DETAILED FLOW
- CHECK SYMPTOM Check the malfunction symptoms by performing the following items. Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred). Check the symptom. GO TO 2.
- PERFORM DIAGNOSIS BY SYMPTOM Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to " «SYMPTOM TABLE»(ref-295145-S16447814362008081400000) ". GO TO 3.
- REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace the malfunctioning parts. GO TO 4.
- FINAL CHECK Perform the operation to check that the malfunction symptom is solved or any other symptoms are present. Is there any symptom? YES: GO TO 2 . NO: INSPECTION END
Scheme 36
AUDIO SYSTEM
| Audio functions |
|---|
| AM/FM radio |
| CD |
AUDIO SYSTEM REFERENCE
- Radio signal are received by radio antenna, next it is amplified by antenna amp., and finally it is input to audio unit. (Antenna amp. is built into radio antenna.)
- Audio unit outputs the audio signal to each speaker.
SPEED SENSITIVE VOLUME
- Volume level of this system gone up and down automatically in proportion to the vehicle speed.
- The control level can be selected by the customer.
Scheme 37
PHYSICAL VALUES
AUDIO UNIT PHYSICAL VALUES CHART Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 2 (R) 3 (G) Sound signal front LH Output Ignition switch ON Voice output 4 (V) 5 (LG) Sound signal rear LH Output Ignition switch ON Voice output 6 (W) 15 (GR) Steering switch signal A Input Ignition switch ON Keep pressing SOURCE switch 0 V Keep pressing SEEK UP switch 1.1 V Keep pressing VOL UP switch 2.2 V Except for above 3.3 V 7 (SB) Ground ACC power supply Input Ignition switch ACC - Battery voltage 11 (O) 12 (W) Sound signal front RH Output Ignition switch ON Voice output 13 (L) 14 (P) Sound signal rear RH Output Ignition switch ON Voice output 15 (GR) Ground Steering switch signal ground - Ignition switch ON - 0 V 16 (O) 15 (GR) Steering switch signal B Input Ignition switch ON Keep pressing POWER switch 0 V Keep pressing SEEK DOWN switch 1.1 V Keep pressing VOL DOWN switch 2.2 V Except for above 3.3 V 18 (L) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25MPH) NOTE: The maximum voltage varies depending on the specification (destination unit). 19 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 51 - Antenna signal Input - - - 52 Ground Antenna amp. ON signal Output Ignition switch ON - 12 V
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
| Symptoms | Check items | Possible malfunction location / Action to take |
|---|---|---|
| Audio sound is not heard. | No sound from all speakers. | Audio unit power supply and ground circuit. Refer to " AUDIO UNIT : Diagnosis Procedure ". |
| Sound is not heard only from the specific places. | Sound signal circuit of malfunctioning system. |
AUDIO SYSTEM SYMPTOM CHART
| Symptoms | Possible malfunction location / Action to take |
|---|---|
| All steering switches are not operated. | Steering switch signal ground circuit. Refer to " DIAGNOSIS PROCEDURE ". |
| Only specified switch cannot be operated. | Replace steering switch. |
| "SEEK UP", "VOL UP" and "SOURCE" switches are not operated. | Steering switch signal A circuit. Refer to " DIAGNOSIS PROCEDURE ". |
| "SEEK DOWN" "VOL DOWN" and "POWER" switches are not operated. | Steering switch signal B circuit. Refer to " DIAGNOSIS PROCEDURE ". |
STEERING SWITCH SYMPTOM CHART
- The majority of the audio malfunctions are the result of outside causes (bad CD, electromagnetic interference, etc.). Check the symptoms below to diagnose the malfunction.
- The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning. Check that noise is caused and/or changed by engine speed, ignition switch turned to each position, and operation of each piece of electrical equipment. Then determine the cause.
Note. CD-R is not guaranteed to play because they can contain compressed audio (MP3, WMA) or could be incorrectly mastered by the customer on a computer. (6CD models) Check that the CDs carry the Compact Disc Logo. If not, the disc is not mastered to the red book Compact Disc Standard and may not play.
| Symptoms | Cause and Counter measure |
|---|---|
| Cannot play | Check that the CD was inserted correctly. |
| Check that the CD is scratched or dirty. | |
| Check that there is condensation inside the player, and if there is, wait until the condensation is gone (about 1 hour) before using the player. | |
| The player will play correctly after it returns to the normal temperature if there is a temperature increase error. | |
| Only the music CD files (CD-DA data) will be played if there is a mixture of music CD files (CDDA data) and MP3/WMA files on a CD. (6CD models) | |
| Files with extensions other than ".MP3", ".WMA", ".mp3", or ".wma" cannot be played. (6CD models) | |
| Check that the finalization process, such as session close and disc close, is done for the disc. | |
| Check that the CD is protected by copyright. | |
| Poor sound quality | Check that the CD is scratched or dirty. |
| It takes a relatively long time before the music starts playing. | If there are many folder or file levels on the MP3/WMA CD, or if it is a multi session disc, some time may be required before the music starts playing. (6CD models) |
| The songs do not play back in the desired order. | The playback order is the order in which the files were written by the software, so the files might not play in the desired order. |
SYMPTOM CHART
Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise from trains and other sources, is not a malfunction.
Note. Fading noise: This noise occurs because of variations in the field strength in a narrow range due to mountains or buildings blocking the signal. Multi-path noise: This noise results from a time difference between the broadcast waves directly from the station arriving at the antenna and the waves reflected by mountains or buildings.
FOR USA AND CANADA : Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the " SRS AIRBAG " and " SEAT BELTS ".
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the " SRS AIRBAG ". Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
FOR MEXICO : Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. Information necessary to service the system safely is included in the " SRS AIRBAG " and " SEAT BELTS ".
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the " SRS AIRBAG ". Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this service information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
Commercial Service Tools
COMMERCIAL SERVICE TOOLS Tool name Description Power tool Loosening bolts and nuts
Scheme 44
Scheme 45
Exploded View
Refer to " EXPLODED VIEW ".
OVERALL SEQUENCE
Reference 1 ... Refer to " SYMPTOM TABLE ".
- CHECK SYMPTOM Check the malfunction symptoms by performing the following items. Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred). Check the symptom. GO TO 2.
- PERFORM DIAGNOSIS BY SYMPTOM Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to " «SYMPTOM TABLE»(ref-295145-S25423722982008081400000) ". GO TO 3.
- REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace the malfunctioning parts. GO TO 4.
- FINAL CHECK Perform the operation to check that the malfunction symptom is solved or any other symptoms are present. Is there any symptom? YES: GO TO 2 . NO: INSPECTION END
Scheme 46
| Audio functions |
|---|
| AM/FM radio |
| CD |
AUDIO SYSTEM REFERENCE
- Radio signal are received by radio antenna, next it is amplified by antenna amp., and finally it is input to audio unit. (Antenna amp. is built into radio antenna.)
- Audio unit outputs sound signal to BOSE amp. and BOSE amp. outputs to each speaker.
SATELLITE RADIO SYSTEM
- Radio signal are supplied to satellite radio tuner from the satellite antenna.
- The satellite radio tuner then sends sound signal to the audio unit.
- Audio unit outputs sound signal to BOSE amp. and BOSE amp. outputs to each speaker.
- Volume level of this system gone up and down automatically in proportion to the vehicle speed.
- The control level can be selected by the customer.
Scheme 47
PHYSICAL VALUES CHART Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (BR) Ground Amp. ON signal Output Ignition switch ON - 12 V 2 (R) 3 (G) Sound signal front LH Output Ignition switch ON Voice output 4 (V) 5 (LG) Sound signal rear LH Output Ignition switch ON Voice output 6 (W) 15 (GR) Steering switch signal A Input Ignition switch ON Keep pressing SOURCE switch 0 V Keep pressing SEEK UP switch 1.1 V Keep pressing VOL UP switch 2.2 V Except for above 3.3 V 7 (SB) Ground ACC power supply Input Ignition switch ACC - Battery voltage 10 - Shield - - - - 11 (O) 12 (W) Sound signal front RH Output Ignition switch ON Voice output 13 (L) 14 (P) Sound signal rear RH Output Ignition switch ON Voice output 15 (GR) Ground Steering switch signal ground - Ignition switch ON - 0 V 16 (O) 15 (GR) Steering switch signal B Input Ignition switch ON Keep pressing POWER switch (1) 0 V Keep pressing SEEK DOWN switch 1.1 V Keep pressing VOL DOWN switch 2.2 V Except for above 3.3 V 18 (L) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25MPH) NOTE: The maximum voltage varies depending on the specification (destination unit). 19 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 20 - shield - - - - 21 (L) - AV communication signal (H) - Input/Output - - 22 (P) - AV communication signal (L) - Input/Output - - 23 - Shield - - - - 25 - Shield - - - - 26 (BR) 27 (Y) Sound signal (Telephone voice, telephone guidance) Input Ignition switch ON Give a voice 28 (V) Ground Telephone ON signal Input Ignition switch ON While using hands-free phone system 0 V While not using hands-free phone system 5 V 32 (L) 31 (R) Satellite radio sound signal LH Input Ignition switch ON When satellite radio mode is selected 34 (W) 33 (G) Satellite radio sound signal RH Input Ignition switch ON When satellite radio mode is selected 35 - Shield - - - - 36 - Shield - - - - 38 (Y) Ground Request signal (SAT TO AUDIO) Input Ignition switch ON When satellite radio mode is selected 39 (B) Ground Communication signal (SAT-AUDIO) Input Ignition switch ON When satellite radio mode is selected 40 (L) Ground Communication signal (AUDIO-SAT) Output Ignition switch ON When satellite radio mode is selected 51 - Antenna signal Input - - - 52 Ground Antenna amp. ON signal Output Ignition switch ON - 12 V (1) : Without telephone system
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
PHYSICAL VALUES CHART Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (L) 10 (R) Sound signal rear speaker LH Output Ignition switch ON Voice output 2 (GR) 3 (Y) Sound signal rear speaker RH Output Ignition switch ON Voice output 4 (B) 5 (P) Sound signal front speaker LH Output Ignition switch ON Voice output 6 (BR) 7 (GR) Sound signal tweeter LH Output Ignition switch ON Voice output 8 (G) 13 (R) Sound signal front speaker RH Output Ignition switch ON Voice output 9 (Y) 14 (BR) Sound signal woofer Output Ignition switch ON Voice output 11 (W) Ground Battery power supply Input Ignition switch OFF - Battery voltage 12 (B) Ground Ground - Ignition switch ON - 0 V 15 (V) 28 (O) Sound signal center speaker Output Ignition switch ON Voice output 18 (R) 32 (G) Sound signal front LH Input Ignition switch ON Voice output 19 (O) 20 (W) Sound signal front RH Input Ignition switch ON Voice output 21 (V) 22 (LG) Sound signal rear LH Input Ignition switch ON Voice output 23 (W) 33 (R) Sound signal rear RH Input Ignition switch ON Voice output 25 (G) Ground Woofer Amp. ON signal Output Ignition switch ACC - 12 V 31 (L) Ground Amp. ON signal Input Ignition switch ACC - 12 V 37 (O) 27 (W) Sound signal tweeter RH Output Ignition switch ON Voice output
Scheme 60
PHYSICAL VALUES CHART Terminal Description Condition Reference value (Approx.) + - Signal name Input/Output 2 (L) 1 (R) Satellite radio sound signal LH Output Ignition switch ON When satellite radio mode is selected 4 (W) 3 (G) Satellite radio sound signal RH Output Ignition switch ON When satellite radio mode is selected 5 - Shield - - - - 6 - Shield - - - - 8 (Y) Ground Request signal (SAT TO AUDIO) Output Ignition switch ON When satellite radio mode is selected 9 (G) Ground Communication signal (SAT-AUDIO) Output Ignition switch ON When satellite radio mode is selected 10 (L) Ground Communication signal (AUDIO-->SAT) Input Ignition switch ON When satellite radio mode is selected 12 (BR) Ground Battery power supply Input Ignition switch OFF - Battery voltage 16 (SB) Ground ACC power supply Input Ignition switch ACC - Battery voltage 31 - Satellite antenna Input
Scheme 61
Scheme 62
Scheme 63
Scheme 64
| Symptoms | Check items | Possible malfunction location / Action to take |
|---|---|---|
| Audio sound is not heard. | No sound from all speakers. | Audio unit power supply and ground circuit. Refer to " AUDIO UNIT : Diagnosis Procedure ". BOSE amp. power supply and ground circuit. Refer to " BOSE AMP. : Diagnosis Procedure ". Amp. ON signal circuit. Refer to " DIAGNOSIS PROCEDURE ". |
| Sound is not heard from woofer. | Sound signal woofer circuit Woofer amp. ON signal circuit. Refer to " DIAGNOSIS PROCEDURE ". | |
| Sound is not heard only from the specific places. | Sound signal circuit of malfunctioning system. | |
| Satellite radio is not received. | When "RADIO" switch is pressed, it change to satellite radio mode. | Satellite radio sound signal circuit Satellite radio antenna |
| When "RADIO" switch is pressed, it does not change to satellite radio mode. | Satellite radio tuner power supply and ground circuit. Refer to " SATELLITE RADIO TUNER : Diagnosis Procedure ". Request signal circuit. Refer to " DIAGNOSIS PROCEDURE ". Communication circuit between audio unit and satellite radio tuner. Refer to " DIAGNOSIS PROCEDURE ". |
AUDIO SYSTEM SYMPTOMS CHART
Scheme 65
- Check that the cellular phone is corresponding type (Bluetooth® enabled) when the hands-free related malfunction vehicle is in service before performing a diagnosis.
- There is a case that malfunction occurs due to the version change of the phone type, etc. even though it is a corresponding type. Therefore, confirm it by changing the cellular phone to another corresponding type phone, and check that it operates normally. It is necessary to distinguish whether the cause is the vehicle or cellular phone. Check to ensure the customer's phone is supported by checking the phone compatibility for the hands-free system.
Simple check for Bluetooth® communication
If cellular phone and TEL adapter unit cannot be connected with Bluetooth® communication, following procedure allows the technician to judge which device has malfunction.
- Turn on a cellular phone, not connecting Bluetooth® communication.
- Start CONSULT-III, then start Windows®.
- Set CONSULT-III near a cellular phone.
- When operated Bluetooth® registration by cellular phone, check if CONSULT-III* would be displayed on the device name. (If other Bluetooth® device is located near cellular phone, a name of the device would be displayed also.) NOTE: *:Displayed device name is "NISSAN-********".
Scheme 66
- If no device name is displayed, cellular phone is malfunction. Repair the cellular phone first, then perform diagnosis.
- If CONSULT-III is displayed on device name, cellular phone is normal. Perform diagnosis as per the following table.
Trouble diagnosis chart by symptom
| Symptoms | Check items | Possible malfunction location/Action to take |
|---|---|---|
| Does not recognize cellular phone connection. | Repeat the registration of cellular phone. | TEL adapter unit |
| Hands-free phone cannot be established. | Both the reception and the speech cannot be performed. Audio cannot be operated by steering switch. | TEL adapter unit power supply and ground circuit. Refer to " TEL ADAPTER UNIT : Diagnosis Procedure ". |
| Both the reception and the speech cannot be performed. Audio can be operated by steering switch. | Telephone ON signal circuit. Refer to " DIAGNOSIS PROCEDURE ". | |
| The other party's voice cannot be heard by hands-free phone. | Audio system sound is normal. | Sound signal (telephone voice, telephone guidance) circuit |
| Audio system sound does not sound. | Refer to " SYMPTOM TABLE ". | |
| Originating sound is not heard by the other party with handsfree phone communication. | Sound operation function is normal. | TEL adapter unit |
| Sound operation function does not work. | Microphone signal circuit. Refer to " DIAGNOSIS PROCEDURE ". | |
| When hands-free phone is in use, the information (connection time etc.) is not displayed on the audio screen. | AV communication signal (H, L) |
SYMPTOM CHART
Scheme 67
- The majority of the audio malfunctions are the result of outside causes (bad CD, electromagnetic interference, etc.). Check the symptoms below to diagnose the malfunction.
- The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning. Check that noise is caused and/or changed by engine speed, ignition switch turned to each position, and operation of each piece of electrical equipment. Then determine the cause.
Note. CD-R is not guaranteed to play because they can contain compressed audio (MP3, WMA) or could be incorrectly mastered by the customer on a computer. Check that the CDs carry the Compact Disc Logo. If not, the disc is not mastered to the red book Compact Disc Standard and may not play.
| Symptoms | Cause and Counter measure |
|---|---|
| Cannot play | Check that the CD was inserted correctly. |
| Check that the CD is scratched or dirty. | |
| Check that there is condensation inside the player, and if there is, wait until the condensation is gone (about 1 hour) before using the player. | |
| The player will play correctly after it returns to the normal temperature if there is a temperature increase error. | |
| Only the music CD files (CD-DA data) will be played if there is a mixture of music CD files (CDDA data) and MP3/WMA files on a CD. | |
| Files with extensions other than ".MP3", ".WMA", ".mp3", or ".wma" cannot be played. | |
| Check that the finalization process, such as session close and disc close, is done for the disc. | |
| Check that the CD is protected by copyright. | |
| Poor sound quality | Check that the CD is scratched or dirty. |
| It takes a relatively long time before the music starts playing. | If there are many folder or file levels on the MP3/WMA CD, or if it is a multi session disc, some time may be required before the music starts playing. |
| The songs do not play back in the desired order. | The playback order is the order in which the files were written by the software, so the files might not play in the desired order. |
SYMPTOM CHART
Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise from trains and other sources, is not a malfunction.
Note. Fading noise: This noise occurs because of variations in the field strength in a narrow range due to mountains or buildings blocking the signal. Multi-path noise: This noise results from a time difference between the broadcast waves directly from the station arriving at the antenna and the waves reflected by mountains or buildings.
| Symptom | Possible cause | Possible solution |
|---|---|---|
| The voice on the other side is difficult to be heard. The voice is difficult to reach the other side of the connection. | The interior of the vehicle is too noisy. | Close the windows or have other occupants be quiet. |
| The volume of the voice is too low. | Speak louder. | |
| Pronunciation is unclear. | Speak clearly. |
TELEPHONE SYMPTOMS CHART
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the " SRS AIRBAG " and " SEAT BELTS ".
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the " SRS AIRBAG ". Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. Information necessary to service the system safely is included in the " SRS AIRBAG " and " SEAT BELTS ".
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the " SRS AIRBAG ". Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
COMMERCIAL SERVICE TOOLS Tool name Description Power tool Loosening bolts and nuts
Scheme 68
Refer to " EXPLODED VIEW ".
