TORQUE CONVERTER CLUTCH CONTROL VALVE CONTROL
Lock-up Control System Diagram
Scheme 1
Lock-up Released
- In the lock-up released state, the torque converter clutch control valve is set into the unlocked state by the torque converter clutch solenoid and the lock-up apply pressure is drained. In this way, the torque converter clutch piston is not coupled.
Lock-up Applied
- In the lock-up applied state, the torque converter clutch control valve is set into the locked state by the torque converter clutch solenoid and lock-up apply pressure is generated. In this way, the torque converter clutch piston is pressed and coupled.
General Specification
| Applied model | VQ40DE engine | VK56DE engine | ||
|---|---|---|---|---|
| 2WD | 4WD | 4WD | ||
| Automatic transmission model | RE5R05A | |||
| Transmission model code number | 3GX1A | 3GX0B | 3DX3D | |
| Stall torque ratio | 1.76: 1 | 1.85: 1 | ||
| Transmission gear ratio | 1st | 3.842 | 3.827 | |
| 2nd | 2.353 | 2.368 | ||
| 3rd | 1.529 | 1.520 | ||
| 4th | 1.000 | 1.000 | ||
| 5th | 0.839 | 0.834 | ||
| Reverse | 2.765 | 2.613 | ||
| Recommended fluid | Genuine NISSAN Matic S ATF (1) | |||
| Fluid capacity | 10.3 liter (10-7/8 US qt, 9-1/8 Imp qt) | 10.6 liter (11-1/4 US qt, 9-3/8 Imp qt) | ||
| CAUTION: If Genuine NISSAN Matic S ATF is not available, Genuine NISSAN Matic J ATF may also be used. Using automatic transmission fluid other than Genuine NISSAN Matic S ATF or Matic J ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not covered by the NISSAN new vehicle limited warranty. | ||||
| (1) Refer to " FOR USA AND CANADA: FLUIDS AND LUBRICANTS " (United States and Canada) and " FOR MEXICO: FLUIDS AND LUBRICANTS " (Mexico). | ||||
