Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS of this Service Information.
| WARNING | Always observe the following items for preventing accidental activation. To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see " SRS AIR BAG ". Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | Always observe the following items for preventing accidental activation. When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Precaution for Procedure without Cowl Top Cover
When performing the procedure after removing cowl top cover, cover the lower end of windshield with urethane, etc to prevent damage to windshield.
Scheme 215
Scheme 216
- When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
- For vehicles with the 2-batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
- After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.
Commercial Service Tool
Tool name Description Remover tool Removes clips, pawls and metal clips
Scheme 217
OUTLINE
Ventilation system is controlled by A/C auto amp. (AUTOMATIC AIR CONDITIONING) or A/C amp. (MANUAL AIR CONDITIONING). For details of air conditioning system, refer to " FRONT AUTOMATIC AIR CONDITIONING SYSTEM: SYSTEM DESCRIPTION " (AUTOMATIC AIR CONDITIONING) or " FRONT MANUAL AIR CONDITIONING SYSTEM: SYSTEM DESCRIPTION " (MANUAL AIR CONDITIONING).
AIR FLOW
Front
Scheme 218
Rear (Second seat underfoot portion)
Scheme 219
| X: Applicable | |||||
|---|---|---|---|---|---|
| MODE/DEF position indication | Air outlet | ||||
| Ventilator (1) | Foot | Defroster (4) | |||
| Center | Side | Front (2) | Rear (3) | ||
| X | X | ||||
| X | X | X | X | ||
| X | X | X | X | ||
| X | X | X | X | ||
| X | X | ||||
Ventilation system is controlled by A/C auto amp. (AUTOMATIC AIR CONDITIONING) or A/C amp. (MANUAL AIR CONDITIONING). For details of air conditioning system, refer to " REAR AUTOMATIC AIR CONDITIONING SYSTEM: SYSTEM DESCRIPTION " (AUTOMATIC AIR CONDITIONING) or " REAR MANUAL AIR CONDITIONING SYSTEM: SYSTEM DESCRIPTION " (MANUAL AIR CONDITIONING).
Headlining
Scheme 220
Rear (Third seat underfoot portion)
Scheme 221
| X: Applicable | ||
|---|---|---|
| Mode position | Air outlet | |
| Ventilator (1) | Foot (2) | |
| X | ||
| X | X | |
| X | ||
Scheme 222
Scheme 223
FRONT BLOWER MOTOR
Refer to " EXPLODED VIEW ".
REAR BLOWER MOTOR
Refer to " EXPLODED VIEW ".
Scheme 224
- Remove instrument lower panel RH. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
- Disconnect harness connector (A).
- Remove fixing screws (B), and then remove front blower motor.
Exploded View
Refer to " EXPLODED VIEW ".
In-cabin microfilter
| Replacement interval | " INTRODUCTION OF PERIODIC MAINTENANCE ". |
