Power Supply, Ground & Circuit Elements: Wiring Nissan Quest III

Body Electrical 20 illustrations ~423 words

Schematic

For detailed ground distribution, refer to , " GROUND DISTRIBUTION ".

Scheme 24

Scheme 24: Schematic
Scheme 24: Schematic

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26: BATTERY POWER SUPPLY -IGNITION SW. IN ANY POSITION
Scheme 26: BATTERY POWER SUPPLY -IGNITION SW. IN ANY POSITION

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30: ACCESSORY POWER SUPPLY - IGNITION SW. IN ACC OR ON
Scheme 30: ACCESSORY POWER SUPPLY - IGNITION SW. IN ACC OR ON

Scheme 31

Scheme 31: IGNITION POWER SUPPLY - IGNITION SW. IN ON
Scheme 31: IGNITION POWER SUPPLY - IGNITION SW. IN ON

Scheme 32

Scheme 32: IGNITION POWER SUPPLY - IGNITION SW. IN ON AND/OR START
Scheme 32: IGNITION POWER SUPPLY - IGNITION SW. IN ON AND/OR START

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35: Fuse
Scheme 35: Fuse
  1. If fuse is blown, be sure to eliminate cause of incident before installing new fuse.
  2. Use fuse of specified rating. Never use fuse of more than specified rating.
  3. Do not partially install fuse, always insert it into fuse holder properly.
  4. Remove fuse for "ELECTRICAL PARTS (BAT)" if vehicle is not used for a long period of time.

HOW TO READ HARNESS LAYOUT

The following Harness Layouts use a map style grid to help locate connectors on the drawings

  1. Main Harness
  2. Engine Room Harness LH View (Engine Compartment)
  3. Engine Room Harness RH View (Engine Compartment)
  4. Engine Control Harness
  5. Body Harness and Rear Sonar Sensor Sub-harness
  6. Body No. 2 Harness and Fuel Tank Sub-harness

Scheme 36

Scheme 36: To use the grid reference
Scheme 36: To use the grid reference
  1. Find the desired connector number on the connector list.
  2. Find the grid reference.
  3. On the drawing, find the crossing of the grid reference letter column and number row.
  4. Find the connector number in the crossing zone.
  5. Follow the line (if used) to the connector.

Wiring Diagram Codes (Cell Codes)

Use the chart below to find out what each wiring diagram code stands for.

Refer to the wiring diagram code in the alphabetical index to find the location (page number) of each wiring diagram.

CodeSectionWiring Diagram Name
1STSIGATA/T 1st Signal
2NDSIGATA/T 2nd Signal
3RDSIGATA/T 3rd Signal
4THSIGATA/T 4th Signal
5THSIGATA/T 5th Signal
A/C, AATCAuto Air Conditioner
A/C, MMTCManual Air Conditioner
AF1B1ECAir Fuel Ratio Sensor 1 Bank 1
AF1B2ECAir Fuel Ratio Sensor 1 Bank 2
AF1HB1ECAir Fuel Ratio Sensor 1 Heater Bank 1
AF1HB2ECAir Fuel Ratio Sensor 1 Heater Bank 2
APPS1ECAccelerator Pedal Position Sensor
APPS2ECAccelerator Pedal Position Sensor
APPS3ECAccelerator Pedal Position Sensor
ASC/BSECASCD Brake Switch
ASC/SWECASCD Steering Switch
ASCBOFECASCD Brake Switch
ASCINDECASCD Indicator
AT/INDDIA/T Indicator Lamp
AUDIOAVAudio
AUT/DPSEAutomatic Drive Positioner
AUTO/LLTAuto Light Control
B/CLOSBLBack Door Auto Closure System
BA/FTSATA/T Fluid Temperature Sensor and TCM Power Supply
BACK/LLTBack-up Lamp
BRK/SWECBrake Switch
CANATCAN Communication Line
CANECCAN Communication Line
CANLANCAN System
CHARGESCCharging System
CHIMEDIWarning Chime
COOL/FECCooling Fan Control
COMBSWLTCombination Switch
COMMAVAudio Visual Communication System
CORNERLTCornering Lamps
D/LOCKBLPower Door Lock
DEFGWRear Window Defogger
DTRLLTHeadlamp - With Daytime Light System
DVDAVDVD Entertainment System
ECM/PWECECM Power Supply for Back-Up
ECTSECEngine Coolant Temperature Sensor
EGR/TSECEGR Temperature Sensor
EGRC1ECEGR Function
EGVC/VECEGR Volume Control Valve
EMNTECEngine Mount
ENGSSATEngine Speed Signal
ETC1ECElectric Throttle Control Function
ETC2ECThrottle Control Motor Relay
ETC3ECThrottle Control Motor
F/FOGLTFront Fog Lamp
F/LIDBLFuel Lid Opener
F/PUMPECFuel Pump
FTSATA/T Fluid Temperature Sensor
FTSPATA/T Fluid Temperature Sensor Failure
FTTSECFuel Tank Temperature Sensor
FUELB1ECFuel Injection System Bank 1
FUELB2ECFuel Injection System Bank 2
H/LAMPLTHeadlamp
HORNWWHorn
HSEATSEHeated Seat
I/MIRRGWInside Mirror (Auto Anti-Dazzling Mirror)
IATSECIntake Air Temperature Sensor
IGNSYSECIgnition System
ILLLTIllumination
INF/DAVVehicle Information and Integrated Switch System
INJECTECInjector
INT/LLTRoom/Map, Vanity, Cargo, Personal, Foot, Step, Puddle and Running Board Lamps
VCB1ECIntake Valve Timing Control Solenoid Valve Bank 1
IVCB2ECIntake Valve Timing Control Solenoid Valve Bank 2
KEYLESBLRemote Keyless Entry System
KSECKnock Sensor
LPSVATLine Pressure Solenoid Valve
LVRSWATA/T Device Lever Switch
MAFSECMass Air Flow Sensor
MAINATMain Power Supply and Ground Circuit
MAINECMain Power Supply and Ground Circuit
METERDISpeedometer, Tachometer, Temp. and Fuel Gauges
MIL/DLECMalfunction Indicator Lamp
MIRRORGWDoor Mirror
NATSBLNissan Anti-Theft System
NAVIAVNavigation System
NONDTCATNon-detectable Items
O2H2B1ECRear Heated Oxygen Sensor 2 Heater Bank 1
O2H2B2ECRear Heated Oxygen Sensor 2 Heater Bank 2
O2S2B1ECHeated Oxygen Sensor 2 Bank 1
O2S2B2ECHeated Oxygen Sensor 2 Bank 2
OVRCSVATOverrun Clutch Solenoid Valve
P/SCKTWWPower Socket
PC/AATLine Pressure Solenoid Valve
PC/BATShift Pressure Solenoid Valve
PC/CATPressure Control Solenoid Valve
PC/CSATPressure Control Solenoid Valve Failure
PEDALAPAdjustable Pedal System
PGC/VECEVAP Canister Purge Volume Control Solenoid Valve
PHSB1ECCamshaft Position Sensor (PHASE) (Bank 1)
PHSB2ECCamshaft Position Sensor (PHASE) (Bank 2)
PNP/SWATPark/Neutral Position Switch
PNP/SWECPark/Neutral Position Switch
POSECCrankshaft Position Sensor (POS)
POWERPGPower Supply Routing
PRE/SEECEVAP Control System Pressure Sensor
PS/SENECPower Steering Pressure Sensor
PWR/INATTCM Ignition Power
R/VIEWDIRear View Camera
RP/SENECRefrigerant Pressure Sensor
S/CLOSBLSlide Door Auto Closure System
SEATSEPower Seat
SEN/PWECSensor Power Supply
SFTFNCATUnusual Shifting
SHIFTATA/T Shift Lock System
SONARDIRear Sonar System
SROOFRFSunroof
SRSSRSSupplemental Restraint System
SSV/AATShift Solenoid Valve A
SSV/BATShift Solenoid Valve B
SSV/CATShift Solenoid Valve C
SSV/CSATShift Solenoid Valve C Failure
SSV/DATShift Solenoid Valve D
SSV/EATShift Solenoid Valve E
STARTSCStarting System
STOP/LLTStop Lamp
T/TOWLTTrailer Tow
T/WARNWTLow Tire Pressure Warning System
TAIL/LLTParking, License and Tail Lamps
TCCSIGATA/T TCC Signal (Lock Up)
TCVATTorque Converter Clutch Solenoid Valve
TPSATThrottle Position Sensor
TPS1ECThrottle Position Sensor
TPS2ECThrottle Position Sensor
TPS3ECThrottle Position Sensor
TRNSCVBLHOMELINK(R) Universal Transceiver
TRSA/TATTurbine Revolution Sensor
TRSCATTurbine Revolution Sensor
TURNLTTurn Signal and Hazard Warning Lamps
VDCBRCVehicle Dynamic Control System
VEHSECBLVehicle Security (Theft Warning) System
VENT/VECEVAP Canister Vent Control Valve
VIASECVariable Air Induction Control System
VIAS/VECVariable Air Induction Control System Valve
VSSA/TATVehicle Speed Sensor A/T (Revolution Sensor)
VSSATCATRevolution Sensor
VSSMTRATVehicle Speed Sensor Meter
W/ANTAVAudio Antenna
WARNDIWarning Lamps
WINDOWGWPower Window
WIP/RWWRear Wiper and Washer
WIPERWWFront Wiper and Washer

WIRING DIAGRAM CODES CHART

Scheme 37

Scheme 37: ENGINE COMPARTMENT
Scheme 37: ENGINE COMPARTMENT

Scheme 38

Scheme 38: PASSENGER COMPARTMENT
Scheme 38: PASSENGER COMPARTMENT

Scheme 39

Scheme 39
Scheme 39

HARNESS CONNECTOR (TAB-LOCKING TYPE)

  1. The tab-locking type connectors help prevent accidental looseness or disconnection.
  2. The tab-locking type connectors are disconnected by pushing or lifting the locking tab(s). Refer to the illustration below.

Refer to the next page for description of the slide-locking type connector.

CAUTIONDo not pull the harness or wires when disconnecting the connector.

[Example]

Scheme 40

Scheme 40
Scheme 40

HARNESS CONNECTOR (SLIDE-LOCKING TYPE)

  1. A new style slide-locking type connector is used on certain systems and components, especially those related to OBD.
  2. The slide-locking type connectors help prevent incomplete locking and accidental looseness or disconnection.
  3. The slide-locking type connectors are disconnected by pushing or pulling the slider. Refer to the illustration below.
CAUTIONDo not pull the harness or wires when disconnecting the connector. Be careful not to damage the connector support bracket when disconnecting the connector.

[Example]

Scheme 41

Scheme 41
Scheme 41

HARNESS CONNECTOR (DIRECT-CONNECT SRS COMPONENT TYPE)

  1. SRS direct-connect type harness connectors are used on certain SRS components such as air bag modules and seat belt pre-tensioners.
  2. Always pull up to release black locking tab prior to removing connector from SRS component.
  3. Always push down to lock black locking tab after installing connector to SRS component. When locked, the black locking tab is level with the connector housing.

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43: Terminal Arrangement
Scheme 43: Terminal Arrangement
