Driver Information System: Wiring Nissan Murano Z50

Wiring Diagram - METER

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Check Fuel Level Sensor Unit and Pump (Main) Harness

Check continuity between fuel level sensor unit and fuel pump (main) connector terminals 5 and 7.

1. 5-7: Continuity should exist.

Scheme 62

Wiring Diagram - COMPAS

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 63

Wiring Diagram - WARN

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. CHECK SELF-DIAGNOSTIC RESULTS OF UNIFIED METER AND A/C AMP. Select "METER A/C AMP" on CONSULT-II, and perform self-diagnosis of unified meter and A/C amp. Refer to «CONSULT-II FUNCTION (METER A/C AMP)»(ref-234025-S04548917222006052700000) . Self-diagnostic results content NO malfunction detected >> GO TO 2 . Malfunction detected >> Go to «SYMPTOM CHART 2»(ref-234025-S23917450822006052800000) .
2. CHECK IPDM E/R OUTPUT SIGNAL Activate IPDM E/R auto active test. Refer to «AUTO ACTIVE TEST»(ref-234031-S40161353102006052700000) . Does oil pressure warning lamp blink? YES: GO TO 5 . NO: GO TO 3 .
3. CHECK BCM INPUT SIGNAL Select "DATA MONITOR" of "SIGNAL BUFFER". Refer to «CONSULT-II FUNCTION (BCM)»(ref-234027-S09240865192006052700000) . Operate ignition switch with "OIL PRESS SW" of "DATA MONITOR" and check operate status. "OIL PRESS SW" When ignition switch is in ON: ON position (Engine stopped) When engine running: OFF OK or NG OK: GO TO 4 . NG: Replace IPDM E/R. Refer to «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-234031-S04459342902006052700000) .
4. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL Select "METER A/C AMP" on CONSULT-II. Operate ignition switch with "OIL W/L" of "DATA MONITOR" and check operation status. "OIL W/L" When ignition switch is in ON: ON position (Engine stopped) When engine running: OFF OK or NG OK: Replace combination meter. NG: Replace BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-234027-S03884723312006052700000) .
5. CHECK OIL PRESSURE SWITCH CIRCUIT Turn ignition switch OFF. Disconnect IPDM E/R connector and oil pressure switch connector. CHECK continuity between IPDM E/R harness connector E9 terminal 57 (P/L) and oil pressure switch harness connector F203 terminal 1 (R/L). 57 (P/L) - 1 (R/L): Continuity should exist. OK or NG OK: GO TO 6 . NG: Repair harness or connector.
6. CHECK OIL PRESSURE SWITCH Check oil pressure switch. Refer to «OIL PRESSURE SWITCH»(ref-234025-S25194332052006052800000) . OK or NG OK: Replace IPDM E/R. Refer to «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-234031-S04459342902006052700000) . NG: Replace oil pressure switch.

Wiring Diagram - CVTIND

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

1. CHECK SELF-DIAGNOSIS OF COMBINATION METER Perform combination meter self-diagnosis. Refer to «OPERATION PROCEDURE»(ref-234025-S36495395642006052800000) . Are all segments displayed? YES: GO TO 2 . NO: Replace combination meter.
2. CHECK SELF-DIAGNOSTIC RESULTS OF UNIFIED METER AND A/C AMP. Select "METER A/C AMP" on CONSULT-II, and perform self-diagnosis of unified meter and A/C amp. Refer to «CONSULT-II FUNCTION (METER A/C AMP)»(ref-234025-S04548917222006052700000) . Self-diagnostic results content NO malfunction detected >> GO TO 3 (With manual mode) or GO TO 4 (Without manual mode). Malfunction detected >> Go to «SYMPTOM CHART 2»(ref-234025-S23917450822006052800000) .
3. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL Connect CONSULT-II and start engine. Use "DATA MONITOR" of "METER A/C AMP" on CONSULT-II. Confirm each indication on the monitor when operating the shift lever. OK or NG OK: Replace combination meter. NG: GO TO 5 .
4. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL Connect CONSULT-II and start engine. Use "DATA MONITOR" of "METER A/C AMP" on CONSULT-II. Confirm each indication on the monitor when operating the shift lever. OK or NG OK: Replace combination meter. NG: GO TO 5 .
5. CHECK CVT DEVICE Check the following. CVT device (Manual mode switch) inspection. Refer to «DTC P0826 MANUAL MODE SWITCH CIRCUIT»(ref-234000-S20995996112006052800000) (With manual mode). CVT device (Second position switch). Refer to «SECOND POSITION SWITCH»(ref-234000-S39842924522006052800000) (Without manual mode). OK or NG OK: GO TO 6 . NG: Repair corresponding parts.
6. CHECK TCM Check TCM input/output signal. Refer to «TCM INPUT/OUTPUT SIGNAL REFERENCE VALUES»(ref-234000-S38955627672006052800000) . OK or NG OK: Replace the unified meter and A/C amp. Refer to «REMOVAL AND INSTALLATION OF UNIFIED METER AND A/C AMP.»(ref-234025-S11827483532006052800000) . NG: Check applicable parts, and repair or replace corresponding parts.

Wiring Diagram - CHIME

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90
