Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Scheme 26

Scheme 26: Special Service Tools

Scheme 27

Scheme 27: Commercial Service Tools

General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or have their NISSAN dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

Scheme 28

Scheme 28: OUTSIDE THE VEHICLE

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.

Scheme 29

Scheme 29: INSIDE THE VEHICLE

Scheme 30

Scheme 30

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

Scheme 31

Scheme 31: UNDER THE HOOD AND VEHICLE

Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals.

Scheme 32

Scheme 32: Introduction of Periodic Maintenance

Scheme 33

Scheme 33: EMISSION CONTROL SYSTEM MAINTENANCE

Scheme 34

Scheme 34

* Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

For valve clearance procedure, refer to VALVE CLEARANCE .

  1. After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged.
  2. If operating mainly in dusty conditions, more frequent maintenance may be required.
  3. Maintenance-free item. For service procedures, refer to «FUEL SYSTEM»(ref-233997) article.
  4. After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
  5. If valve noise increases, inspect valve clearance.

Scheme 35

Scheme 35: CHASSIS AND BODY MAINTENANCE

Scheme 36

Scheme 36

Note. If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-II every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to CHECK CVT FLUID DETERIORATION DATE .) And if CONSULT-II is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine Nissan CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000) or 24 months. Refer to TIRE ROTATION under the General Maintenance heading earlier in this article.

Scheme 37

Scheme 37: EMISSION CONTROL SYSTEM MAINTENANCE

For valve clearance adjustment procedure, refer to VALVE CLEARANCE .

Note. After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged. Maintenance-free item. For service procedures, refer to FUEL SYSTEM article. After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. If valve noise increases, inspect valve clearance.

* Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required

Scheme 38

Scheme 38: CHASSIS AND BODY MAINTENANCE

Note. Using transmission fluid other than Genuine Nissan CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. Refer to TIRE ROTATION under the General Maintenance heading earlier in this article.

Scheme 39

Scheme 39: Fluids and Lubricants
  1. *1: For further details, see «SAE VISCOSITY NUMBER»(ref-234032-S05806634762006052800000) .
  2. *2: Using transmission fluid other than Genuine Nissan CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty.
  3. *3: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 0°C (32°F).
  4. *4: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON(tm) III/MERCON(tm), or equivalent ATF may also be used.
  5. *5: Available in mainland U.S.A. through your NISSAN dealer.

GASOLINE ENGINE OIL

SAE 5W-30 viscosity oil is preferred for all temperatures. SAE 10W-30 and 10W-40 viscosity oil may be used if the ambient temperature is above -18°C (0°F).

Scheme 40

Scheme 40: GASOLINE ENGINE OIL

Anti-Freeze Coolant Mixture Ratio

The engine cooling system is filled at the factory with a high-quality, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.

CAUTIONWhen adding or replacing coolant, be sure to use only Genuine Nissan Long Life Antifreeze/Coolant or equivalent with the proper mixture ratio of 50% anti-freeze and 50% demineralized water/distilled water.

Other types of coolant solutions may damage your cooling system.

Scheme 41

Scheme 41

Checking Drive Belts

WARNINGBe sure to perform when the engine is stopped.
  1. Inspect belts for cracks, fraying, wear and oil. If necessary, replace.
  2. Inspect drive belt deflection or tension at a point on belt midway between pulleys. Inspection should be done only when engine is cold, or over 30 minutes after engine is stopped. Measure belt tension with tension gauge (BT3373-F or equivalent) at points (Scheme 42) When measuring deflection, apply 98 N (10 kg, 22 lb) at the marked point. Adjust if belt deflection exceeds the limit or if belt tension is not within specifications.

Scheme 42

Scheme 42
CAUTIONWhen checking belt deflection or tension immediately after installation, first adjust it to the specified value. Then, after turning the crankshaft two turns or more, re-adjust to the specified value to avoid variation in deflection between pulleys. Tighten idler pulley lock nut by hand and measure deflection or tension without looseness.

Scheme 43

Scheme 43

Scheme 44

Scheme 44: Belt Deflection and Tension

*: If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on the belt.

POWER STEERING OIL PUMP BELT

  1. Remove splash guard (RH).
  2. Loosen lock bolt (C).
  3. Loosen power steering oil pump mounting bolt (D). Bolt head (D) is engine rear side.
  4. Adjust tension by turning adjusting bolt (E). For specified belt tension, refer to «CHECKING DRIVE BELTS»(ref-234032-S39642082162006052800000) . NOTE: Adjusting bolt (E) is loosened with counterclockwise rotation.
  5. Tighten lock bolt (C). : 28.0 N-m (2.9 kg-m, 21 ft-lb)
  6. Tighten power steering oil pump mounting bolt (D). : 43.2 N-m (4.4 kg-m, 32 ft-lb)

Changing Engine Coolant

WARNINGTo avoid being scalded, never change engine coolant when the engine is hot. Wrap a thick cloth around radiator cap and carefully remove radiator cap. First, turn radiator cap a quarter of a turn to release built-up pressure. Then turn radiator cap all the way. Be careful not to allow engine coolant to contact drive belts.

Scheme 45

Scheme 45: DRAINING ENGINE COOLANT

Scheme 46

Scheme 46
  1. Remove radiator drain hole cap on undercover.
  2. Open radiator drain plug at the bottom of radiator, and then remove radiator cap. When draining all of engine coolant in the system, open water drain plugs on cylinder block. Refer to «DISASSEMBLY»(ref-233993-S09363877202006052800000) .
  3. Remove reservoir tank as necessary, and drain engine coolant and clean reservoir tank before installing.
  4. Check drained engine coolant for contaminants such as rust, corrosion or discoloration. If contaminated, flush the engine cooling system. Refer to «FLUSHING COOLING SYSTEM»(ref-234032-S04796005412006052800000) .

Checking Fuel Lines

Inspect fuel lines, fuel filler cap and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration.

If necessary, repair or replace damaged parts.

Scheme 47

Scheme 47: Checking Fuel Lines

VISCOUS PAPER TYPE

The viscous paper type filter does not need cleaning between replacement intervals. Refer to PERIODIC MAINTENANCE .

Scheme 48

Scheme 48: VISCOUS PAPER TYPE
  1. Unhook air cleaner case (lower) side clips and lift up air cleaner case (upper).
  2. Remove air cleaner filter.

Changing Engine Oil

WARNINGBe careful not to burn yourself, as engine oil may be hot. Prolonged and repeated contact with used engine oil may cause skin cancer; try to avoid direct skin contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible.

Scheme 49

Scheme 49

Scheme 50

Scheme 50
  1. Warm up engine, put vehicle horizontally and check for engine oil leakage from engine components. Refer to «ENGINE OIL LEAKAGE»(ref-233994-S01347141552006052800000) .
  2. Stop engine and wait for 10 minutes.
  3. Loosen oil filler cap, and then remove drain plug.
  4. Drain engine oil.
  5. Install drain plug with new washer. Refer to «OIL PAN AND OIL STRAINER»(ref-233993-S25354294872006052800000) . CAUTION: Be sure to clean drain plug and install with new washer. Oil pan drain plug: : 34.3 N-m (3.5 kg-m, 25 ft-lb)
  6. Refill with new engine oil. Engine oil specification and viscosity: Refer to «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-234032-S17417855162006052700000) . Engine oil capacity (Approximate): CAUTION: When filling engine oil, do not pull out oil level gauge. The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine the proper amount of engine oil in engine.
  7. Warm up engine and check area around drain plug and oil filter for oil leakage.
  8. Stop engine and wait for 10 minutes.
  9. Check the engine oil level.

Scheme 51

Scheme 51: REMOVAL
  1. Remove splash guard (RH).
  2. Using oil filter wrench [SST], remove oil filter. CAUTION: Oil filter is provided with relief valve. Use genuine Nissan oil filter or equivalent. Be careful not to get burned when engine and engine oil may be hot. When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Do not allow engine oil to adhere to drive belts. Completely wipe off any engine oil that adheres to engine and vehicle.

Scheme 52

Scheme 52: INSTALLATION

Scheme 53

Scheme 53
  1. Remove foreign materials adhering to oil filter installation surface.
  2. Apply engine oil to the oil seal contact surface of new oil filter.
  3. Screw oil filter manually until it touches the installation surface, then tighten it by 2/3 turn. Or tighten to specification. Oil filter: :17.6 N-m (1.8 kg-m, 13 ft-lb)

Checking EVAP Vapor Lines

  1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
  2. Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to «EVAPORATIVE EMISSION SYSTEM»(ref-233996-S22328976352006052800000) .

Checking Exhaust System

Check exhaust pipes, muffler and mounting for improper attachment, leaks, cracks, damage, chafing or deterioration.

Scheme 54

Scheme 54: Checking Exhaust System
  1. If anything is found, repair or replace damaged parts.

Checking Transfer Oil

Check for oil leakage and oil level.

CAUTIONNever start engine while checking oil level.
  1. Filler plug: : 14.7 N-m (1.5 kg-m, 11 ft-lb)

Scheme 55

Scheme 55

Changing Transfer Oil

CAUTIONWhen draining oil, protect exhaust tube flange with cover.

Scheme 56

Scheme 56
  1. Drain oil from drain plug and refill with new gear oil.
  2. Check oil level. CAUTION: Carefully fill the oil. (Fill up for Approx. 3 minutes.) Oil grade: API GL-5 Viscosity: Refer to «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-234032-S17417855162006052700000) . Oil capacity: : Approx. 0.31 l (5/8 US pt, 1/2 lmp pt) Drain plug: : 14.7 N-m (1.5 kg-m, 11 ft-lb) Filler plug: : 14.7 N-m (1.5 kg-m, 11 ft-lb)

Checking Propeller Shaft

Check propeller shaft for damage, looseness or grease leakage.

Scheme 57

Scheme 57: Checking Propeller Shaft
  1. Tightening torque: Refer to «REAR PROPELLER SHAFT»(ref-234002-S13531087652006052700000) .

Scheme 58

Scheme 58: Checking Differential Gear Oil
  1. Check for oil leakage.

Scheme 59

Scheme 59: Changing Differential Gear Oil
  1. Drain oil from drain plug and refill with new gear oil.
  2. Check oil level. Oil grad and Viscosity: Refer to «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-234032-S17417855162006052700000) . Capacity: 0.55 l (1-1/8 US pt, 1 lmp pt) Drain plug: : 34.5 N-m (3.5 kg-m, 25 ft-lb) Filler plug: : 34.5 N-m (3.5 kg-m, 25 ft-lb) CAUTION: Gaskets are not reusable. Never reuse them.

ROTOR

Check condition, wear, and damage.

FrontRear
Brake modelCLZ31VBAD14VE
Standard thickness28.0 mm (1.102 in)16.0 mm (0.630 in)
Maximum runout0.04 mm (0.0016 in)0.05 mm (0.0020 in)
Minimum thickness (Wear limit)26.0 mm (1.024 in)14.0 mm (0.551 in)

DISC BRAKE SPECIFICATIONS CHART

Scheme 60

Scheme 60: CALIPER
  1. Check for leakage.

PAD

  1. Check for wear or damage.
Brake modelCLZ31VBAD14VE
Standard thickness9.5 mm (0.374 in)8.5 mm (0.335 in)
Minimum thickness (Wear limit)2.0 mm (0.079 in)2.0 mm (0.079 in)

BRAKE PAD SPECIFICATIONS CHART

Scheme 61

Scheme 61

STEERING GEAR

  1. Check gear housing and boots for looseness, damage and grease leakage.
  2. Check connection with steering column for looseness.

Scheme 62

Scheme 62

STEERING LINKAGE

Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.

Axle and Suspension Parts

Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.

  1. Shake each wheel to check for excessive play.
  2. Check wheel bearings for smooth operation.
  3. Check axle and suspension nuts and bolts for looseness.
  4. Check strut (shock absorber) for oil leakage or other damage.
  5. Check suspension ball joint for grease leakage and ball joint dust cover for cracks or other damage.

Scheme 63

Scheme 63

Scheme 64

Scheme 64

Drive Shaft

Check boot and drive shaft for cracks, wear, damage and grease leakage.

Scheme 65

Scheme 65: Drive Shaft

Scheme 66

Scheme 66: Lubricating Locks, Hinges and Hood Latch

Scheme 67

Scheme 67: Checking Seat Belt, Buckles, Retractors, Anchors and Adjusters

Scheme 68

Scheme 68: BELT DEFLECTION AND TENSION

SPARK PLUG (PLATINUM-TIPPED TYPE)

MakeNGK
Standard typePLFR5A-11
Hot typePLFR4A-11
Cold typePLFR6A-11
Gap (nominal)1.1 mm (0.043 in)

SPARK PLUG (PLATINUM-TIPPED TYPE) SPECIFICATIONS CHART

Scheme 69

Scheme 69: WHEEL BALANCE
