Cooling System Bleeding: Removal & Installation Nissan Quest I

Removal

1. Release fuel system pressure. See «FUEL PRESSURE RELEASE»(ref-49048-S06862619232001011500000) under REMOVAL & INSTALLATION. Remove front wheels, lower engine covers and right side cover. Drain coolant and remove radiator.
2. Disconnect all electrical connectors, hoses and cables affecting engine removal. Remove exhaust pipes, ball joints and drive axles.
3. Remove accessory drive belts. Remove power steering pump, A/C compressor and alternator. Raise vehicle. Set engine jack under engine and transaxle.
4. Remove left rear and right rear engine mounts. (Scheme 5) Remove bolts at crossmember. Lower engine assembly from vehicle.

Scheme 5

Installation

To install, reverse removal procedure. Replace rubber engine mounts if deteriorated. Fill cooling system and crankcase.

1. Release fuel system pressure. See «FUEL PRESSURE RELEASE»(ref-49048-S06862619232001011500000) under REMOVAL & INSTALLATION. Allow engine to cool to room temperature. Disconnect battery. Drain cooling system. Disconnect and label vacuum and coolant lines attached to intake manifold. Disconnect throttle linkage.
2. Remove intake manifold collector. Remove intake manifold using correct removal sequence. (Scheme 6) If necessary, remove fuel injectors and fuel rails as an assembly. Remove intake manifold.

Using NEW gaskets, install the intake manifold assembly. (Scheme 6) Tighten bolts to specification in reverse order of removal sequence. See TORQUE SPECIFICATIONS. To complete installation, reverse removal procedure.

Scheme 6

Allow engine to cool to room temperature. Remove exhaust manifold shields. Disconnect exhaust pipes from manifolds. Remove exhaust manifold bolts using proper sequence. (Scheme 7) Remove exhaust manifold.

Install exhaust manifold with NEW gasket. (Scheme 7) Tighten exhaust manifold bolts to specification in reverse order of removal. See TORQUE SPECIFICATIONS. To install remaining components, reverse removal procedure.

Scheme 7
