Lighting System: Overview Nissan Quest III

General precautions for service operations

1. Never work with wet hands.
2. Turn the lighting switch OFF before disconnecting and connecting the connector.
3. When checking the headlamp on/off operation, check it on vehicle and with the power connected to the vehicle-side connector.
4. Do not touch the headlamp bulb glass surface with bare hands or allow oil or grease to get on it. Do not touch the headlamp bulb just after the headlamp is turned off, because it is very hot.
5. When the bulb has burned out, wrap it in a thick vinyl bag and discard. Do not break the bulb.
6. Leaving the bulb removed from the headlamp housing for a long period of time can deteriorate the performance of the lens and reflector (dirt, clouding). Always prepare a new bulb and have it on hand when replacing the bulb.
7. Do not use organic solvent (paint thinner or gasoline) to clean lamps and to remove old sealant.

Scheme 1

System Description

Control of the headlamp system operation is dependent upon the position of the combination switch (lighting switch). When the lighting switch is placed in the 2ND position, the BCM (body control module) receives input requesting the headlamps (and tail lamps) illuminate. This input is communicated to the IPDM E/R (intelligent power distribution module engine room) across the CAN communication lines. The CPU (central processing unit) of the IPDM E/R controls the headlamp high and headlamp low relay coils. When energized, these relays direct power to the respective headlamps, which then illuminate.

Low Beam Operation

With the lighting switch in 2ND position, the BCM receives input requesting the headlamps to illuminate. This input is communicated to the IPDM E/R across the CAN communication lines. The CPU of the IPDM E/R controls the headlamp low relay coil. When energized, this relay directs power

1. through 15A fuse (No. 36, located in the IPDM E/R)
2. through IPDM E/R terminal 20
3. to front combination lamp RH terminal 1, and
4. through 15A fuse (No. 45, located in the IPDM E/R)
5. through IPDM E/R terminal 30
6. to front combination lamp LH terminal 1.

Ground is supplied

1. to front combination lamp LH and RH terminal 2
2. through grounds E9, E15 and E24.

With power and ground supplied, low beam headlamps illuminate.

High Beam Operation/Flash-to-Pass Operation

With the lighting switch in 2ND position and placed in HIGH or PASS position, the BCM receives input requesting the headlamp high beams to illuminate. This input is communicated to the IPDM E/R and combination meter across the CAN communication lines. The CPU of the combination meter controls the ON/OFF status of the HIGH BEAM indicator. The CPU of the IPDM E/R controls the headlamp high relay coil. When energized, this relay directs power

1. through 10A fuse (No. 40, located in the IPDM E/R)
2. through IPDM E/R terminal 27
3. to front combination lamp RH terminal 3, and
4. through 10A fuse (No. 38, located in the IPDM E/R)
5. through IPDM E/R terminal 28
6. to front combination lamp LH terminal 3.

Ground is supplied

1. to front combination lamp LH and RH terminal 4
2. through grounds E9, E15 and E24.

With power and ground supplied, the high beam headlamps illuminate.

AUTO LIGHT OPERATION

Refer to " SYSTEM DESCRIPTION " for auto light operation.

CAN Communication System Description

Refer to " CAN COMMUNICATION ".

Scheme 2

CONSULT-II OPERATION

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM" on "SELECT SYSTEM" screen. If "BCM" is not indicated, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-239935-S20808400922006080400000) ".
4. Touch "HEAD LAMP" on "SELECT TEST ITEM" screen.

Operation Procedure

1. Touch "HEAD LAMP" on "SELECT TEST ITEM" screen.
2. Touch "WORK SUPPORT" on "SELECT DIAG MODE" screen.
3. Touch item on "SELECT WORK ITEM" screen.
4. Touch "START".
5. Touch "CHANGE SETT".
6. The setting will be changed and "CUSTOMIZING COMPLETED" will be displayed.
7. Touch "END".

1. Touch "HEAD LAMP" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on the "SELECT MONITOR ITEM" screen.
4. Touch "START". DATA MONITOR TABLE ALL SIGNALS Monitors all the signals. SELECTION FROM MENU Selects and monitors individual signal.
5. When "SELECTION FROM MENU" is selected, touch individual items to be monitored. When "ALL SIGNALS" is selected, all the items will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

1. Touch "HEAD LAMP" on "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
3. Touch item to be tested, and check operation of the selected item.
4. During the operation check, touching "BACK" deactivates the operation.

1. Touch "BCM" on "SELECT TEST ITEM" screen.
2. Touch "SELF-DIAG RESULTS" on "SELECT DIAG MODE" screen.
3. Self-diagnostic results are displayed.

Scheme 7

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn the ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "IPDM E/R" on "SELECT SYSTEM" screen. If "IPDM E/R" is not displayed, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-239935-S20808400922006080400000) ".
4. Select the desired part to be diagnosed on the "SELECT DIAG MODE" screen.

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch "ALL SIGNALS""MAIN SIGNALS" or "SELECTION FROM MENU" on the "SELECT MONITOR ITEM" screen. DATA MONITOR TABLE ALL SIGNALS All items will be monitored. MAIN SIGNALS Monitor the predetermined item. SELECTION FROM MENU Select any item for monitoring.
3. Touch "START".
4. Touch the required monitoring item on "SELECTION FROM MENU". In "ALL SIGNALS", all items are monitored. In "MAIN SIGNALS", predetermined items are monitored.
5. Touch "RECORD" while monitoring to record the status of the item being monitored. To stop recording, touch "STOP".

All Items, Main Items, Select Item Menu

ITEM MENU TABLE

Note. Perform monitoring of IPDM E/R data with the ignition switch ON. When the ignition switch is at ACC, the display may not be correct.

1. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
2. Touch item to be tested and check operation.
3. Touch "START".
4. Touch "STOP" while testing to stop the operation. TEST ITEM DESCRIPTION TABLE Test item CONSULT-II screen display Description Tail lamp relay output TAIL LAMP Allows tail lamp relay to operate by switching operation ON-OFF at your option. Headlamp relay (HI, LO) output LAMPS Allows headlamp relay (HI, LO) to operate by switching operation (OFF, HI, LO) at your option (Head lamp high beam repeats ON-OFF every 1 second). Front fog lamp relay (FOG) output Allows fog lamp relay (FOG) to operate by switching operation ON-OFF at your option. Cornering lamp relay (RH, LH) output CORNERING LAMP Allows cornering lamp relay (RH, LH) to operate by switching operation ON-OFF at your option.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. CHECK COMBINATION SWITCH INPUT SIGNAL Select "BCM" on CONSULT-II. With "HEAD LAMP" data monitor, make sure "HI BEAM SW" turns ON-OFF linked with operation of lighting switch. When lighting switch is in HIGH position: HI BEAM SW ON OK or NG OK: GO TO 2. NG: Check lighting switch. Refer to " «COMBINATION SWITCH INSPECTION»(ref-239962-S11371497032006080400000) ".
2. HEADLAMP ACTIVE TEST Select "IPDM E/R" on CONSULT-II, and select "ACTIVE TEST" on "SELECT DIAG MODE" screen. Select "LAMPS" on "SELECT TEST ITEM" screen. Touch "HI" on "ACTIVE TEST" screen. Make sure headlamp high beam operates. Headlamp high beam should operate. OK or NG OK: GO TO 3. NG: GO TO 4.
3. CHECK IPDM E/R Select "IPDM E/R" on CONSULT-II, and select "DATA MONITOR" on "SELECT DIAG MODE" screen. Make sure "HL LO REQ" and "HL HI REQ" turns ON when lighting switch is in HIGH position. When lighting switch is in HIGH position: HL LO REQ ON : HL HI REQ ON OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-239939-S09181280512006080300000) ". NG: Replace BCM. Refer to " «REMOVAL AND INSTALLATION OF BCM»(ref-239966-S24017391232006080300000) ".
4. CHECK HEADLAMP INPUT SIGNAL Turn ignition switch OFF. Disconnect front combination lamp RH and LH connectors. Turn ignition switch ON. Select "IPDM E/R" on CONSULT-II, and select "ACTIVE TEST" on "SELECT DIAG MODE" screen. Select "LAMPS" on "SELECT TEST ITEM" screen. Touch "HI" on "ACTIVE TEST" screen. When headlamp high beam is operating, check voltage between front combination lamp RH and LH harness connector terminals and ground. FRONT COMBINATION LAMP - VOLTAGE TABLE Terminals (-) Voltage (+) Front combination lamp connector Terminal RH E13 3 Ground Battery voltage LH E45 OK or NG OK: GO TO 6. NG: GO TO 5.
5. CHECK HEADLAMP CIRCUIT Turn ignition switch OFF. Disconnect IPDM E/R connector. Check continuity between IPDM E/R harness connector terminals and front combination lamp RH and LH harness connector terminals. IPDM E/R - FRONT COMBINATION LAMP - CONTINUITY TABLE A B Continuity IPDM E/R connector Terminal Front combination lamp connector Terminal E122 27 RH E13 3 Yes 28 LH E45 OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-239939-S09181280512006080300000) ". NG: Repair harness or connector.
6. CHECK HEADLAMP GROUND Turn ignition switch OFF. Check continuity between front combination lamp RH and LH harness connector terminals and ground. FRONT COMBINATION LAMP - CONTINUITY TABLE Terminals Continuity Front combination lamp connector Terminal RH E13 4 Ground Yes LH E45 OK or NG OK: Check front combination lamp connector for damage or poor connection. Repair as necessary. NG: Repair harness or connector.

Scheme 14

Scheme 15

Scheme 16

1. BULB INSPECTION Inspect inoperative headlamp bulb. OK or NG OK: GO TO 2. NG: Replace headlamp bulb. Refer to " «HEADLAMP (INNER SIDE), FOR HIGH BEAM»(ref-239962-S19829187882006080400000) ".
2. CHECK POWER TO HEADLAMP Disconnect inoperative front combination lamp connector. Turn the high beam headlamps ON. Check voltage between inoperative front combination lamp harness connector terminal and ground. INOPERATIVE FRONT COMBINATION LAMP - VOLTAGE TABLE Terminals (-) Voltage (Approx.) (+) Front combination lamp connector Terminal RH E13 3 Ground Battery voltage LH E45 OK or NG OK: GO TO 3. NG: GO TO 4.
3. CHECK HEADLAMP GROUND Turn the high beam headlamps OFF. Check continuity between inoperative front combination lamp harness connector terminal and ground. INOPERATIVE FRONT COMBINATION LAMP - CONTINUITY TABLE Terminals Continuity Front combination lamp connector Terminal RH E13 4 Ground Yes LH E45 OK or NG OK: Check front combination lamp connector for damage or poor connection. Repair as necessary. NG: Repair open circuit in harness between inoperative headlamp and ground.
4. INSPECTION BETWEEN IPDM E/R AND HEADLAMPS Disconnect IPDM E/R connector. Check continuity between IPDM E/R harness connector terminal and inoperative front combination lamp harness connector terminal. IPDM E/R - INOPERATIVE FRONT COMBINATION LAMP - CONTINUITY TABLE A B Continuity IPDM E/R connector Terminal Front combination lamp connector Terminal E122 27 RH E13 3 Yes 28 LH E45 OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-239939-S09181280512006080300000) ". NG: Check for short circuits and open circuits in harness between IPDM E/R and headlamps. Repair as necessary.

High-Beam Indicator Lamp Does Not Illuminate

1. CAN COMMUNICATION SYSTEM INSPECTION Inspect CAN communication system. Refer to " «CAN COMMUNICATION»(ref-239941-S36413072992006080300000) ". OK or NG OK: Replace combination meter. Refer to " «COMBINATION METER»(ref-239968-S31189908282006080400000) ". NG: Repair as necessary.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. CHECK COMBINATION SWITCH INPUT SIGNAL Select "BCM" on CONSULT-II. With "HEAD LAMP" data monitor, make sure "HEAD LAMP SW 1" and "HEAD LAMP SW 2" turns ONOFF linked with operation of lighting switch. When lighting switch is in 2ND position: HEAD LAMP SW 1 ON : HEAD LAMP SW 2 ON OK or NG OK: GO TO 2. NG: Check lighting switch. Refer to " «COMBINATION SWITCH INSPECTION»(ref-239962-S11371497032006080400000) ".
2. HEADLAMP ACTIVE TEST Select "IPDM E/R" on CONSULT-II, and select "ACTIVE TEST" on "SELECT DIAG MODE" screen. Select "LAMPS" on "SELECT TEST ITEM" screen. Touch "LO" on "ACTIVE TEST" screen. Make sure headlamp low beam operates. Headlamp low beam should operate. OK or NG OK: GO TO 3. NG: GO TO 4.
3. CHECK IPDM E/R Select "IPDM E/R" on CONSULT-II, and select "DATA MONITOR" on "SELECT DIAG MODE" screen. Make sure "HL LO REQ" turns ON when lighting switch is in 2ND position. When lighting switch is in 2ND position: HL LO REQ ON OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-239939-S09181280512006080300000) ". NG: Replace BCM. Refer to " «REMOVAL AND INSTALLATION OF BCM»(ref-239966-S24017391232006080300000) ".
4. CHECK HEADLAMP INPUT SIGNAL Turn ignition switch OFF. Disconnect front combination lamp RH and LH connectors. Turn ignition switch ON. Select "IPDM E/R" on CONSULT-II, and select "ACTIVE TEST" on "SELECT DIAG MODE" screen. Select "LAMPS" on "SELECT TEST ITEM" screen. Touch "LO" on "ACTIVE TEST" screen. When headlamp low beam is operating, check voltage between front combination lamp RH and LH harness connectors and ground. FRONT COMBINATION LAMP - VOLTAGE TABLE Terminals (-) Voltage (+) Front combination lamp connector Terminal RH E12 1 Ground Battery voltage LH E44 OK or NG OK: GO TO 6. NG: GO TO 5.
5. CHECK HEADLAMP CIRCUIT Turn ignition switch OFF. Disconnect IPDM E/R connector. Check continuity between IPDM E/R harness connector terminal and front combination lamp harness connector terminal. IPDM E/R - FRONT COMBINATION LAMP - CONTINUITY TABLE A B Continuity IPDM E/R connector Terminal Front combination lamp connector Terminal E122 20 RH E12 1 Yes 30 LH E44 OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-239939-S09181280512006080300000) ". NG: Repair harness or connector.
6. CHECK HEADLAMP GROUND Turn ignition switch OFF. Check continuity between front combination lamp harness connector terminal and ground. FRONT COMBINATION LAMP - VOLTAGE TABLE Terminals Voltage Front combination lamp connector Terminal RH E12 2 Ground Battery voltage LH E44 OK or NG OK: Check front combination lamp connector for damage or poor connection. Repair as necessary. NG: Repair harness or connector.

Scheme 22

Scheme 23

Scheme 24

1. BULB INSPECTION Inspect inoperative headlamp bulb. OK or NG OK: GO TO 2. NG: Replace headlamp bulb. Refer to " «HEADLAMP (OUTER SIDE), FOR LOW BEAM»(ref-239962-S26495164772006080400000) ".
2. CHECK POWER TO HEADLAMP Disconnect inoperative front combination lamp connector. Turn the low beam headlamps ON. Check voltage between inoperative front combination lamp connector terminal and ground. INOPERATIVE FRONT COMBINATION LAMP - VOLTAGE TABLE Terminals (-) Voltage (Approx.) (+) Front combination lamp connector Terminal RH E12 1 Ground Battery voltage LH E44 OK or NG OK: GO TO 3. NG: GO TO 4.
3. CHECK HEADLAMP GROUND Turn the low beam headlamps OFF. Check continuity between inoperative front combination lamp connector terminal and ground. INOPERATIVE FRONT COMBINATION LAMP - CONTINUITY TABLE Terminals Continuity Front combination lamp connector Terminal RH E12 2 Ground Yes LH E44 OK or NG OK: Check headlamp and IPDM E/R connector. Repair as necessary. NG: Repair open circuit in harness between inoperative headlamp and ground.
4. INSPECTION BETWEEN IPDM E/R AND HEADLAMPS Disconnect IPDM E/R connector. Check continuity between IPDM E/R harness connector terminals and inoperative front combination lamp harness connector terminals. IPDM E/R - INOPERATIVE FRONT COMBINATION LAMP - CONTINUITY TABLE A B Continuity IPDM E/R connector Terminal Front combination lamp connector Terminal E122 20 RH E12 1 Yes 30 LH E44 OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-239939-S09181280512006080300000) ". NG: Check for short circuits and open circuits in harness between IPDM E/R and headlamps. Repair as necessary.

Scheme 25

Scheme 26

1. CHECK COMBINATION SWITCH INPUT SIGNAL Select "BCM" on CONSULT-II. With "HEAD LAMP" data monitor, make sure "HEAD LAMP SW 1" and "HEAD LAMP SW 2" turns ONOFF linked with operation of lighting switch. When lighting switch is in OFF position: HEAD LAMP SW 1 OFF : HEAD LAMP SW 2 OFF OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-239939-S09181280512006080300000) ". NG: GO TO 2.
2. CHECK LIGHTING SWITCH Check lighting switch. Refer to " «COMBINATION SWITCH INSPECTION»(ref-239962-S11371497032006080400000) ". OK or NG OK: GO TO 3. NG: Replace lighting switch. Refer to " «REMOVAL AND INSTALLATION»(ref-239962-S33953714992006080400000) ".
3. CHECKING CAN COMMUNICATIONS BETWEEN BCM AND IPDM E/R Select "BCM" on CONSULT-II and perform self-diagnosis for BCM. Display of self-diagnosis results NO DTC: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-239939-S09181280512006080300000) ". CAN COMM CIRCUIT: Refer to " «CAN COMMUNICATION INSPECTION USING CONSULT-II (SELF-DIAGNOSIS)»(ref-239966-S14070209852006080300000) ".

Scheme 27

For details, refer to the regulations in your state.

Before performing aiming adjustment, check the following.

1. Ensure all tires are inflated to correct pressure.
2. Place vehicle and screen on level surface.
3. Ensure there is no load in vehicle other than the driver (or equivalent weight placed in driver's position). Coolant and engine oil filled to correct level and fuel tank full.
4. Confirm spare tire, jack and tools are properly stowed.

The headlamp system for Canada vehicles is equipped with a daytime light control unit that activates the high beam headlamps at approximately half illumination whenever the engine is running. If the parking brake is applied before the engine is started the daytime lights will not be illuminated. The daytime lights will illuminate once the parking brake is released. Thereafter, the daytime lights will continue to operate when the parking brake is applied.

Battery saver system is controlled by the BCM (body control module).

Power is supplied at all times

1. to headlamp high relay, located in the IPDM E/R (intelligent power distribution module engine room), and
2. to headlamp low relay, located in the IPDM E/R, and
3. through 50A fusible link (letter j, located in the fuse and fusible link box)
4. to BCM terminal 55, and
5. through 15A fuse [No. 3, located in the fuse block (J/B)]
6. to BCM terminal 42, and
7. through 15A fuse (No. 29, located in the fuse and fusible link box)
8. to daytime light control unit terminals 2 and 3.

With the ignition switch in the ON or START position, power is supplied

1. through 10A fuse [No. 12, located in the fuse block (J/B)]
2. to daytime light control unit terminal 12, and
3. through 10A fuse [No. 16, located in the fuse block (J/B)]
4. to BCM terminal 38.

With the ignition switch in the ACC or ON position, power is supplied

1. through 10A fuse [No. 4, located in the fuse block (J/B)]
2. to BCM terminal 11.

With the ignition switch in the START position, power is supplied

1. through 10A fuse [No. 9, located in the fuse block (J/B)]
2. to daytime light control unit terminal 1.

Ground is supplied

1. to daytime light control unit terminal 9
2. through grounds E9, E15 and E24, and
3. to BCM terminal 52
4. through grounds M57, M61 and M79.

With the lighting switch in 2ND position, the BCM receives input requesting the headlamps to illuminate. This input is communicated to the IPDM E/R across the CAN communication lines. The CPU (central processing unit) of the IPDM E/R controls the headlamp low relay coil. When energized, this relay directs power

1. through 15A fuse (No. 45, located in the IPDM E/R)
2. through IPDM E/R terminal 30
3. to front combination lamp LH terminal 1, and
4. through 15A fuse (No. 36, located in the IPDM E/R)
5. through IPDM E/R terminal 20
6. to front combination lamp RH terminal 1.

Ground is supplied

1. to front combination lamp LH and RH terminal 2
2. through grounds E9, E15 and E24.

With power and ground supplied, low beam headlamps illuminate.

With the lighting switch in 2ND position and placed in HIGH or PASS position, the BCM receives input requesting the headlamp high beams to illuminate. This input is communicated to the IPDM E/R across the CAN communication lines. The CPU of the combination meter controls the ON/OFF status of the HIGH BEAM indicator.

The CPU of the IPDM E/R controls the headlamp high relay coil. When energized, this relay directs power

1. through 10A fuse (No. 40, located in the IPDM E/R)
2. through IPDM E/R terminal 27
3. to daytime light relay terminal 2
4. through daytime light relay terminal 1
5. to grounds E9, E15 and E24.

When energized, the daytime light relay directs power

1. through daytime light relay terminal 3
2. to daytime light control unit terminal 8 and
3. to front combination lamp RH terminal 3.

Also when the headlamp high relay is energized, it directs power

1. through 10A fuse (No. 38, located in the IPDM E/R)
2. through IPDM E/R terminal 28
3. to daytime light control unit terminal 5
4. through daytime light control unit terminal 6
5. to front combination lamp LH terminal 3.

Ground is supplied

1. to front combination lamp RH terminal 4
2. through grounds E9, E15 and E24, and
3. to front combination lamp LH terminal 4
4. to daytime light control unit terminal 7
5. through daytime light control unit terminal 9
6. through grounds E9, E15 and E24.

With power and ground supplied, the high beam headlamps illuminate.

For auto light operation, refer to " SYSTEM DESCRIPTION ".

DAYTIME LIGHT OPERATION

With the engine running, the lighting switch in the OFF or 1ST position and parking brake released, power is supplied

1. through daytime light control unit terminal 6
2. to front combination lamp LH terminal 3
3. through front combination lamp LH terminal 4
4. to daytime light control unit terminal 7, and
5. through daytime light control unit terminal 8
6. to front combination lamp RH terminal 3.

Ground is supplied

1. to front combination lamp RH terminal 4
2. through grounds E9, E15 and E24.

Because the high beam headlamps are now wired in series, they operate at half illumination.

OPERATION

After starting the engine with the lighting switch in the "OFF" or 1ST position, the headlamp high beam automatically turns on. Lighting switch operations other than the above are the same as conventional light systems.

LIGHTING SWITCH OPERATION TABLE

Refer to " CAN COMMUNICATION ".

Scheme 28

Automatically turns on/off the parking lamps and the headlamps in accordance with ambient light.

Timing for when the lamps turn on/off can be selected using four modes.

Refer to " CAN COMMUNICATION ".

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM" on "SELECT SYSTEM" screen. If "BCM" is not indicated, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-239935-S20808400922006080400000) ".
4. Touch "HEAD LAMP" on "SELECT TEST ITEM" screen.

1. Touch "HEAD LAMP" on "SELECT TEST ITEM" screen.
2. Touch "WORK SUPPORT" on "SELECT DIAG MODE" screen.
3. Touch "CUSTOM A/LIGHT SETTING" or "ILL DELAY SET" on "SELECT WORK ITEM" screen.
4. Touch "START".
5. Touch "MODE 1-4" of setting to be changed (CUSTOM A/LIGHT SETTING). Touch "MODE1-8" of setting to be changed (ILL DELAY SET).
6. Touch "CHANGE SETT".
7. The setting will be changed and "CUSTOMIZING COMPLETED" will be displayed.
8. Touch "END".

1. Touch "HEAD LAMP" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on the "SELECT MONITOR ITEM" screen. DATA MONITOR TABLE ALL SIGNALS Monitors all the signals. SELECTION FROM MENU Selects and monitors individual signal.
4. Touch "START".
5. When "SELECTION FROM MENU" is selected, touch individual items to be monitored. When "ALL SIGNALS" is selected, all the items will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

1. Touch "HEAD LAMP" on "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching "BACK" deactivates the operation.

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn the ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "IPDM E/R" on "SELECT SYSTEM" screen. If "IPDM E/R" is not displayed, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-239935-S20808400922006080400000) ".
4. Select the desired part to be diagnosed on the "SELECT DIAG MODE" screen.

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch "ALL SIGNALS""MAIN SIGNALS" or "SELECTION FROM MENU" on the "SELECT MONITOR ITEM" screen. DATA MONITOR TABLE ALL SIGNALS All items will be monitored. MAIN SIGNALS Monitor the predetermined item. SELECTION FROM MENU Select any item for monitoring.
3. Touch "START".
4. Touch the required monitoring item on "SELECTION FROM MENU". In "ALL SIGNALS", all items are monitored. In "MAIN SIGNALS", predetermined items are monitored.
5. Touch "RECORD" while monitoring to record the status of the item being monitored. To stop recording, touch "STOP".

All Items, Main Items, Select Item Menu

ITEM MENU TABLE

Note. Perform monitoring of IPDM E/R data with the ignition switch ON. When the ignition switch is at ACC, the display may not be correct.

1. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
2. Touch item to be tested, and check operation.
3. Touch "START".
4. Touch "STOP" while testing to stop the operation. ACTIVE TEST DESCRIPTION TABLE Test item CONSULT-II screen display Description Tail lamp relay output TAIL LAMP Allows tail lamp relay to operate by switching operation ON-OFF at your option. Headlamp relay (HI, LO) output LAMPS Allows headlamp relay (HI, LO) to operate by switching operation (OFF, HI, LO) at your option (Headlamp high beam repeats ON-OFF every 1 second). Front fog lamp relay output Allows fog lamp relay to operate by switching operation ON-OFF at your option. Cornering lamp relay (RH, LH) output CORNERING LAMP Allows cornering lamp relay (RH, LH) to operate by switching operation ON-OFF at your option.

Control of the fog lamps is dependent upon the position of the combination switch (lighting switch). The lighting switch must be in the 2ND position or AUTO position (LOW beam is ON) for front fog lamp operation.

When the lighting switch is placed in the fog lamp position, the BCM (body control module) receives input signal requesting the fog lamps to illuminate. When the headlamps are illuminated, this input signal is communicated to the IPDM E/R (intelligent power distribution module engine room) across the CAN communication lines. The CPU (central processing unit) of the IPDM E/R controls the front fog lamp relay coil. When activated, this relay directs power to the front fog lamps.

FOG LAMP OPERATION

The fog lamp switch is built into the combination switch. The lighting switch must be in the 2ND position or AUTO position (LOW beam is ON) and the fog lamp switch must be ON for fog lamp operation.

With the fog lamp switch in the ON position, the CPU of the IPDM E/R grounds the coil side of the fog lamp relay. The fog lamp relay then directs power

1. through IPDM E/R terminal 37
2. to front fog lamp LH terminal +, and
3. through IPDM E/R terminal 36
4. to front fog lamp RH terminal +.

Ground is supplied

1. to front fog lamp LH and RH terminal
2. through grounds E9, E15 and E24.

With power and ground supplied, the front fog lamps illuminate.

Refer to " CAN COMMUNICATION ".

TURN SIGNAL OPERATION

When the ignition switch is in the ON or START position, power is supplied

1. through 10A fuse [No. 16, located in the fuse block (J/B)]
2. to BCM terminal 38, and
3. through 10A fuse [No. 14, located in the fuse block (J/B)]
4. to combination meter terminal 30.

Ground is supplied

1. to BCM terminal 52 and
2. to combination meter terminal 32
3. through grounds M57, M61 and M79.

HAZARD LAMP OPERATION

Power is supplied at all times

1. through 50A fusible link (letter j , located in the fuse and fusible link box)
2. to BCM terminal 55, and
3. through 15A fuse [No. 19, located in the fuse block (J/B)]
4. to combination meter terminal 31.

Ground is supplied

1. to BCM terminal 52 and
2. to combination meter terminal 32
3. through grounds M57, M61 and M79.

When the hazard switch is depressed, ground is supplied

1. to BCM terminal 29
2. through hazard switch terminal 2
3. through hazard switch terminal 1
4. through grounds M57, M61 and M79.

When the hazard switch is depressed, the BCM, interpreting it as hazard warning lamps are ON, outputs turn signal from BCM terminals 45 and 46.

The BCM supplies power

1. through BCM terminals 45 and 46
2. to front combination lamp LH and RH terminal 6
3. through front combination lamp LH and RH terminal 5
4. to grounds E9, E15 and E24, and
5. to rear combination lamp LH terminal 3
6. through rear combination lamp LH terminal 5
7. to grounds B7 and B19, and
8. to rear combination lamp RH terminal 3
9. through rear combination lamp RH terminal 5
10. to grounds B117 and B132.

BCM sends signal to combination meter through CAN communication lines and turns on turn signal indicator lamps within combination meter.

REMOTE KEYLESS ENTRY SYSTEM OPERATION

Power is supplied at all times

1. through 50A fusible link (letter j , located in the fuse and fusible link box)
2. to BCM terminal 55, and
3. through 15A fuse [No. 3, located in the fuse block (J/B)]
4. to BCM terminal 42, and
5. through 15A fuse [No. 19, located in the fuse block (J/B)]
6. to combination meter terminal 31.

Ground is supplied

1. to BCM terminal 52 and
2. to combination meter terminal 32
3. through grounds M57, M61 and M79.

When the remote keyless entry system is triggered by input from the key fob, the BCM, interpreting it as turn signal is ON, outputs turn signal from BCM terminals 45 and 46.

The BCM supplies power

1. through BCM terminals 45 and 46
2. to front combination lamp LH and RH terminal 6
3. through front combination lamp LH and RH terminal 5
4. to grounds E9, E15 and E24, and
5. to rear combination lamp LH terminal 3
6. through rear combination lamp LH terminal 5
7. to grounds B7 and B19, and
8. to rear combination lamp RH terminal 3
9. through rear combination lamp RH terminal 5
10. to grounds B117 and B132.

BCM sends signal to combination meter through CAN communication lines and turns on turn signal indicator lamps within combination meter.

With power and input supplied, the BCM controls the flashing of the hazard warning lamps when key fob is used to activate the remote keyless entry system.

Refer to " CAN COMMUNICATION ".

Scheme 29

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM" on "SELECT SYSTEM" screen. If "BCM" is not indicated, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-239935-S20808400922006080400000) ".
4. Touch "FLASHER" on "SELECT TEST ITEM" screen.

1. Touch "FLASHER" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on the "SELECT MONITOR ITEM" screen. DATA MONITOR TABLE ALL SIGNALS Monitors all the signals. SELECTION FROM MENU Selects and monitors the individual signal.
4. Touch "START".
5. When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is selected, all the items will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

1. Touch "FLASHER" on "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching "BACK" deactivates the operation.

CORNERING LAMP OPERATION

When the ignition switch is in the ON or START position, power is supplied

1. to ignition relay, located in the IPDM E/R, and
2. through 10A fuse [No. 16, located in the fuse block (J/B)]
3. to BCM terminal 38.

Ground is supplied

1. to BCM terminal 52
2. through grounds M57, M61 and M79, and
3. to IPDM E/R terminals 38 and 60
4. through grounds E9, E15 and E24.

Refer to " CAN COMMUNICATION ".

Scheme 30

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "IPDM E/R" on "SELECT SYSTEM" screen. If "IPDM E/R" is not indicated, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-239935-S20808400922006080400000) ".
4. Touch appropriate item"DATA MONITOR" or "ACTIVE TEST" on "SELECT DIAG MODE" screen.

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch "ALL SIGNALS" or "SELECTION FROM MENU" on "SELECT MONITOR ITEM" screen. DATA MONITOR TABLE ALL SIGNALS Monitors all the signals. SELECTION FROM MENU Selects and monitors the individual signal.
3. Touch "START".
4. When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is selected, all the items will be monitored.
5. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

All Items, Main Items, Select Item Menu

ITEM MENU TABLE

Note. Perform monitoring of IPDM E/R data with the ignition switch ON. When the ignition switch is at ACC, the display may not be correct.

1. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
2. Touch "CORNERING LAMP" on "SELECT TEST ITEM" screen.
3. Touch "RH" or "LH" item to be tested and check operation of the selected item.
4. During the operation check, touching "BACK" deactivates the operation.

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM" on "SELECT SYSTEM" screen. If "BCM" is not indicated, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-239935-S20808400922006080400000) ".
4. Touch "COMB SW" on "SELECT TEST ITEM" screen.

1. Touch "COMB SW" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on "SELECT MONITOR ITEM" screen. DATA MONITOR TABLE ALL SIGNALS Monitors all the signals. SELECTION FROM MENU Selects and monitors individual signal.
4. Touch "START".
5. When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is selected, all the signals will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

Power is supplied at all times

1. through 10A fuse [No. 20, located in fuse block (J/B)]
2. to stop lamp switch terminal 1.

When the brake pedal is pressed, the stop lamp switch is closed and power is supplied

1. through stop lamp switch terminal 2
2. to rear combination lamp LH and RH terminal 1, and
3. to high-mounted stop lamp terminal +.

Ground is supplied

1. to rear combination lamp LH terminal 5
2. through grounds B7 and B19, and
3. to rear combination lamp RH terminal 5
4. through grounds B117 and B132, and
5. to high-mounted stop lamp terminal
6. through grounds D403 and D404.

With power and ground supplied, the stop lamps illuminate.

Control of the parking, license plate, and tail lamp operation is dependent upon the position of the lighting switch (combination switch). When the lighting switch is placed in the 1ST position, the BCM (body control module) receives input signal requesting the parking, license plate and tail lamps to illuminate. This input signal is communicated to the IPDM E/R (intelligent power distribution module engine room) across the CAN communication lines. The CPU (central processing unit) of the IPDM E/R controls the tail lamp relay coil. This relay, when energized, directs power to the parking, license plate and tail lamps, which then illuminate.

Power is supplied at all times

1. to ignition relay, located in the IPDM E/R, and
2. through 15A fuse (No. 41, located in the IPDM E/R)
3. to tail lamp relay, located in the IPDM E/R, and
4. through 15A fuse (No. 34 located in the IPDM E/R)
5. to CPU of the IPDM E/R, and
6. through 50A fusible link (letter j, located in the fuse and fusible link box)
7. to BCM terminal 55, and
8. through 15A fuse [No. 3, located in the fuse block (J/B)]
9. to BCM terminal 42.

With the ignition switch in the ON or START position, power is supplied

1. to ignition relay, located in the IPDM E/R, and
2. through 10A fuse [No. 16, located in the fuse block (J/B)]
3. to BCM terminal 38.

With the ignition switch in the ACC or ON position, power is supplied

1. through 10A fuse [No. 4, located in the fuse block (J/B)]
2. to BCM terminal 11.

Ground is supplied

1. to BCM terminal 52
2. through grounds M57, M61 and M79, and
3. to IPDM E/R terminals 38 and 60
4. through grounds E9, E15 and E24.

OPERATION BY LIGHTING SWITCH

With the lighting switch in the 1ST or 2ND position (or if the auto light system is activated), the BCM receives input signal requesting the parking, license plate and tail lamps to illuminate. This input signal is communicated to the IPDM E/R across the CAN communication lines. The CPU in the IPDM E/R controls the tail lamp relay coil, which when energized, directs power

1. through IPDM E/R terminal 22
2. to front combination lamp LH and RH terminal 4
3. to license plate lamp LH and RH terminal +
4. to rear combination lamp LH and RH terminal 2.

Ground is supplied

1. to front combination lamp LH and RH terminal 5
2. through grounds E9, E15 and E24, and
3. to license plate lamp LH and RH terminal
4. through grounds D403 and D404, and
5. to rear combination lamp LH terminal 5
6. through grounds B7 and B19, and
7. to rear combination lamp RH terminal 5
8. through grounds B117 and B132.

With power and ground supplied, the parking, license plate and tail lamps illuminate.

Refer to " CAN COMMUNICATION ".

Scheme 31

Power is supplied at all times

1. through 20A fuse (No. 24, located in the fuse and fusible link box)
2. to trailer tow control unit terminal 7.

Ground is supplied

1. to trailer tow control unit terminal 5, and
2. to trailer connector terminal 5
3. through ground B307.

TRAILER TAIL LAMP OPERATION

With the lighting switch in the parking and tail lamp ON (1ST) position, AUTO position (and the auto light system is activated) or headlamp ON (2ND) position, power is supplied

1. through rear combination lamp LH
2. to trailer tow control unit terminal 3.

The trailer tail lamps are controlled by the trailer tow control unit. The trailer tow control unit supplies power

1. through trailer tow control unit terminal 1
2. to trailer connector terminal 1.

TRAILER STOP, TURN SIGNAL AND HAZARD LAMP OPERATION

The trailer stop, turn signal and hazard lamps are all controlled by the trailer tow control unit. The trailer tow control unit regulates the amount of voltage supplied to the trailer lamps. If either turn signal or the hazard lamps are turned on and the trailer tow control unit gets a brake lamp input, the trailer tow control unit supplies more voltage to the trailer lamps to make them illuminate brighter.

Stop lamp input is supplied

1. through rear combination lamp LH
2. to trailer tow control unit terminal 8.

Left turn signal and hazard lamp input is supplied

1. through rear combination lamp LH
2. to trailer tow control unit terminal 4.

Right turn signal and hazard lamp input is supplied

1. through rear combination lamp RH
2. to trailer tow control unit terminal 9.

Based on the stop lamp, turn signal lamp and hazard lamp inputs to the trailer tow control unit, power is supplied to trailer stop/turn lamp LH

1. through trailer tow control unit terminal 2
2. to trailer harness connector terminal 2.

Power is also supplied to trailer stop/turn lamp RH

1. through trailer tow control unit terminal 6
2. to trailer harness connector terminal 6.

When lamps on demand switch is in DOOR position, room/map lamp and personal lamp ON/OFF is controlled by timer according to signals from switches including key switch, front door switch LH, unlock signal from key fob, door lock and unlock switch, key cylinder switch, ignition switch.

When room/map lamp and personal lamp turns ON, there is a gradual brightening over 1 second. When room/map lamp and personal lamp turns OFF, there is a gradual dimming over 1 second.

The room/map lamp and personal lamp timer is controlled by the BCM (body control module).

Room/map lamp and personal lamp timer control settings can be changed with CONSULT-II.

Ignition keyhole illumination turns ON when front door LH is opened (door switch ON) or key is removed from key cylinder. Illumination turns OFF when front door LH is closed (door switch OFF).

Step and foot lamp turns ON when front or rear doors are opened (door switch ON). Lamp turns OFF when front and rear doors are closed (all door switches OFF).

SWITCH OPERATION

When front door switch LH is ON (door is opened), ground is supplied

1. to ignition keyhole illumination terminal
2. through BCM terminal 1.

And power is supplied

1. through BCM terminal 41
2. to ignition keyhole illumination terminal +.

When any door switch is ON (door is opened), ground is supplied

1. to front step lamp LH and RH and foot lamp LH and RH terminal
2. through BCM terminal 47.

And power is supplied

1. through BCM terminal 41
2. to front step lamp LH and RH terminal +
3. to puddle lamp LH and RH terminal 1 (if equipped)
4. to running board lamps pre-wiring terminal 2
5. to foot lamp LH and RH terminal +.

When room/map lamps switch is ON, ground is supplied

1. to room/map lamps terminal 3
2. through grounds M57, M61 and M79.

And power is supplied

1. through BCM terminal 41
2. to room/map lamps terminal 1.

When vanity lamp LH or RH is ON, ground is supplied

1. to vanity lamp LH and RH terminal
2. through grounds M57, M61 and M79.

And power is supplied

1. through BCM terminal 41
2. to vanity lamp LH and RH terminal +.

When personal lamps 2nd row LH or RH is ON, ground is supplied

1. to personal lamps 2nd row terminal 3 (without rear roof console assembly) or terminal 2 (with rear roof console assembly)
2. through grounds M57, M61 and M79.

And power is supplied

1. through BCM terminal 41
2. to personal lamps 2nd row terminal 1.

When personal lamps 3rd row LH or RH is ON, ground is supplied

1. to personal lamps 3rd row terminal 3 (without rear roof console assembly) or terminal 2 (with rear roof console assembly)
2. through grounds M57, M61 and M79.

And power is supplied

1. through BCM terminal 41
2. to personal lamps 3rd row terminal 1.

When cargo lamp is ON, ground is supplied

1. to cargo lamp terminal 1
2. through grounds M57, M61 and M79.

And power is supplied

1. through BCM terminal 41
2. to cargo lamp terminal 2.

ROOM LAMP TIMER OPERATION

When lamps on demand switch is in DOOR position and when all conditions below are met, BCM performs timer control (maximum 30 seconds) for interior room/map lamp ON/OFF.

Power is supplied

1. through 15A fuse [No. 19, located in the fuse block (J/B)]
2. to key switch terminal 1.

Key is removed from ignition key cylinder (key switch OFF), power will not be supplied to BCM terminal 37.

Ground is supplied

1. to BCM terminal 22
2. through main power window and door lock/unlock switch terminal 14 (with rear power vent windows) or 12 (without rear power vent windows).

At the time that front door LH is opened, BCM detects that front door LH is unlocked. It determines that interior room/map lamp timer operation conditions are met and turns the interior room/map lamp ON for 30 seconds.

Key is in ignition key cylinder (key switch ON), power is supplied

1. through key switch terminal 2
2. to BCM terminal 37.

When key is removed from key switch (key switch OFF), power supply to BCM terminal 37 is terminated. BCM detects that key has been removed, determines that interior room/map lamp timer conditions are met, and turns the interior room/map lamp ON for 30 seconds.

When front door LH opens --> closes and the key is not inserted in the key switch (key switch OFF), BCM terminal 62 changes between 0V (door open) --> 12V (door closed). The BCM determines that conditions for interior room/map lamp operation are met and turns the interior room/map lamp ON for 30 seconds.

Timer control is canceled under the following conditions.

1. Front door LH is locked [when locked with key fob, main power window and door lock/unlock switch or front door lock assembly LH (key cylinder switch)]
2. Front door LH is opened (front door switch LH turns ON)
3. Ignition switch ON.

Scheme 32

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM" on "SELECT SYSTEM" screen. If "BCM" is not indicated, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-239935-S20808400922006080400000) ".
4. Touch "INT LAMP" on "SELECT TEST ITEM" screen.

1. Touch "INT LAMP" on "SELECT TEST ITEM" screen.
2. Touch "WORK SUPPORT" on "SELECT DIAG MODE" screen.
3. Touch "SET I/L D-UNLCK INTCON" on "SELECT WORK ITEM" screen.
4. Touch "START".
5. Touch "CHANGE SETT".
6. The setting will be changed and "CUSTOMIZING COMPLETED" will be displayed.
7. Touch "END".

1. Touch "INT LAMP" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on "SELECT MONITOR ITEM" screen.
4. Touch "START". DATA MONITOR TABLE ALL SIGNALS Monitors all the signals. SELECTION FROM MENU Selects and monitors the individual signal.
5. When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is selected, all the items will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

1. Touch "INT LAMP" on "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching "BACK" deactivates the operation.

Control of the illumination lamps operation is dependent upon the position of the lighting switch (combination switch). When the lighting switch is placed in the 1ST or 2ND position (or if the auto light system is activated) the BCM (body control module) receives input signal requesting the illumination lamps to illuminate. This input signal is communicated to the IPDM E/R (intelligent power distribution module engine room) across the CAN communication lines. The CPU (central processing unit) of the IPDM E/R controls the tail lamp relay. This relay, when energized, directs power to the illumination lamps, which then illuminate.

Power is supplied at all times

1. to ignition relay, located in the IPDM E/R, and
2. through 15A fuse (No. 41, located in the IPDM E/R)
3. to tail lamp relay, located in the IPDM E/R, and
4. through 50A fusible link (letter j, located in the fuse and fusible link box)
5. to BCM terminal 55, and
6. through 15A fuse [No. 3, located in fuse block (J/B)]
7. to BCM terminal 42, and
8. through 15A fuse (No. 34, located in the IPDM E/R)
9. to CPU of the IPDM E/R, and
10. through 15A fuse [No.19, located in fuse block (J/B)]
11. to combination meter terminal 31, and
12. through BCM terminal 53
13. to main power window and door lock/unlock switch terminal 10, and
14. through BCM terminal 54
15. to power window and door lock/unlock switch RH terminal 10.

With the ignition switch in the ON or START position, power is supplied

1. to ignition relay, located in the IPDM E/R, and
2. through 10A fuse [No. 16, located in the fuse block (J/B)]
3. to BCM terminal 38, and
4. through 10A fuse [No. 14, located in the fuse block (J/B)]
5. to combination meter terminal 30.

With the ignition switch in the ACC or ON position, power is supplied

1. through 10A fuse [No. 4, located in the fuse block (J/B)]
2. to BCM terminal 11.

Ground is supplied

1. to BCM terminal 52 and
2. to combination meter terminal 32
3. through grounds M57, M61 and M79, and
4. to IPDM E/R terminals 38 and 60
5. through grounds E9, E15 and E24.

ILLUMINATION OPERATION BY LIGHTING SWITCH

With the lighting switch in the 1ST or 2ND position (or if the auto light system is activated), the BCM receives input signal requesting the illumination lamps to illuminate. This input signal is communicated to the IPDM E/R across the CAN communication lines. The CPU of the IPDM E/R controls the tail lamp relay which, when energized, directs power

1. through IPDM E/R terminal 22
2. to illumination control switch terminal 1
3. to A/T device (illumination) terminal 3
4. to TCS OFF switch (illumination) terminal 3 (without VDC)
5. to VDC OFF switch (illumination) terminal 3 (with VDC)
6. to AV switch (illumination) terminal 3
7. to hazard switch (illumination) terminal 3
8. to audio unit terminal 8
9. to rear sonar system OFF switch terminal 5 (with rear sonar system)
10. to lamps on demand switch terminal 5
11. to glove box lamp terminal +
12. to display unit terminal 4 (with monochrome display unit)
13. to display control unit terminal 14 (with color display unit)
14. to console lamp terminal 2
15. to door mirror remote control switch (illumination) terminal 16
16. to front air control terminal 23
17. to DVD player terminal 12 (with DVD entertainment system)
18. to NAVI control unit terminal 61 (with NAVI)
19. to automatic door main switch terminal 5 (with power sliding door)
20. to rear audio remote control unit terminal 6 (with rear audio remote control unit)
21. to rear air control terminal 1
22. through resistor-1 terminal 2 (with steering wheel audio control switches)
23. through resistor-1 terminal 1 (with steering wheel audio control switches)
24. through spiral cable terminal 26 (with steering wheel audio control switches)
25. to spiral cable (steering switch) terminal 18 (with steering wheel audio control switches).

Illumination is controlled

1. through illumination control switch terminal 2
2. to A/T device terminal 4
3. to TCS OFF switch terminal 4 (without VDC)
4. to VDC OFF switch terminal 4 (with VDC)
5. to AV switch terminal 4
6. to hazard switch terminal 4
7. to audio unit terminal 7
8. to rear sonar system OFF switch terminal 4 (with rear sonar system)
9. to lamps on demand switch terminal 6
10. to door mirror remote control switch (illumination) terminal 15
11. to front air control terminal 24
12. to DVD player terminal 10 (with DVD entertainment system)
13. to automatic door main switch terminal 7 (with power sliding door)
14. to combination meter terminal 10
15. through spiral cable terminal 27 (with steering wheel audio control switches)
16. to spiral cable (steering switch) terminal 21 (with steering wheel audio control switches).

Ground is supplied

1. to illumination control switch terminal 3
2. to glove box lamp terminal
3. to display unit terminal 6 (with monochrome display unit)
4. to display control unit terminal 3 (with color display unit)
5. to console lamp terminal 1
6. to main power window and door lock/unlock switch terminal 17 (with rear power vent windows) or terminal 15 (without rear power vent windows)
7. to power window and door lock/unlock switch RH terminal 11
8. to combination meter terminal 32
9. through grounds M57, M61 and M79, and
10. to rear audio remote control unit terminal 15 (with rear audio remote control unit)
11. through grounds B7 and B19, and
12. to NAVI control unit terminal 1 (with NAVI)
13. to rear air control terminal 3
14. through grounds B117 and B132.

With power and ground supplied, illumination lamps illuminate.

Refer to " CAN COMMUNICATION ".

Scheme 33

Scheme 34
