Camera Specification
| Manufacturer name | SONY Corp. |
|---|---|
| Image pickup element | 1/4-inch CMOS image sensor |
| Effective number of pixels | Approx. 300, 000 pixels (632 x 480) |
| Minimum brightness | 2 lx |
| Angle of view | H: 190.4° V: 141.8° |
| Image | With mirror processing function |
Scheme 1
- Pump control unit is installed in under the luggage floor front finisher.
- Communicates with camera control unit via communication line.
- Activates air pump and washer pump according to the signal from camera control unit.
- Receives rear washer signal from washer switching solenoid valve.
Scheme 2
- Air pump is installed in the luggage floor spacer LH in the luggage room.
- Air pump is activated and generates compressed air when power is supplied from the pump control unit.
- Compressed air jets out from the air nozzle of rear view camera via air tube.
Scheme 3
- Washer switching solenoid valve is installed in the back door.
- When rear washer is in the inactive condition, the solenoid valve is inactive and rear view camera washer path is activated.
- When rear washer is in the active condition, the solenoid valve is active and the washer path is switched to rear washer side.
- When solenoid valve is active, a rear washer signal is transmitted to the pump control unit.
Scheme 4
- Rear view camera washer relay 1 and 2 are installed in the engine room LH
- When the relay is in the inactive state, the circuit of window washer is energized.
- Rear view camera washer relay 1 and 2 are activated according to a signal from the pump control unit and activate the washer pump regardless of window washer activation.
