal.

Scheme 34

Scheme 34: Exploded View
Scheme 34: Exploded View
  1. Remove luggage side upper finisher (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-295101-S24778847662008081400000) ".
  2. Remove TEL antenna.

Scheme 35

Scheme 35: Location of Antenna
Scheme 35: Location of Antenna
