| No. | Part | Description |
|---|---|---|
| 1. | IPDM E/R | Controls the integrated relay according to the request signal from BCM (via CAN communication). Refer to " IPDM E/R: COMPONENT PARTS LOCATION " for detailed installation location. |
| 2. | BCM | Activates the interior room lamp timer depending on the vehicle condition to turn the interior room lamps ON/OFF. Operates the interior room lamp battery saver depending on the vehicle condition to cut the interior room lamp power supply. Detects each switch condition by the combination switch reading function. Judges the illumination lamp ON/OFF status depending on the vehicle condition. And then it transmits position light request signal to IPDM E/R and combination meter (with CAN communication). Refer to " BODY CONTROL SYSTEM: COMPONENT PARTS LOCATION " for detailed installation location. |
| 3. | Optical sensor | Refer to " COMPONENT PARTS LOCATION ". |
| 4. | Step lamp | Refer to " BULB SPECIFICATIONS ". |
| 5. | Door switch | Refer to " DOOR LOCK SYSTEM: COMPONENT PARTS LOCATION ". |
| 6. | Front door lock assembly (driver side) (door key cylinder switch) | Refer to " DOOR LOCK SYSTEM: COMPONENT PARTS LOCATION ". |
| 7. | Door request switch | Refer to " DOOR LOCK SYSTEM: COMPONENT PARTS LOCATION ". |
| 8. | Luggage room lamp | Refer to " BULB SPECIFICATIONS ". |
| 9. | Automatic back door close switch | Refer to " AUTOMATIC BACK DOOR SYSTEM: COMPONENT PARTS LOCATION ". |
| 10. | Back door lock assembly (back door switch) | Refer to " DOOR LOCK SYSTEM: COMPONENT PARTS LOCATION ". |
| 11. | Third personal lamp | Refer to " BULB SPECIFICATIONS ". |
| 12. | Second personal lamp | Refer to " BULB SPECIFICATIONS ". |
| 13. | Remote keyless entry receiver | Refer to " DOOR LOCK SYSTEM: COMPONENT PARTS LOCATION ". |
| 14. | Vanity mirror lamp | Refer to " BULB SPECIFICATIONS ". |
| 15. | Combination meter | Refer to " METER SYSTEM: COMPONENT PARTS LOCATION ". |
| 16. | Door lock and unlock switch | Refer to " DOOR LOCK SYSTEM: COMPONENT PARTS LOCATION ". |
| 17. | Push-button ignition switch | Refer to " AUTOMATIC BACK DOOR SYSTEM: COMPONENT PARTS LOCATION ". |
| 18. | AV control unit | Receives the dimmer signal from BCM via CAN communication. Refer to " COMPONENT PARTS LOCATION " for detailed installation location. |
| 19. | Combination switch (Lighting & turn signal switch) | Refer to " COMBINATION SWITCH READING SYSTEM: SYSTEM DESCRIPTION ". |
| 20. | Map lamp | Refer to " BULB SPECIFICATIONS ". |
OUTLINE
- Interior room lamps* are controlled by interior room lamp timer control function of BCM. *: Map lamp and personal lamp (when map lamp switch and personal lamp switch are in DOOR position).
- Step lamp is controlled by step lamp control function of BCM.
- Luggage room lamp and automatic back door close switch illumination are controlled by luggage room lamp control function of BCM.
- Push-button ignition switch illumination is controlled by the push-button ignition switch illumination control function of BCM and combination meter.
INTERIOR ROOM LAMP TIMER CONTROL
Interior Room Lamp Timer Basic Operation
Scheme 20
- The interior room lamp turns ON and OFF (gradual brightening and dimming) by the interior room lamp timer.
- BCM judges the vehicle condition with the following items. It activates the interior room timer. Ignition switch status Door switch signal (except back door) Door lock/unlock signal (remote keyless entry receiver, each door request switch, door key cylinder switch, door lock/unlock switch)
Note. Each function of interior room lamp timer can be set by CONSULT. Refer to " INT LAMP: CONSULT Function (BCM - INT LAMP) ".
Interior Room Lamp ON Operation
- BCM always turns the interior room lamp ON when any door opens excepting back door.
- BCM activates the interior room timer in any of the following conditions to turn the interior room lamp ON for a period of time. Any door opens before all doors close excepting back door. Ignition switch is turned ON --> OFF. Any door unlock signal is detected when all doors close excepting back door with ignition switch OFF.
Note. The timer restarts if new condition is input during the timer operating time.
Interior Room Lamp OFF Operation
BCM stops the timer and turns interior room lamp OFF, when any of the following conditions is satisfied.
- The interior room lamp timer operating time is expired with all doors closed excepting back door.
- Ignition switch position is other than OFF with all doors close excepting back door.
- Any door lock signal is detected with all doors close excepting back door.
LUGGAGE ROOM LAMP CONTROL
BCM controls the luggage room lamp and automatic back door close switch illumination (ground-side) to turn ON with back door switch ON.
- When luggage room lamp switch is in the DOOR position and back door is opened, luggage room lamp turns ON.
- When back door is opened, automatic back door close switch illumination turn ON.
STEP LAMP CONTROL
BCM controls the step lamp (ground-side) to turn ON with any door switch ON excepting back door.
Push-button Ignition Switch Illumination Basic Operation
BCM provides the power supply to turn the push-button ignition switch illumination ON.
Push-button Ignition Switch Illumination ON Operation
BCM turns the push-button ignition switch illumination ON in the following conditions.
- Ignition switch ON
- Any of the following conditions with ignition switch OFF/ACC Engine start permission is entered Driver side door is LOCK --> UNLOCK Driver side door is open
Push-button Ignition Switch Illumination OFF Operation
BCM turns the push-button ignition switch illumination OFF in any of the following conditions.
- The push-button ignition switch illumination ON conditions do not satisfy.
- Any of the following conditions with ignition switch OFF. The push-button ignition switch illumination ON conditions do not change (15 seconds after the ignition switch OFF) Driver side door is UNLOCK --> LOCK
Scheme 21
Scheme 22
Scheme 23
Scheme 24
- Interior room lamp battery saver is controlled by BCM.
- BCM turns applicable lamps OFF depending on the vehicle condition. This function prevents the battery from over-discharging if the driver neglects turning OFF the any lamps.
Applicable lamps
- Map lamp
- Personal lamp
- Luggage room lamp
- Automatic back door close switch illumination
- Step lamp
- Vanity mirror lamp
INTERIOR ROOM LAMP BATTERY SAVER FUNCTION
- When the ignition switch is turned to a position other than ON, BCM operates the timer for a period of time to cut the interior room lamp power supply.
- BCM restart the timer when any of the following signals changes while operating the timer. Ignition switch status Door switch signal (ALL) Door lock/unlock signal (remote keyless entry receiver, each door request switch, door lock and unlock switch, door key cylinder switch)
- BCM provides the interior room lamp power supply continuously when the ignition switch position is ON.
Note. Each function of interior room lamp battery saver can be set by CONSULT. Refer to " BATTERY SAVER: CONSULT Function (BCM - BATTERY SAVER) ".
Scheme 25
Scheme 26
Each illumination lamp is controlled by each function of BCM, IPDM E/R and combination meter.
Control by BCM
- Combination switch reading function
- Headlamp control function
Control by IPDM E/R
- Relay control function
Control by combination meter
- Meter illumination control function (Refer to " «METER ILLUMINATION CONTROL: SYSTEM DESCRIPTION»(ref-672645-S12243006382014112400000) ".)
ILLUMINATION CONTROL
- BCM detects the combination switch condition by the combination switch reading function.
- BCM transmits position light request signal to IPDM E/R and combination meter according to tail lamp ON condition.
Tail lamp ON condition
- Lighting switch 1ST
- Lighting switch 2ND
- Lighting switch AUTO, and the auto light function ON judgment
- Lighting switch AUTO, with the front fog lamp switch ON and the ignition switch ON
- IPDM E/R turns the integrated tail lamp relay ON according to position light request signal. It provides the power supply to each illumination lamp.
- Combination meter enters in the nighttime mode according to position light request signal. Under the nighttime mode the combination meter controls the illuminance by controlling each illumination lamp (ground side).
Scheme 27
Scheme 28
Auto light adjustment system is controlled by each function of BCM, combination meter and AV control unit
Control by BCM
- Auto light system
- Auto light adjustment system
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on CONSULT.
| CONSULT screen item | Indication/Unit | Description | |
|---|---|---|---|
| Vehicle Speed | Km/h | Vehicle speed of the moment a particular DTC is detected | |
| ODO/Trip Meter | Km | Total mileage (Odometer value) of the moment a particular DTC is detected | |
| Vehicle Condition | SLEEP>LOCK | Power position status of the moment a particular DTC is detected (1) | While turning BCM status from low power consumption mode to normal mode [Power supply position is OFF (LOCK)] |
| SLEEP>OFF | While turning BCM status from low power consumption mode to normal mode [Power supply position is OFF (OFF)] | ||
| LOCK>ACC | While turning power supply position from OFF (LOCK) to ACC | ||
| ACC>ON | While turning power supply position from ACC to ON | ||
| RUN>ACC | While turning power supply position from RUN to ACC (Except emergency stop operation) | ||
| CRANK>RUN | While turning power supply position from CRANK to RUN | ||
| RUN>URGENT | While turning power supply position from RUN to ACC (Emergency stop operation) | ||
| ACC>OFF | While turning power supply position from ACC to OFF (OFF) | ||
| OFF>LOCK | While turning power supply position from OFF (OFF) to OFF (LOCK) | ||
| OFF>ACC | While turning power supply position from OFF (OFF) to ACC | ||
| ON>CRANK | While turning power supply position from ON to CRANK | ||
| OFF>SLEEP | While turning BCM status from normal mode [Power supply position is OFF (OFF)] to low power consumption mode | ||
| LOCK>SLEEP | While turning BCM status from normal mode [Power supply position is OFF (LOCK)] to low power consumption mode | ||
| LOCK | Power supply position is OFF (LOCK) | ||
| OFF | Power supply position is OFF (OFF) | ||
| ACC | Power supply position is ACC | ||
| ON | Power supply position is ON | ||
| ENGINE RUN | Power supply position is RUN | ||
| CRANKING | Power supply position is CRANK | ||
| IGN Counter | 0 - 39 | The number of times that ignition switch is turned ON after DTC is detected The number is 0 when a malfunction is detected now. The number increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39. | |
| NOTE: (1) Refer to the following for details of the power supply position. OFF (OFF, LOCK): Ignition switch OFF ACC: Ignition switch ACC IGN: Ignition switch ON with engine stopped RUN: Ignition switch ON with engine running CRANK: At engine cranking Power supply position shifts to "OFF (LOCK)" from "OFF (OFF)", when ignition switch is in the OFF position, shift position is in the P position, and any of the following conditions are met. Closing door Opening door Door is locked using door request switch Door is locked using Intelligent Key The power supply position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "OFF (LOCK)". | |||
| NOTE |
|---|
| (1) Refer to the following for details of the power supply position. OFF (OFF, LOCK): Ignition switch OFF ACC: Ignition switch ACC IGN: Ignition switch ON with engine stopped RUN: Ignition switch ON with engine running CRANK: At engine cranking Power supply position shifts to "OFF (LOCK)" from "OFF (OFF)", when ignition switch is in the OFF position, shift position is in the P position, and any of the following conditions are met. Closing door Opening door Door is locked using door request switch Door is locked using Intelligent Key The power supply position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "OFF (LOCK)". |
| (1) | Refer to the following for details of the power supply position. |
WORK SUPPORT
| Service item | Setting item | Setting | |
|---|---|---|---|
| ROOM LAMP TIMER SET | MODE 2 | 7.5 sec. | Sets the interior room lamp ON time. (Timer operating time) |
| MODE 3 (1) | 15 sec. | ||
| MODE 4 | 30 sec. | ||
| SET I/L D-UNLCK INTCON | On (1) | With the interior room lamp timer function | |
| Off | Without the interior room lamp timer function | ||
| ROOM LAMP ON TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual brightening time. |
| MODE 2 (1) | 1 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 4 | 3 sec. | ||
| MODE 5 | 0 sec. | ||
| ROOM LAMP OFF TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual dimming time. |
| MODE 2 (1) | 1 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 4 | 3 sec. | ||
| MODE 5 | 0 sec. | ||
| R LAMP TIMER LOGIC SET | MODE 1 (1) | Interior room lamp timer activates with synchronizing all doors. | |
| MODE 2 | Interior room lamp timer activates with synchronizing the driver door only. | ||
| (1) Factory setting | |||
| (1) | Factory setting |
DATA MONITOR
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
| Monitor item [Unit] | Description |
|---|---|
| REQ SW-DR [On/Off] | The switch status input from door request switch (driver side) |
| REQ SW-AS [On/Off] | The switch status input from door request switch (passenger side) |
| REQ SW-RR [On/Off] | NOTE: The item is indicated, but not monitored. |
| REQ SW-RL [On/Off] | |
| PUSH SW [On/Off] | The switch status input from push-button ignition switch |
| UNLK SEN-DR [On/Off] | Driver door unlock status input from unlock sensor |
| DOOR SW-DR [On/Off] | The switch status input from front door switch (driver side) |
| DOOR SW-AS [On/Off] | The switch status input from front door switch (passenger side) |
| DOOR SW-RR [On/Off] | The switch status input from sliding door switch RH |
| DOOR SW-RL [On/Off] | The switch status input from sliding door switch LH |
| DOOR SW-BK [On/Off] | The switch status input from back door switch |
| CDL LOCK SW [On/Off] | Lock switch status input from door lock and unlock switch |
| CDL UNLOCK SW [On/Off] | Unlock switch status input from door lock and unlock switch |
| TRNK/HAT MNTR [On/Off] | NOTE: The item is indicated, but not monitored |
| KEY CYL LK-SW [On/Off] | Lock switch status received from door key cylinder switch |
| KEY CYL UN-SW [On/Off] | Unlock switch status received from door key cylinder switch |
| RKE-LOCK [On/Off] | Lock signal status received from remote keyless entry receiver |
| RKE-UNLOCK [On/Off] | Unlock signal status received from remote keyless entry receiver |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored |
| Service item | Setting item | Setting | |
|---|---|---|---|
| ROOM LAMP TIMER SET | MODE 1 | 30 min. | Sets the interior room lamp battery saver timer operating time. NOTE: The factor setting is 10 minutes. The setting cannot be returned to the factory setting, when the setting is changed once. |
| MODE 2 | 60 min. | ||
| MODE 3 | 15 min. | ||
| BATTERY SAVER SET | On (1) | With the exterior lamp battery saver function | |
| Off | Without the exterior lamp battery saver function | ||
| (1) Factory setting | |||
| NOTE |
|---|
| The factor setting is 10 minutes. The setting cannot be returned to the factory setting, when the setting is changed once. |
| (1) | Factory setting |
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
| Monitor item [Unit] | Description |
|---|---|
| REQ SW-DR [On/Off] | The switch status input from door request switch (driver side) |
| REQ SW-AS [On/Off] | The switch status input from door request switch (passenger side) |
| REQ SW-RR [On/Off] | NOTE: The item is indicated, but not monitored. |
| REQ SW-RL [On/Off] | |
| PUSH SW [On/Off] | The switch status input from push-button ignition switch |
| UNLK SEN-DR [On/Off] | Driver door unlock status input from unlock sensor |
| DOOR SW-DR [On/Off] | The switch status input from front door switch (driver side) |
| DOOR SW-AS [On/Off] | The switch status input from front door switch (passenger side) |
| DOOR SW-RR [On/Off] | The switch status input from sliding door switch RH |
| DOOR SW-RL [On/Off] | The switch status input from sliding door switch LH |
| DOOR SW-BK [On/Off] | The switch status input from back door switch |
| CDL LOCK SW [On/Off] | Lock switch status input from door lock and unlock switch |
| CDL UNLOCK SW [On/Off] | Unlock switch status input from door lock and unlock switch |
| TRNK/HAT MNTR [On/Off] | NOTE: The item is indicated, but not monitored |
| KEY CYL LK-SW [On/Off] | Lock switch status received from door key cylinder switch |
| KEY CYL UN-SW [On/Off] | Unlock switch status received from door key cylinder switch |
| RKE-LOCK [On/Off] | Lock signal status received from remote keyless entry receiver |
| RKE-UNLOCK [On/Off] | Unlock signal status received from remote keyless entry receiver |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored |
List of ECU Reference
| ECU | Reference |
|---|---|
| BCM | " REFERENCE VALUE " |
| " FAIL-SAFE " | |
| " DTC INSPECTION PRIORITY CHART " | |
| " DTC INDEX " |
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
DETAILED FLOW
- GET INFORMATION FOR SYMPTOM Get detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurs). Check operation condition of the function that is malfunctioning. : GO TO 2.
- CHECK DTC Check DTC. Perform the following procedure if DTC is detected. Record DTC and freeze frame data (Print them out using CONSULT.) Erase DTC. Study the relationship between the cause detected by DTC and the symptom described by the customer. Check related service bulletins for information. Are any symptoms described and any DTC detected? Symptom is described, DTC is detected: GO TO 3. Symptom is described, DTC is not detected: GO TO 4 . Symptom is not described, DTC is detected: GO TO 5 .
- CONFIRM THE SYMPTOM Try to confirm the symptom described by the customer. Also study the normal operation and fail-safe related to the symptom. Verify relation between the symptom and the condition when the symptom is detected. : GO TO 5 .
- CONFIRM THE SYMPTOM Try to confirm the symptom described by the customer. Verify relation between the symptom and the condition when the symptom is detected. : GO TO 6 .
- PERFORM DTC CONFIRMATION PROCEDURE Perform DTC CONFIRMATION PROCEDURE for the detected DTC, and then check that DTC is detected again. At this time, always connect CONSULT to the vehicle, and check self diagnostic results in real time. If two or more DTCs are detected, refer to DTC INSPECTION PRIORITY CHART, and determine trouble diagnosis order. NOTE: Freeze frame data is useful if the DTC is not detected. Perform Component Function Check if DTC CONFIRMATION PROCEDURE is not included on Service Information. This simplified check procedure is an effective alternative though DTC cannot be detected during this check. If the result of Component Function Check is NG, it is the same as the detection of DTC by DTC CONFIRMATION PROCEDURE. Is DTC detected? YES: GO TO 7 . NO: Check according to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ".
- DETECT MALFUNCTIONING SYSTEM BY SYMPTOM DIAGNOSIS Detect malfunctioning system according to SYMPTOM DIAGNOSIS based on the confirmed symptom in step 4 , and determine the trouble diagnosis order based on possible causes and symptom. Is the symptom described? YES: GO TO 7. NO: Monitor input data from related sensors or check voltage of related module terminals using CONSULT.
- DETECT MALFUNCTIONING PART BY DIAGNOSIS PROCEDURE Inspect according to Diagnosis Procedure of the system. Is malfunctioning part detected? YES: GO TO 8. NO: Check according to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ".
- REPAIR OR REPLACE THE MALFUNCTIONING PART Repair or replace the malfunctioning part. Reconnect parts or connectors disconnected during Diagnosis Procedure again after repair and replacement. Check DTC. If DTC is detected, erase it. : GO TO 9.
- FINAL CHECK When DTC is detected in step 2 , perform DTC CONFIRMATION PROCEDURE again, and then check that the malfunction is repaired securely. When symptom is described by the customer, refer to confirmed symptom in step 3 or 4 , and check that the symptom is not detected. Is DTC detected and does symptom remain? YES-1: DTC is detected: GO TO 7 . YES-2: Symptom remains: GO TO 4 . NO: Before returning the vehicle to the customer, always erase DTC.
Component Function Check
- CHECK INTERIOR ROOM LAMP POWER SUPPLY FUNCTION CONSULT ACTIVE TEST Turn ignition switch ON. Turn each interior room lamp ON. Personal lamp Map lamp Luggage room lamp Automatic back door close switch illumination Step lamp Vanity mirror lamp Select "BATTERY SAVER" of BCM (BATTERY SAVER) active test item. With operating the test items, check that each interior room lamp turns ON/OFF. Off: Interior room lamp OFF On: Interior room lamp ON Does the interior room lamp turn ON/OFF? YES: Interior room lamp power supply circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-672665-S38057040732014112400000) ".
| CAUTION | Before performing the diagnosis, check that the following are normal. Interior room lamp power supply Map lamp bulb Personal lamp bulb |
- CHECK INTERIOR ROOM LAMP CONTROL FUNCTION CONSULT ACTIVE TEST Switch the map lamp switch and personal lamp switch to DOOR. Turn ignition switch ON. Select "INT LAMP" of BCM (INT LAMP) active test item. With operating the test items, check that each interior room lamp turns ON/OFF (gradual brightening/dimming). On: Interior room lamp gradual brightening Off: Interior room lamp gradual dimming Does the interior room lamp turns ON/OFF (gradual brightening/dimming)? YES: Interior room lamp control circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-672665-S21135809762014112400000) ".
| CAUTION | Before performing the diagnosis, check that the following is normal. Interior room lamp power supply Step lamp bulb |
- CHECK STEP LAMP OPERATION CONSULT ACTIVE TEST Turn ignition switch ON. Select "STEP LAMP TEST" of BCM (INT LAMP) active test item. With operating the test items, check that step lamp turns ON/OFF. On: Step lamp ON Off: Step lamp OFF Does the step lamp turn ON/OFF? YES: Step lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-672665-S35554535152014112400000) ".
- CHECK PUSH-BUTTON IGNITION SWITCH ILLUMINATION OPERATION CONSULT ACTIVE TEST Turn ignition switch ON. Select "ENGINE SW ILLUMI" of BCM (INTELLIGENT KEY) active test item. With operating the test items, check that the push-button ignition switch illumination turns ON/OFF. On: Push-button ignition switch illumination ON Off: Push-button ignition switch illumination OFF Does the push-button ignition switch illumination turn ON/OFF? YES: Push-button ignition switch illumination circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-672665-S15617657562014112400000) ".
FOOT LAMP BULB (DRIVER SIDE)
- Remove instrument lower panel LH. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
- Rotate the bulb & socket assembly counterclockwise and unlock it and then remove bulb & socket assembly.
Scheme 57
FOOT LAMP BULB (PASSENGER SIDE)
- Remove instrument lower panel RH. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
- Rotate the bulb & socket assembly counterclockwise and unlock it and then remove bulb & socket assembly.
Scheme 58
STEP LAMP BULB
Push bulb with a remover tool (A), and then remove bulb.
