Engine Cooling System: Overhaul Nissan Murano Z50

DISASSEMBLY

1. Remove cooling fans (RH and LH) from fan motors.
2. Remove fan motors from fan shroud.

ASSEMBLY

Assemble in the reverse order of disassembly.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. Remove engine cover. Refer to «INTAKE MANIFOLD COLLECTOR»(ref-233993-S36113184132006052800000) .
2. Remove air duct (inlet) and radiator cover grills (right and left sides). Refer to «AIR CLEANER AND AIR DUCT»(ref-233993-S13601402462006052800000) .
3. Remove undercover and splash guard (RH).
4. Drain engine coolant from radiator. Refer to «CHANGING ENGINE COOLANT»(ref-233995-S01322841342006052700000) . CAUTION: Perform this step when the engine is cold. Do not spill engine coolant on drive belts.
5. Remove drive belts. Refer to «DRIVE BELTS»(ref-233993-S14607392772006052800000) .
6. Remove reservoir tank of radiator. Refer to «RADIATOR»(ref-233995-S41746158612006052700000) .
7. Remove reservoir tank of power steering oil pump with piping connected, and move it to aside. Refer to «HYDRAULIC LINE»(ref-234012-S14474342682006052700000) .
8. Support oil pan (lower) bottom with transmission jack.
9. Remove RH engine mounting insulator and RH engine mounting bracket. Refer to «ENGINE ASSEMBLY»(ref-233993-S16501809062006052800000) .
10. Remove water drain plug (front) on water pump side of cylinder block to drain engine coolant from engine inside.
11. Remove chain tensioner cover and water pump cover from front timing chain case. Use the seal cutter [SST: KV10111100 (J37228)] to cut liquid gasket for removal.
12. Remove idler pulley and bracket. Refer to «TIMING CHAIN»(ref-233993-S27825796252006052800000) .
13. Remove timing chain tensioner (primary) as follows: Pull lever down and release plunger stopper tab. Plunger stopper tab can be pushed up to release (coaxial structure with lever). Insert stopper pin into tensioner body hole to hold lever, and keep tab released. NOTE: An alien wrench [2.5 mm (0.098 in)] is used for the stopper pin as an example. Insert plunger into tensioner body by pressing slack guide. Keep slack guide pressed and hold plunger in by pushing stopper pin through the lever hole and tensioner body hole. Turn crankshaft pulley clockwise so that timing chain on the timing chain tensioner (primary) side is loose. Remove mounting bolts and remove timing chain tensioner (primary). CAUTION: Be careful not to drop mounting bolts inside timing chain case.
14. Remove water pump as follows: Remove three water pump mounting bolts. Secure a gap between water pump gear and timing chain, by turning crankshaft pulley counterclockwise until timing chain looseness on water pump sprocket becomes maximum. Screw M8 bolts [pitch: 1.25 mm (0.049 in) length: approx. 50 mm (1.97 in)] into water pumps upper and lower mounting bolt holes until they reach timing chain case. Then, alternately tighten each bolt for a half turn, and pull out water pump. CAUTION: Pull straight out while preventing vane from contacting socket in installation area. Remove water pump without causing sprocket to contact timing chain. Remove M8 bolts and O-rings from water pump. CAUTION: Do not disassemble water pump.

Scheme 16

1. Check for badly rusted or corroded water pump body assembly.
2. Check for rough operation due to excessive end play.
3. If anything is found, replace water pump.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Install new O-rings to water pump. Apply engine oil and engine coolant to O-rings (Scheme 17) Locate O-ring with white paint mark to engine front side.
2. Install water pump. CAUTION: Do not allow cylinder block to nip O-rings when installing water pump. Check that timing chain and water pump sprocket are engaged. Insert water pump by tightening mounting bolts alternately and evenly.
3. Install timing chain tensioner (primary) as follows: Remove dust and foreign material completely from backside of timing chain tensioner (primary) and from installation area of rear timing chain case. Turn crankshaft pulley clockwise so that timing chain on the timing chain tensioner (primary) side is loose. Install timing chain tensioner (primary) with its stopper pin attached. CAUTION: Be careful not to drop mounting bolts inside timing chain case. Remove stopper pin. Make sure again that timing chain and water pump sprocket are engaged.
4. Install chain tensioner cover and water pump cover as follows: Before installing, remove all traces of old liquid gasket from mating surface of water pump cover and chain tensioner cover using scraper. Also remove traces of old liquid gasket from the mating surface of front timing chain case. Apply a continuous bead of liquid gasket with the tube presser [SST: WS39930000 (-)] to mating surface of chain tensioner cover and water pump cover. Use Genuine RTV Silicone Sealant or equivalent. Refer to «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-233992-S15687029032006052800000). CAUTION: Attaching should be done within 5 minutes after coating. Tighten mounting bolts.
5. Install water drain plug (front) on water pump side of cylinder block. Apply liquid gasket to the thread of water drain plug (front). Use Genuine RTV Silicone Sealant or equivalent. Refer to «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-233992-S15687029032006052800000).
6. Install in the reverse order of removal after this step. After starting engine, let idle for three minutes, then rev engine up to 3,000 rpm under no load to purge air from the high-pressure chamber of chain tensioner. Engine may produce a rattling noise. This indicates that air still remains in the chamber and is not a matter of concern.
