Scheme 36
- When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
- For vehicles with 2 batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
- After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.
Scheme 37
| Component | Function | |
|---|---|---|
| 1. | ABS actuator and electric unit (control unit) | Transmits the vehicle speed signal to the combination meter via CAN communication. Refer to " COMPONENT PARTS LOCATION " for detailed installation location. |
| 2. | Parking brake switch | Transmits the parking brake switch signal to the combination meter. |
| 3. | BCM | Based on the signals received from various units and switches, transmits the buzzer output signal to the combination meter via CAN communication. Refer to " BODY CONTROL SYSTEM: COMPONENT PARTS LOCATION " for detailed installation location. |
| 4. | Combination meter | Receives a buzzer output signal from the BCM with CAN communication line and sounds the buzzer. Judges whether the parking brake is released from the vehicle speed signal received from the ABS actuator and electric unit (control unit) with CAN communication line and the parking brake switch signal from the parking brake switch, and sounds the buzzer if necessary. |
| 5. | Seat belt buckle switch (driver side) | Transmits the seat belt buckle switch signal (driver side) to the combination meter. |
Combination Meter
The buzzer (1) for the warning chime system is integrated in the combination meter.
Scheme 38
Scheme 39
COMBINATION METER INPUT/OUTPUT SIGNAL (CAN COMMUNICATION SIGNAL)
| Signal name | Transmit unit |
|---|---|
| Vehicle speed signal | ABS actuator and electric unit (control unit) |
| Buzzer output signal | BCM |
INPUT SIGNAL DESCRIPTION
| Signal name | Reception unit |
|---|---|
| Vehicle speed signal | BCM |
OUTPUT SIGNAL DESCRIPTION
BCM INPUT/OUTPUT SIGNAL (CAN COMMUNICATION SIGNAL)
| Signal name | Transmit unit |
|---|---|
| Vehicle speed signal | Combination meter |
INPUT SIGNAL DESCRIPTION
| Signal name | Reception unit |
|---|---|
| Buzzer output signal | Combination meter |
OUTPUT SIGNAL DESCRIPTION
The combination meter sounds the alarm buzzer installed in the combination meter when receiving the buzzer output signal transmitted from each unit.
BCM
BCM receives signals from various units and transmits a buzzer output signal to the combination meter via CAN communication if it judges that the warning buzzer should be activated.
WARNING CHIME FUNCTION LIST
| Warning functions | Out line | Warning judgment unit | Refer to |
|---|---|---|---|
| Light reminder warning chime | The warning chime sounds when the ignition switch is in OFF or ACC position with the combination switch (lighting switch) in the 1st or 2nd position and the driver side door open. | BCM | " LIGHT REMINDER WARNING CHIME: SYSTEM DESCRIPTION " |
| Front fog light reminder warning chime | The warning chime sounds when the ignition switch is turned to LOCK, OFF or ACC position from ON position, with combination switch (lighting switch) is in AUTO position and the front fog lamp switch in ON position. | BCM | " FRONT FOG LIGHT REMINDER WARNING CHIME: SYSTEM DESCRIPTION " |
| Seat belt warning chime | The warning chime sounds when the driver seat belt is unfastened with the ignition switch in ON position. | BCM | " SEAT BELT WARNING CHIME: SYSTEM DESCRIPTION " |
| Parking brake release warning chime | The warning chime sounds when the ignition switch is in ON position with the parking brake in operation and the vehicle speed 7 km/h (4.3 MPH) or more. | Combination meter | " PARKING BRAKE RELEASE WARNING CHIME: SYSTEM DESCRIPTION " |
Scheme 40
The combination meter activates the fail-safe control if CAN communication with each unit is malfunctioning.
| Function | Specifications |
|---|---|
| Buzzer | The buzzer turns OFF by suspending communication. |
Scheme 41
WARNING CHIME CANCEL CONDITIONS
Warning is canceled if any of the following conditions is fulfilled.
| Operation conditions | |
|---|---|
| Ignition switch | ON |
| Combination switch (Lighting switch) | OFF or AUTO position |
| Driver side door | Close [front door switch (driver side) OFF] |
SIGNAL PATH
- BCM requires warning chime output to combination meter when it judges light reminder warning chime is necessary from signals below. Signal name Signal source Ignition switch signal - Combination switch signal Combination switch (Lighting switch) ==> BCM Driver door switch signal Front door switch (driver side) ==> BCM
- Combination meter sounds integrated buzzer, following the warning chime output requirement (below signal) from BCM. Signal name Signal source Buzzer output signal BCM ==> Combination meter via CAN Communication Line
Scheme 42
Scheme 43
- BCM requires warning chime output to combination meter when it judges front fog light reminder warning chime is necessary from signals below. Signal name Signal source Ignition switch signal - Combination switch signal Combination switch (Lighting switch) ==> BCM
- Combination meter sounds integrated buzzer, following the warning chime output requirement (below signal) from BCM. Signal name Signal source Buzzer output signal BCM ==> Combination meter via CAN Communication Line
Scheme 44
Scheme 45
WARNING CANCEL CONDITIONS
Warning is canceled if any of the following conditions is fulfilled.
| Operation conditions | |
|---|---|
| Ignition switch | OFF |
| Seat belt (driver side) | Fastened (driver side seat belt buckle switch OFF) |
| 6 seconds after the start of warning sound | |
- BCM requires warning chime output to combination meter when it judges seat belt warning chime is necessary from signals below. Signal name Signal source Ignition switch signal - Seat belt buckle switch signal (driver side) Seat belt buckle switch (driver side) ==> Combination meter ==> BCM via CAN Communication Line
- Combination meter sounds integrated buzzer, following the warning chime output requirement (below signal) from BCM. Signal name Signal source Buzzer output signal BCM ==> Combination meter via CAN Communication Line
Scheme 46
Scheme 47
Scheme 48
Warning is canceled if any of the following conditions are fulfilled.
| Operation conditions | |
|---|---|
| Ignition switch | OFF |
| Parking brake | Release condition (parking brake switch OFF) |
| Vehicle speed | Approximately 3 km/h (1.9 MPH) or less |
Combination meter sounds integrated buzzer when it judges that parking brake release warning chime is necessary from signals below.
| Signal name | Signal source |
|---|---|
| Ignition switch signal | |
| Parking brake switch signal | Parking brake switch ==> Combination meter |
| Vehicle speed signal | ABS actuator and electric unit (control unit) ==> Combination meter via CAN Communication Line |
Scheme 49
Scheme 50
SELF DIAG RESULT
Refer to " DTC INDEX ".
DATA MONITOR
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
Display Item List
| X: Applicable | ||
|---|---|---|
| Display item [Unit] | MAIN SIGNALS | Description |
| SPEED METER [km/h] | X | Value of vehicle speed signal received from ABS actuator and electric unit (control unit) via CAN communication. NOTE: 655.35 is displayed when the malfunction signal is received. |
| SPEED OUTPUT [km/h] | X | Vehicle speed signal value transmitted to other units via CAN communication. NOTE: 655.35 is displayed when the malfunction signal is received. |
| ODO OUTPUT [km/h or mph] | Odometer signal value transmitted to other units via CAN communication. | |
| TACHO METER [rpm] | X | Value of the engine speed signal received from ECM via CAN communication. NOTE: 8191.875 is displayed when the malfunction signal is received. |
| FUEL METER [L] | X | Fuel level indicated on combination meter. |
| W TEMP METER [°C] | X | Value of engine coolant temperature signal is received from ECM via CAN communication. NOTE: 215 is displayed when the malfunction signal is input. |
| ABS W/L [On/Off] | Status of ABS warning lamp detected from ABS warning lamp signal is received from ABS actuator and electric unit (control unit) via CAN communication. | |
| VDC/TCS IND [On/Off] | Status of VDC OFF indicator lamp detected from VDC OFF indicator lamp signal is received from ABS actuator and electric unit (control unit) via CAN communication. | |
| SLIP IND [On/Off] | Status of VDC warning lamp detected from VDC warning lamp signal received from ABS actuator and electric unit (control unit) via CAN communication. | |
| BRAKE W/L [On/Off] | Status of brake warning lamp detected from brake warning lamp signal is received from ABS actuator and electric unit (control unit) via CAN communication. NOTE: Displays "Off" if the brake warning lamp is illuminated when the valve check starts, the parking brake switch is turned ON or the brake fluid level switch is turned ON. | |
| DOOR W/L [On/Off] | Status of door open warning detected from door switch signal received from BCM via CAN communication. | |
| HI-BEAM IND [On/Off] | Status of high beam indicator lamp detected from high beam request signal is received from BCM via CAN communication. | |
| TURN IND [On/Off] | Status of turn indicator lamp detected from turn indicator signal is received from BCM via CAN communication. | |
| LIGHT IND [On/Off] | Status of position lamp indicator lamp detected from dimmer signal is received from BCM via CAN communication. (For USA) Status of position lamp indicator lamp detected from position light request signal is received from BCM via CAN communication. (For Canada) | |
| OIL W/L [On/Off] | Status of oil pressure warning lamp detected from oil pressure switch signal is received from BCM via CAN communication. | |
| MIL [On/Off] | Status of malfunction indicator lamp detected from malfunctioning indicator lamp signal is received from ECM via CAN communication. | |
| CRUISE IND [On/Off] | Status of CRUISE indicator detected from ASCD status signal is received from ECM via CAN communication. | |
| SET IND [Off] | This item is displayed, but cannot be monitored. | |
| CRUISE W/L [Off] | This item is displayed, but cannot be monitored. | |
| BA W/L [Off] | This item is displayed, but cannot be monitored. | |
| O/D OFF IND [On/Off] | Status of O/D OFF indicator detected from O/D OFF indicator signal is received from CVT shift selector. | |
| 4WD W/L [Off] | This item is displayed, but cannot be monitored. | |
| 4WD LOCK IND [Off] | This item is displayed, but cannot be monitored. | |
| FUEL W/L [On/Off] | Low fuel warning status detected by the identified fuel level. | |
| WASHER W/L [On/Off] | Status of low washer fluid warning judged from washer level switch input to combination meter. | |
| AIR PRES W/L [On/Off] | Status of low tire pressure warning lamp judged from TPMS malfunction warning lamp signal received from BCM with CAN communication line. | |
| KEY G/Y W/L [On/Off] | Status of Intelligent Key system malfunction detected from Intelligent Key warning display signal is received from BCM via CAN communication. | |
| EPS W/L [On/Off] | Status of EPS warning lamp judged from EPS warning lamp signal received from EPS control unit with CAN communication line. | |
| AFS OFF IND [Off] | This item is displayed, but cannot be monitored. | |
| ECO MODE IND [Off] | This item is displayed, but cannot be monitored. | |
| LCD [B & P N, B & P I, ID NG, ROTAT, SFT P, INSRT, BATT, NO KY, OUTKY, LK WN, KY>PSW, Off] | Displays status of Intelligent Key system warning judged from meter display signal received from BCM with CAN communication line. | |
| ACC TARGET [Off] | This item is displayed, but cannot be monitored. | |
| ACC DISTANCE [Off] | This item is displayed, but cannot be monitored. | |
| ACC OWN VHL [Off] | This item is displayed, but cannot be monitored. | |
| ACC SET SPEED [Off] | This item is displayed, but cannot be monitored. | |
| ACC UNIT [Off] | This item is displayed, but cannot be monitored. | |
| SHIFT IND [P, R, N, D, L] | Status of shift position indicator judged from shift position signal received from TCM with CAN communication line. | |
| BSW IND [Off] | This item is displayed, but cannot be monitored. | |
| BSW W/L [On/Off] | Status of BSW warning lamp judged from BSW warning lamp signal received from camera control unit via CAN communication. | |
| FUEL CAP W/L [On/Off] | Status of fuel filler cap warning detected from fuel filler cap warning display signal is received from ECM via CAN communication. | |
| O/D OFF SW [On/Off] | Status of overdrive control switch. | |
| M RANGE SW [Off] | This item is displayed, but cannot be monitored. | |
| NM RANGE SW [Off] | This item is displayed, but cannot be monitored. | |
| AT SFT UP SW [Off] | This item is displayed, but cannot be monitored. | |
| AT SFT DWN SW [Off] | This item is displayed, but cannot be monitored. | |
| COMP F/B SIG [On/Off] | A/C compressor activation condition that ECM judges according to the water temperature and the acceleration degree. | |
| PKB SW [On/Off] | Status of parking brake switch. | |
| BUCKLE SW [On/Off] | Status of seat belt buckle switch (driver side). | |
| BRAKE OIL SW [On/Off] | Status of brake fluid level switch. | |
| A/C AMP CONN [On/Off] | Status of A/C auto amp. connection recognition signal. | |
| ENTER SW [On/Off] | Status of [] (ENTER) switch. | |
| SELECT SW [On/Off] | Status of • (SELECT) switch. | |
| ECO MODE SW [Off] | This item is displayed, but cannot be monitored. | |
| DISTANCE [km] | Value of distance to empty calculated by combination meter. | |
| OUTSIDE TEMP [°C or °F] | Ambient temperature value converted from ambient sensor signal received from ambient sensor. NOTE: This may not match with the temperature value indicated on the information display. (Because the information display value is a corrected value from the ambient sensor input value.) | |
| FUEL LOW SIG [On/Off] | Status of fuel level low warning signal to output to AV control unit via CAN communication. | |
| BUZZER [On/Off] | X | Buzzer status (in the combination meter) is detected from the buzzer output signal received from each unit via CAN communication and the warning output condition of the combination meter. |
| TPMS PRESS L [On/Off] | Status of low tire pressure warning judged from low tire pressure warning lamp signal received from BCM with CAN communication line. | |
| 4WD AUTO IND [Off] | This item is displayed, but cannot be monitored. | |
| NOTE: Some items are not available according to vehicle specification. | ||
| NOTE |
|---|
| 655.35 is displayed when the malfunction signal is received. |
| NOTE |
|---|
| 655.35 is displayed when the malfunction signal is received. |
| NOTE |
|---|
| 8191.875 is displayed when the malfunction signal is received. |
| NOTE |
|---|
| 215 is displayed when the malfunction signal is input. |
| NOTE |
|---|
| Displays "Off" if the brake warning lamp is illuminated when the valve check starts, the parking brake switch is turned ON or the brake fluid level switch is turned ON. |
| NOTE |
|---|
| This may not match with the temperature value indicated on the information display. (Because the information display value is a corrected value from the ambient sensor input value.) |
| NOTE |
|---|
| Some items are not available according to vehicle specification. |
Warning History
- Stores histories when warning/indicator lamp is turned on.
- "Warning History" indicates the "TIME" when the warning/indicator lamp is turned on.
- The "TIME" above is: 0: The condition that the warning/indicator lamp has been turned on 1 or more times after starting the engine and waiting for 30 seconds. 1 - 39: The number of times the engine was restarted after the 0 condition. NO Warning History: Stores NO (0) turning on history of warning/indicator lamp.
Note. Warning History is not stored for approximately 30 seconds after the engine starts. Brake warning lamp does not store any history when the parking brake is applied or the brake fluid level gets low.
Display Item
| Display item | Description |
|---|---|
| ABS W/L | Lighting history of ABS warning lamp. |
| VDC/TCS IND | Lighting history of VDC OFF indicator lamp. |
| SLIP IND | Lighting history of VDC warning lamp. |
| BRAKE W/L | Lighting history of brake warning lamp. |
| DOOR W/L | Lighting history of door open warning. |
| OIL W/L | Lighting history of oil pressure warning lamp. |
| C-ENG W/L | Lighting history of malfunction indicator lamp. |
| CRUISE IND | Lighting history of CRUISE indicator. |
| O/D OFF IND | Lighting history of O/D OFF indicator lamp. |
| FUEL W/L | Lighting history of low fuel level warning. |
| WASHER W/L | Lighting history of low washer fluid warning. |
| AIR PRES W/L | Lighting history of low tire pressure warning lamp. |
| KEY G/Y W/L | Lighting history of Intelligent Key system malfunction. |
| EPS W/L | Lighting history of EPS warning lamp. |
| BSW W/L | Lighting history of BSW warning lamp. |
Note. In items displayed on the CONSULT screen, only those listed in the above table are used.
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on CONSULT.
| CONSULT screen item | Indication/Unit | Description | |
|---|---|---|---|
| Vehicle Speed | Km/h | Vehicle speed of the moment a particular DTC is detected | |
| Odo/Trip Meter | Km | Total mileage (Odometer value) of the moment a particular DTC is detected | |
| Vehicle Condition | SLEEP>LOCK | Power position status of the moment a particular DTC is detected (1) | While turning BCM status from low power consumption mode to normal mode [Power supply position is OFF (LOCK)] |
| SLEEP>OFF | While turning BCM status from low power consumption mode to normal mode [Power supply position is OFF (OFF)] | ||
| LOCK>ACC | While turning power supply position from OFF (LOCK) to ACC | ||
| ACC>ON | While turning power supply position from ACC to ON | ||
| RUN>ACC | While turning power supply position from RUN to ACC (Except emergency stop operation) | ||
| CRANK>RUN | While turning power supply position from CRANK to RUN | ||
| RUN>URGENT | While turning power supply position from RUN to ACC (Emergency stop operation) | ||
| ACC>OFF | While turning power supply position from ACC to OFF (OFF) | ||
| OFF>LOCK | While turning power supply position from OFF (OFF) to OFF (LOCK) | ||
| OFF>ACC | While turning power supply position from OFF (OFF) to ACC | ||
| ON>CRANK | While turning power supply position from ON to CRANK | ||
| OFF>SLEEP | While turning BCM status from normal mode [Power supply position is OFF (OFF)] to low power consumption mode | ||
| LOCK>SLEEP | While turning BCM status from normal mode [Power supply position is OFF (LOCK)] to low power consumption mode | ||
| LOCK | Power supply position is OFF (LOCK) | ||
| OFF | Power supply position is OFF (OFF) | ||
| ACC | Power supply position is ACC | ||
| ON | Power supply position is ON | ||
| ENGINE RUN | Power supply position is RUN | ||
| CRANKING | Power supply position is CRANK | ||
| IGN Counter | 0 - 39 | The number of times that ignition switch is turned ON after DTC is detected The number is 0 when a malfunction is detected now. The number increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39. | |
| NOTE: (1) Refer to the following for details of the power supply position. OFF (OFF, LOCK): Ignition switch OFF ACC: Ignition switch ACC IGN: Ignition switch ON with engine stopped RUN: Ignition switch ON with engine running CRANK: At engine cranking Power supply position shifts to "OFF (LOCK)" from "OFF (OFF)", when ignition switch is in the OFF position, shift position is in the P position, and any of the following conditions are met. Closing door Opening door Door is locked using door request switch Door is locked using Intelligent Key The power supply position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "OFF (LOCK)". | |||
| NOTE |
|---|
| (1) Refer to the following for details of the power supply position. OFF (OFF, LOCK): Ignition switch OFF ACC: Ignition switch ACC IGN: Ignition switch ON with engine stopped RUN: Ignition switch ON with engine running CRANK: At engine cranking Power supply position shifts to "OFF (LOCK)" from "OFF (OFF)", when ignition switch is in the OFF position, shift position is in the P position, and any of the following conditions are met. Closing door Opening door Door is locked using door request switch Door is locked using Intelligent Key The power supply position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "OFF (LOCK)". |
| (1) | Refer to the following for details of the power supply position. |
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
| Display item [Unit] | Description |
|---|---|
| PUSH SW [On/Off] | Status of push-button ignition switch judged by BCM. |
| UNLK SEN-DR [On/Off] | Status of unlock sensor judged by BCM. |
| VEH SPEED 1 [km/h] | Value of vehicle speed signal received from combination meter with CAN communication line. |
| TAIL LAMP SW [On/Off] | Status of lighting switch judged by BCM using the combination switch readout function. |
| FR FOG SW [On/Off] | Status of front fog lamp switch judged by BCM using the combination switch readout function. |
| DOOR SW-DR [On/Off] | Status of driver side door switch judged by BCM. |
| CDL LOCK SW [On/Off] | Status of door lock unlock switch judged by BCM. |
PHYSICAL VALUES
Terminal No. (Wire color) Description Condition Value (Approx.) + - Signal name Input/Output 1 (O) Ground Battery power supply Input Ignition switch OFF - Battery voltage 2 (Y) Ground Ignition signal Input Ignition switch ON - Battery voltage 3 (B) Ground Ground - Ignition switch ON - 0 V 4 (B) Ground Ground - Ignition switch ON - 0 V 5 (B/P) Ground Illumination control signal Output Ignition switch ON Lighting switch 1ST position When meter illumination is maximum Lighting switch 1ST position When meter illumination is step 11 Lighting switch 1ST position When meter illumination is minimum 12 V 8 (SB) 10 (P) Trip reset switch signal Input Ignition switch ON When trip reset switch is pressed 0 V Other than the above 5 V 10 (P) Ground Meter control switch ground - Ignition switch ON - 0 V 11 (G) 10 (P) Enter switch signal Input Ignition switch ON When [] switch (enter switch) is pressed 0 V Other than the above 5 V 12 (BR) 10 (P) Select switch signal Input Ignition switch ON When • switch (select switch) is pressed 0 V Other than the above 5 V 13 (Y) 10 (P) Illumination control switch signal (+) Input Ignition switch ON When ILLUMINATION+ switch [illumination control switch (+)] is pressed 0 V Other than the above 5 V 14 (V) 10 (P) Illumination control switch signal (-) Input Ignition switch ON When ILLUMINATION- switch [illumination control switch (-)] is pressed 0 V Other than the above 5 V 15 (BR) - Air bag signal Input - - - 16 (L) Ground Engine coolant temperature signal Output Ignition switch ON At idle [after warming up, approx. 20°C (68°F)] At idle [after warming up, approx. 80°C (176°F)] 18 (LG) Ground Ambient sensor signal Input Ignition switch ON - 19 (R) Ground A/C auto amp. connection recognition signal Input Ignition switch ON - 5 V 20 (Y) Ground Ambient sensor ground - Ignition switch ON - 0 V 21 (L) - CAN-H - - - - 22 (P) - CAN-L - - - - 23 (B) Ground Ground - Ignition switch ON - 0 V 24 (B) Ground Fuel level sensor ground - Ignition switch ON - 0 V 25 (BR) Ground Alternator signal Input Ignition switch ON Charge warning lamp ON 12 V Charge warning lamp OFF 0 V 26 (BR) Ground Parking brake switch signal Input Ignition switch ON Parking brake applied. 0 V Parking brake released. 12 V 27 (Y) Ground Brake fluid level switch signal Input Ignition switch ON Brake fluid level is normal 12 V Brake fluid level is less than LOW level 0 V 28 (V) Ground Security signal Input Ignition switch ON Security indicator lamp ON 0 V Security indicator lamp OFF 12 V 29 (G) Ground Washer level switch signal Input Ignition switch ON Washer level switch ON 0 V Washer level switch OFF 5 V 31 (SB) Ground Vehicle speed signal (8-pulse) Output Ignition switch ON Speedometer operated [When vehicle speed is approx. 40 km/h (25 MPH)] NOTE: The maximum voltage varies depending on the specification (destination unit). 32 (P) Ground Overdrive control switch signal Input Ignition switch ON When overdrive control switch is pressed 0 V Other than the above 5 V 34 (O) 24 (B) Fuel level sensor signal Input Ignition switch ON - " COMPONENT INSPECTION " 35 (P) Ground Seat belt buckle switch signal (driver side) Input Ignition switch ON When driver seat belt is fastened 5 V When driver seat belt is unfastened 0 V 36 (BR) - Passenger seat belt warning signal Input
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
FAIL-SAFE
The combination meter activates the fail-safe control if CAN communication with each unit is malfunctioning.
| Function | Specifications | ||
|---|---|---|---|
| Speedometer | Reset to zero by suspending communication. | ||
| Tachometer | |||
| Engine coolant temperature gauge | |||
| Illumination control | When suspending communication, changes to nighttime mode. | ||
| Information display | Odo/trip meter | An indicated value is maintained at communications blackout. | |
| Shift position indicator | The display turns OFF by suspending communication. | ||
| Interrupt indication | Door open warning | The display turns OFF by suspending communication. | |
| Fuel filler cap warning | |||
| Low tire pressure warning | |||
| Trip computer | Current fuel consumption | When reception time of an abnormal signal is 2 seconds or less, the last received datum is used for calculation to indicate the result. When reception time of an abnormal signal is more than two seconds, the last calculation results are indicated. | |
| Average fuel consumption | |||
| Distance to empty | |||
| Average vehicle speed | |||
| Travel distance | |||
| Buzzer | The buzzer turns OFF by suspending communication. | ||
| Warning lamp/indicator lamp | ABS warning lamp | The lamp turns ON by suspending communication. | |
| VDC warning lamp | |||
| Brake warning lamp | |||
| EPS warning lamp | |||
| Malfunction indicator lamp | |||
| Low tire pressure warning lamp | The lamp blinking caused by suspending communication. | ||
| High beam indicator lamp | The lamp turns OFF by suspending communication. | ||
| Turn signal indicator lamp | |||
| VDC OFF indicator lamp | |||
| O/D OFF indicator lamp | |||
| Position lamp indicator lamp | |||
| CRUISE indicator lamp | |||
| Oil pressure warning lamp | |||
| BSW warning lamp | |||
| Key warning lamp | |||
List of ECU Reference
| ECU | Reference |
|---|---|
| BCM | " REFERENCE VALUE " |
| " FAIL-SAFE " | |
| " DTC INSPECTION PRIORITY CHART " | |
| " DTC INDEX " |
Scheme 57
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
DETAILED FLOW
- OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain as much information as possible about the conditions and environment under which the malfunction occurred. : GO TO 2.
- CHECK SYMPTOM Check the symptom based on the information obtained from the customer. Check if any other malfunctions are present. : GO TO 3.
- CHECK CONSULT SELF-DIAGNOSIS RESULTS Connect CONSULT and perform self-diagnosis. Refer to " «DTC INDEX»(ref-672645-S05636642752014112400000) ". When DTC is detected, follow the instructions below: Record DTC and Freeze Frame Data. Are self-diagnosis results normal? YES: GO TO 4. NO: GO TO 5 .
- NARROW DOWN MALFUNCTIONING PARTS BY SYMPTOM DIAGNOSIS Perform symptom diagnosis and narrow down the malfunctioning parts. : GO TO 5.
- REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace malfunctioning parts. NOTE: If DTC is displayed, erase DTC after repairing or replacing malfunctioning parts. : GO TO 6.
- FINAL CHECK Check that the warning buzzer in the combination meter operates normally. Does it operate normally? YES: INSPECTION END NO: GO TO 1 .
Component Function Check
- CHECK OPERATION OF METER BUZZER Select "BUZZER" of "BCM" on CONSULT. Perform "LIGHT WARN ALM" of "Active Test". Does meter buzzer beep? YES: INSPECTION END NO: GO TO 2.
- CHECK COMBINATION METER INPUT SIGNAL Select the "Data Monitor" for the "METER/M & A" and check the "BUZZER" monitor value. BUZZER Under the condition of buzzer input: On Except above: Off Is the inspection result normal? YES: Replace combination meter. Refer to " «REMOVAL AND INSTALLATION»(ref-672645-S26037931462014112400000) ". NO: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-672646-S20942395972014112400000) ".
- CHECK COMBINATION METER INPUT SIGNAL Select the "Data Monitor" for the "METER/M & A" and check the "BUCKLE SW" monitor value. BUCKLE SW When seat belt is fastened: Off When seat belt is unfastened: On : INSPECTION END
