Body Control System: Removal & Installation Nissan Quest IV

Communication Devices 1 illustration ~167 words

BEFORE REPLACEMENT

When replacing BCM, save or print current vehicle specification with CONSULT configuration before replacement.

Note. If "READ CONFIGURATION" can not be used, use the "WRITE CONFIGURATION - Manual selection" after replacing BCM.

AFTER REPLACEMENT

CAUTIONWhen replacing BCM, always perform "WRITE CONFIGURATION" with CONSULT. Or not doing so, BCM control function does not operate normally. Complete the procedure of "WRITE CONFIGURATION" in order. Configuration is different for each vehicle model. Confirm configuration of each vehicle model. If you set incorrect "WRITE CONFIGURATION", incidents might occur.

Note. When replacing BCM, perform the system initialization (NATS) (if equipped).

Removal and Installation

Note. Before replacing BCM, perform "READ CONFIGURATION" to save or print current vehicle specification. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (BCM): DESCRIPTION ".

REMOVAL

  1. Remove combination meter. Refer to " «REMOVAL AND INSTALLATION»(ref-672645-S26037931462014112400000) ".
  2. Remove bolts.
  3. Remove BCM and disconnect the connectors.

INSTALLATION

Install in the reverse order of removal.

CAUTIONBe sure to perform "WRITE CONFIGURATION" when replacing BCM. Or not doing so, BCM control function does not operate normally.

Note. Be sure to perform the system initialization (NATS) when replacing BCM. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (BCM): WORK PROCEDURE ".

Scheme 64

Scheme 64: Exploded View
Scheme 64: Exploded View
  1. Remove steering column cover. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
  2. Remove screws.
  3. Disconnect the connector.
  4. Pull up the combination switch to remove it.

Install in the reverse order of removal.
