STARTING SYSTEM : Component Description
| Component part | Description |
|---|---|
| TCM | TCM supplies power to the starter relay and starter control relay inside IPDM E/R when the selector lever is shifted to the P or N position. |
| BCM | BCM controls the starter relay inside IPDM E/R. |
| IPDM E/R | CPU inside IPDM E/R controls the starter control relay. |
| Starter motor | The starter motor plunger closes and the motor is supplied with battery power, which in turn cranks the engine, when the "S" terminal is supplied with electric power. |
STARTING SYSTEM COMPONENTS DESCRIPTION
Scheme 10
STARTING SYSTEM : System Description
The starter motor plunger closes and provides a closed circuit between the battery and starter motor. The starter motor is grounded to the engine block. With power and ground supplied, cranking occurs and the engine starts.
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Description
The "B" terminal is constantly supplied with battery power.
The starter motor magnetic switch is supplied with power when the ignition switch is turned to the START position while the selector lever is in the P or N position.
