Automatic Transmission: Maintenance Nissan Pathfinder III рестайлинг

Checking the A/T Fluid (ATF)

Scheme 367

Scheme 368

Scheme 369

Scheme 370

Scheme 371

1. Before driving, the A/T fluid level can be checked at A/T fluid temperatures of 30° to 50° C (86° to 122° F) using the "COLD" range on the A/T fluid level gauge as follows: Park the vehicle on a level surface and set the parking brake. Start the engine and move the selector lever through each gear position. Shift the selector lever into the "P" position. Check the A/T fluid level with the engine idling. Remove the A/T fluid level gauge and wipe it clean with a lint-free paper. CAUTION: When wiping the A/T fluid from the A/T fluid level gauge, always use a lint-free paper, not a cloth. Re-insert the A/T fluid level gauge into the A/T fluid charging pipe until the cap contacts the top of the A/T fluid charging pipe as shown. CAUTION: To check A/T fluid level, insert the A/T fluid level gauge until the cap contacts the top of the A/T fluid charging pipe, with the gauge reversed from the normal inserted position. Remove the A/T fluid level gauge and note the A/T fluid level. If the A/T fluid level is at low side of range, add A/T fluid to the transmission through the A/T fluid charging pipe. CAUTION: Do not overfill the transmission with A/T fluid. Install the A/T fluid level gauge and the A/T fluid level gauge bolt. A/T fluid level gauge bolt: Refer to " «2WD: EXPLODED VIEW»(ref-519782-S12129575412012122900000) " (2WD) or " «4WD: EXPLODED VIEW»(ref-519782-S15494186702012122900000) " (4WD) .
2. Warm up the engine and transmission.
3. Check for any A/T fluid leaks.
4. Drive the vehicle to increase the A/T fluid temperature to 80° C (176° F).
5. Allow the A/T fluid temperature to fall to approximately 65°C (149°F). Use the CONSULT to monitor the A/T fluid temperature as follows: NOTE: The A/T fluid level will be significantly affected by the A/T fluid temperature as shown. Therefore monitor the A/T fluid temperature data using the CONSULT. Connect CONSULT to data link connector. Select "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT. Read out the value of "ATF TEMP 1".
6. Re-check the A/T fluid level at A/T fluid temperatures of approximately 65°C (149°F) using the "HOT" range on the A/T fluid level gauge as shown. The HOT range is between 50° - 80° C (122° - 176° F). CAUTION: When wiping the A/T fluid from the A/T fluid level gauge, always use lint-free paper, not a cloth. To check the A/T fluid level, insert the A/T fluid level gauge until the cap contacts the top of the A/T fluid charging pipe, with the gauge reversed from the normal inserted position as shown.
7. Check the A/T fluid condition. If the A/T fluid is very dark or has some burned smell, there may be an internal problem with the transmission. Refer to «WIRING DIAGRAM»(ref-519782-S13494545242012122900000) . Flush the transmission cooling system after repairing the transmission. If the A/T fluid contains frictional material (clutches, bands, etc.), replace the radiator and flush the transmission cooler lines using cleaning solvent and compressed air after repairing the transmission.
8. Install the A/T fluid level gauge in the A/T fluid charging pipe.
9. Tighten the A/T fluid level gauge bolt to specification. A/T fluid level gauge bolt: Refer to " «2WD: EXPLODED VIEW»(ref-519782-S12129575412012122900000) " (2WD) or " «4WD: EXPLODED VIEW»(ref-519782-S15494186702012122900000) " (4WD) .

Changing the A/T Fluid (ATF)

Scheme 372

Scheme 373

1. Drive the vehicle to warm up the A/T fluid to approximately 80° C (176° F).
2. Stop the engine.
3. Remove the A/T fluid level gauge.
4. Drain the A/T fluid from the drain plug hole, then install the drain plug with a new gasket. Refill the transmission with new A/T fluid. Always refill with the same volume as the drained A/T fluid. Use the A/T fluid level gauge to check the A/T fluid level as shown. Add A/T fluid as necessary. Drain plug: Refer to " «REMOVAL AND INSTALLATION»(ref-519782-S27780927392012122900000) ". To flush out the old A/T fluid from the transmission oil coolers, pour new A/T fluid into the A/T fluid charging pipe with the engine idling and at the same time drain the old A/T fluid from the auxiliary transmission oil cooler hose return line. When the color of the A/T fluid coming out of the auxiliary transmission oil cooler hose return line is about the same as the color of the new A/T fluid, flushing out the old A/T fluid is complete. The amount of new A/T fluid used for flushing should be 30% to 50% increase of the specified capacity. A/T fluid grade and capacity: Refer to " «FOR USA AND CANADA: INTRODUCTION TO PERIODIC MAINTENANCE»(ref-519787-S01912346392012122900000) " (United States and Canada) and " «FOR MEXICO: PERIODIC MAINTENANCE SCHEDULE»(ref-519787-S15489281182012122900000) " (Mexico) . CAUTION: If Genuine NISSAN Matic S ATF is not available, Genuine NISSAN Matic J ATF may also be used. Using automatic transmission fluid other than Genuine NISSAN Matic S or Matic J will cause deterioration in driveability. and may damage automatic transmission, which is not covered by the NISSAN new vehicle limited warranty. When filling the transmission with A/T fluid, do not spill the A/T fluid on any heat generating parts such as the exhaust manifold. Do not reuse the drain plug gasket.
5. Install the A/T fluid level gauge and tighten the A/T fluid level gauge bolt to specification. A/T fluid level gauge bolt: Refer to " «2WD: EXPLODED VIEW»(ref-519782-S12129575412012122900000) " (2WD) or " «4WD: EXPLODED VIEW»(ref-519782-S15494186702012122900000) " (4WD) .
6. Drive the vehicle to warm up the A/T fluid to approximately 80° C (176° F).
7. Check the fluid level and condition. If the A/T fluid is still dirty, repeat steps 2 through 6 .
8. Install the A/T fluid level gauge in the A/T fluid charging pipe and install the A/T fluid level gauge bolt.
9. Tighten the A/T fluid level gauge bolt to specification. A/T fluid level gauge bolt: Refer to " «2WD: EXPLODED VIEW»(ref-519782-S12129575412012122900000) " (2WD) or " «4WD: EXPLODED VIEW»(ref-519782-S15494186702012122900000) " (4WD) .

A/T Fluid Cooler Cleaning

Whenever an A/T is repaired, overhauled, or replaced, the A/T fluid cooler mounted in the radiator must be inspected and cleaned.

Metal debris and friction material, if present, can become trapped in the A/T fluid cooler. This debris can contaminate the newly serviced A/T or, in severe cases, can block or restrict the flow of A/T fluid. In either case, malfunction of the newly serviced A/T may result.

Debris, if present, may build up as A/T fluid enters the cooler inlet. It will be necessary to back flush the cooler through the cooler outlet in order to flush out any built up debris.

Scheme 374

Scheme 375

Scheme 376

1. Position a drain pan under the A/T inlet and outlet fluid cooler tube to cooler hose connection.
2. Put a different color matching mark on each cooler tube to cooler hose connection to aid in assembly. CAUTION: Use paint to make the matching mark. Do not damage the tubes or hose.
3. Disconnect the fluid cooler inlet and outlet rubber hoses from the steel cooler tubes. NOTE: Replace the cooler hoses if rubber material from the hose remains on the tube fitting.
4. Drain any A/T fluid from the cooler hose.
5. Insert the extension adapter hose of a can of Transmission Cooler Cleaner (Nissan P/N 999MP-AM006) into the cooler outlet hose. CAUTION: Wear safety glasses and rubber gloves when spraying the Transmission Cooler Cleaner. Spray cooler cleaner only with adequate ventilation. Avoid contact with eyes and skin. Do not breath vapors or spray mist.
6. Hold the hose and can as high as possible and spray Transmission Cooler Cleaner in a continuous stream into the cooler outlet hose until fluid flows out of the cooler inlet hose for 5 seconds.
7. Insert the tip of an air gun into the end of the cooler outlet hose.
8. Wrap a shop rag around the tip of the air gun and the cooler outlet hose.
9. Blow compressed air regulated to 5 - 9 kg/cm 2 (70 - 130 psi) through the cooler outlet hose for 10 seconds to force out any remaining fluid.
10. Repeat steps 5 through 9 three additional times.
11. Position an oil pan under the banjo bolts that connect the fluid cooler tubes to the A/T.
12. Remove the banjo bolts.
13. Flush each steel line from the cooler side back toward the A/T by spraying Transmission Cooler Cleaner in a continuous stream for 5 seconds.
14. Blow compressed air regulated to 5 - 9 kg/cm 2 (70 - 130 psi) through each steel line from the cooler side back toward the A/T for 10 seconds to force out any remaining fluid.
15. Ensure all debris is removed from the steel cooler lines.
16. Ensure all debris is removed from the banjo bolts and fittings.
17. Perform "A/T FLUID COOLER DIAGNOSIS PROCEDURE".

A/T FLUID CHECK

Fluid Leakage and Fluid Level Check

1. Inspect for fluid leakage and check the fluid level. Refer to " «CHANGING THE A/T FLUID (ATF)»(ref-519782-S32269675102012122900000) ".

Fluid Condition Check

Inspect the fluid condition.

Scheme 377

A/T Fluid Temperature Sensor
