Accelerator Control System: Removal & Installation Nissan Quest IV

Engine Control Systems 1 illustration

REMOVAL

Disconnect accelerator pedal position sensor harness connector.
Remove accelerator pedal assembly. CAUTION: Never disengage accelerator pedal assembly and bracket. Never disassemble accelerator lever. Never remove accelerator pedal position sensor from accelerator lever. Avoid impact from dropping etc. during handling. Be careful to keep accelerator lever away from water.

INSTALLATION

Read the following instructions carefully, and install accelerator pedal assembly in the reverse order of removal.

Scheme 1

Scheme 1: INSTALLATION

Scheme 1: INSTALLATION

Insert pawl (A) of bracket into locating hole (B) of accelerator pedal assembly to tighten the mounting bolts.
