EXCEPT FRONTIER & XTERRA

  1. Before adjusting alignment, check riding height. Riding height must be checked with vehicle on level floor and tires properly inflated. See «RIDING HEIGHT SPECIFICATIONS (EXCEPT FRONTIER & XTERRA)»(ref-4630-S16462331032000071100000) table. Bounce vehicle several times, and allow suspension to settle. Measure from ground to top center of wheel opening.
  2. Visually inspect vehicle for signs of abnormal height from front to rear and side to side. Check passenger and luggage compartments for extra heavy items and remove if present. If riding height is not within specification check, repair or replace suspension components.
ApplicationFront In. (mm)Rear In. (mm)
Altima
SE27.17 (690)26.69 (678)
GLE, GXE & XE27.20 (691)26.77 (680)
Maxima
1999
205/65 R1528.07 (713)28.15 (715)
215/65 R1528.07 (713)28.07 (713)
2000
205/65 R1527.56 (700)27.17 (690)
215/55 R1627.48 (698)26.89 (683)
225/50 R1727.80 (706)27.32 )694)
Pathfinder
2WD32.20 (818)33.70 (856)
4WD
235/70 R1532.09 (815)33.66 (855)
265/70 R1532.09 (815)33.31 (846)
Quest (1)30.39 (772)31.22 (793)
Sentra
1999
195/55 R1526.34 (669)25.59 (650)
2000
1.8L
185/65 R1425.55 (649)25.31 (643)
195/60 R15
Exc. Calif.25.94 (659)25.71 (653)
Calif. Model26.14 (664)25.91 (658)
2.0L
195/55 R1625.98 (660)25.67 (652)
195/60 R1525.91 (658)25.71 (653)
(1) Measurement is approximate.
(1)Measurement is approximate.

RIDING HEIGHT SPECIFICATIONS (EXCEPT FRONTIER & XTERRA)

FRONTIER & XTERRA

  1. Park vehicle on level ground, and bounce front of vehicle several times. When vehicle settles, measure distance from lower control arm pivot bolt center to ground. This is measurement "A". (Scheme 5)or (Scheme 6).
  2. On 2WD models, measure distance from lower tension rod (at lower control arm) attaching bolt to ground. On 4WD models, measure distance from bottom of steering stopper (on lower control arm) bracket to ground. On all models, this is measurement "B".
  3. Subtract measurement "B" from measurement "A". This is measurement "H". Measurement "H" should be within specifications. See «RIDE HEIGHT SPECIFICATIONS (FRONTIER & XTERRA)»(ref-4630-S32341172022000071100000) table. If measurement is not within specification, adjust torsion bar(s). Check wheel alignment. Adjust settings until correct.

Scheme 5

Scheme 5

Scheme 6

Scheme 6
ApplicationIn. (mm)
2WD
Allowable Limit (1)
Adjusting Range4.37-4.53 (111-115)
4WD
Allowable Limit (1)
Adjusting Range1.79-1.95 (46-50)
(1) Allowable limit specifications are not available from manufacturer.
(1)Allowable limit specifications are not available from manufacturer.

RIDE HEIGHT SPECIFICATIONS (FRONTIER & XTERRA)

JACKING & HOISTING

Note. Illustration given is not intended to represent exact structure of vehicle frames, underbody or body outline. Illustrations are provided only to give a point of reference when lifting or hoisting.

FLOOR JACK

Using a floor jack or hoist, lift vehicle at points indicated by shaded areas on frame. (Scheme 7)- (Scheme 12).

HOISTING

Position lift blocks on reinforced support points of side body panels, between front and rear wheels. If necessary, use wooden or rubber block to ensure proper clearance.

Scheme 7

Scheme 7: HOISTING

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12
