Seat System: Overview Nissan Quest III

Manual Operation

The driving position [front seat LH position, pedal position (accelerator, brake) and door mirror position] can be adjusted with the power seat switch LH, pedal adjusting switch or door mirror remote control switch.

Note. The door mirrors can be manually operated with the ignition switch turned to ACC or ON. Adjustable pedal operates only when A/T selector lever is in P position, (except when ignition switch turned to OFF). If A/T device (park position switch) error is detected, manual adjustable pedal operation cannot be performed when ignition switch turns ON.

Automatic Operation

AUTOMATIC OPERATION DESCRIPTION

Note. Disconnecting the battery erases the stored memory. After connecting the battery, insert the key into the ignition cylinder and turn the front door switch LH ON (open) --> OFF (close) --> ON (open), the Entry/Exiting function becomes possible. After Exiting operation is carried out, return operation can be operated. AUTOMATIC OPERATION DESCRIPTION Auto operation temporary stop conditions. When ignition switch is turned to START during seat memory switch operation and return operation, seat memory switch operation and return operation is stopped. Auto operation stop conditions. When the vehicle speed becomes 7 km/h (4 MPH) or higher (memory switch operation and entry operation). When the setting switch, seat memory switch 1 or 2 are pressed. When A/T selector lever is in any position other than P. When the door mirror switch is operated (when ignition switch turned to ON). When power seat switch LH turned ON. When pedal adjusting switch turned ON. When front seat sliding Entry/Exiting setting is OFF (entry/exiting operation).

Note. During automatic operation, if the ignition switch is turned ON --> START, the automatic operation is suspended. When the ignition switch returns to ON, it resumes.

System Description

1. The system automatically moves the front seat LH to facilitate entry/exit to/from the vehicle. The driver seat control unit can also store the optimum driving positions (front seat LH, pedal position and door mirror position) for 2 people. If the front seat LH is changed, one-touch operation allows changing to the other driving position.
2. The settings (ON/OFF) of the automatic sliding seat (Entry/Exiting operation) at entry/exit can be changed as desired, using the display unit in the center of the instrument panel. The set content is transmitted by CAN communication, from display unit (without NAVI) or display control unit (with NAVI) to driver seat control unit.
3. Using CONSULT-II, the seat slide amount at entry/exit setting can be changed.

MEMORY OPERATION

Selecting the memorized position.

1. Within 45 seconds of opening front door LH press the desired seat memory switch for at least 1 second, or turn ignition switch ON and press the desired seat memory switch for at least 1 second.
2. The front seat LH, door mirrors, accelerator pedal and brake pedal will move to their set memory positions. (during adjustments, indicator LED flashes, then illuminates for 5 seconds.

Note. The front seat LH position and pedal adjustment functions (see the following table) operate simultaneously in the order of priority.

FRONT SEAT LH POSITION AND PEDAL ADJUSTMENT FUNCTIONS

ENTRY OPERATION

When the front seat LH is in the exiting positions, the following operation moves the front seat LH to the previous position before the exiting operation.

Scheme 1

EXITING OPERATION

At Entry/Exiting, the front seat LH is automatically moved to the exiting position.

Scheme 2

CAN Communication System Description

Refer to " CAN COMMUNICATION ".

Scheme 3

Scheme 4
