Steering System: Overhaul Nissan Note E12

DISASSEMBLY

1. Remove outer socket lock nut and outer socket. CAUTION: When loosening outer socket lock nut, be sure to hold outer socket with a suitable tool to prevent ball joint from contacting knuckle.
2. Remove inner boot clamp, outer boot clamp and remove boot. CAUTION: Do not damage inner socket or steering gear housing when removing boot.
3. Remove inner socket.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. Apply (Autolex A or Dow Corning 111) or equivalent to inner socket and turn pinion fully to retract inner socket into gear housing assembly. CAUTION: Make sure there are no contaminants in the grease, on the inner socket, or inside the steering gear housing.
2. Install large end (1) of boot (2) to gear housing assembly.
3. Install small end (3) of boot (2) to inner socket boot mounting groove.
4. Install outer boot clamp to boot small end using suitable tool.
5. Install inner boot clamp to boot large end using suitable tool. CAUTION: Do not reuse boot clamps.
6. Install outer socket.
7. Adjust inner socket to standard length (L) and then tighten lock nut to the specified torque. Check length of inner socket (L) again after tightening lock nut. Inner socket length (L): Refer to " «INNER SOCKET LENGTH»(ref-675600-S41452228272014120500000) ". CAUTION: The length achieved after toe-in adjustment is not necessarily the above value.
8. Check wheel alignment. Refer to " «ADJUSTMENT»(ref-675608-S28541819612014120500000) ". CAUTION: When tightening outer socket lock nut (1), be sure to hold outer socket (2) using a suitable tool to prevent ball joint from contacting knuckle.
