TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Altima & Sentra |
| Generator Adjusting Bolt | 12-15 (16-21) |
| Generator Pivot Bolt | 12-15 (16-21) |
| Generator Pulley Nut | 36-47 (49-64) |
| Maxima |
| Generator Adjusting Bolt | 12-15 (16-21) |
| Generator Pivot Bolt | 32-38 (44-52) |
| Generator Pulley Nut | 47-61 (64-83) |
| Frontier |
| Generator Adjusting Bolt | 12-14 (16-19) |
| Generator Pivot Bolt | 32-38 (44-52) |
| Generator Pulley Nut | 36-47 (49-64) |
| Pathfinder |
| Generator Adjusting Bolt | 32-43 (43-58) |
| Generator Pivot Bolt | 32-43 (43-58) |
| Generator Pulley Nut | 29-43 (39-59) |
Charging System Wiring Diagram (Altima). Scheme 1
Scheme 1: Charging System Wiring Diagram (Altima)
Charging System Wiring Diagram (Frontier - 2.4L Engine). Scheme 2
Scheme 2: Charging System Wiring Diagram (Frontier - 2.4L Engine)
Charging System Wiring Diagram (Frontier - 3.3L Engine). Scheme 3
Scheme 3: Charging System Wiring Diagram (Frontier - 3.3L Engine)
Charging System Wiring Diagram (Maxima). Scheme 4
Scheme 4: Charging System Wiring Diagram (Maxima)
Charging System Wiring Diagram (Pathfinder). Scheme 5
Scheme 5: Charging System Wiring Diagram (Pathfinder)
Charging System Wiring Diagram (Sentra). Scheme 6
Scheme 6: Charging System Wiring Diagram (Sentra)
