Removal and Installation
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. |
Scheme 5
- Disengage map lamp assembly fixing metal clips with a remover tool (A).
- Disconnect harness connector, and then remove map lamp assembly.
INSTALLATION
Install in the reverse order of removal.
Replacement
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Never touch the glass surface of the bulb with bare hands because the surface is very hot just after the lamp is turned OFF to prevent a burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (causing dirty or clouding). Always prepare a new bulb and have it on hand when replacing the bulb. |
Scheme 6
- Disengage lens fixing pawls with a remover tool (A).
- Remove bulb.
Scheme 7
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Never touch the glass surface of the bulb with bare hands because the surface is very hot just after the lamp is turned OFF to prevent a burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (causing dirty or clouding). Always prepare a new bulb and have it on hand when replacing the bulb. |
Scheme 8
Scheme 8: VANITY MIRROR LAMP
- Disengage lens fixing pawls with a remover tool (A). CAUTION: Apply protective tape (B) on the part to protect it from damage.
- Remove bulb.
Scheme 9
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Never touch the glass surface of the bulb with bare hands because the surface is very hot just after the lamp is turned OFF to prevent a burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (causing dirty or clouding). Always prepare a new bulb and have it on hand when replacing the bulb. |
Scheme 10
Scheme 10: GLOVE BOX LAMP BULB
- Remove Instrument lower panel RH. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
- Rotate the bulb & socket assembly counterclockwise and unlock it and then remove bulb & socket assembly.
Scheme 11
Scheme 11: DRIVER SIDE: Exploded View
DRIVER SIDE: Replacement
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Never touch the glass surface of the bulb with bare hands because the surface is very hot just after the lamp is turned OFF to prevent a burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (causing dirty or clouding). Always prepare a new bulb and have it on hand when replacing the bulb. |
PASSENGER SIDE: Replacement
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Never touch the glass surface of the bulb with bare hands because the surface is very hot just after the lamp is turned OFF to prevent a burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (causing dirty or clouding). Always prepare a new bulb and have it on hand when replacing the bulb. |
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. |
Scheme 12
- Disengage step lamp assembly fixing pawls with a remover tool (A). CAUTION: Apply protective tape (B) on the part to protect it from damage.
- Disconnect harness connector, and then remove step lamp assembly.
Install in the reverse order of removal.
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Never touch the glass surface of the bulb with bare hands because the surface is very hot just after the lamp is turned OFF to prevent a burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (causing dirty or clouding). Always prepare a new bulb and have it on hand when replacing the bulb. |
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. |
Scheme 13
Scheme 14
- Remove rear cooler grille. Disengage rear cooler grille fixing metal clips with a remover tool (A). Disconnect harness connector, and then remove rear cooler grille.
- Remove personal lamp case. Disengage personal lamp case fixing metal clips with a remover tool (A), and then remove personal lamp case.
Install in the reverse order of removal.
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Never touch the glass surface of the bulb with bare hands because the surface is very hot just after the lamp is turned OFF to prevent a burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (causing dirty or clouding). Always prepare a new bulb and have it on hand when replacing the bulb. |
Scheme 15
Scheme 15: PERSONAL LAMP BULB
- Remove personal lamp case. Refer to " «REMOVAL AND INSTALLATION»(ref-672665-S06861352862014112400000) ".
- Remove lens fixing screw.
- Disengage lens fixing pawls with a remover tool (A), and then remove lens.
- Remove bulb.
Scheme 16
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. |
REMOVAL
Disengage luggage room lamp case fixing metal clips with a remover tool (A), and then remove luggage room lamp case.
Install in the reverse order of removal.
| CAUTION | Disconnect the battery negative terminal or remove power circuit fuse while performing the operation to electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Never touch the glass surface of the bulb with bare hands because the surface is very hot just after the lamp is turned OFF to prevent a burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (causing dirty or clouding). Always prepare a new bulb and have it on hand when replacing the bulb. |
Scheme 17
Scheme 17: LUGGAGE ROOM LAMP BULB
- Remove luggage room lamp case. Refer to " «REMOVAL AND INSTALLATION»(ref-672665-S32494017662014112400000) ".
- Remove lens fixing screw.
- Disengage lens fixing pawls with a remover tool (A), and then remove lens.
- Remove bulb.
